Page 1: User Manual
Wireless Digital Microscope 2.4GHZ Wireless Digital Microscope S05-200X User Manual （English） repared by oolingtech Digital Engineering Dept. 2012.10.1 1/22... -
Page 2: Table Of Contents
Wireless Digital Microscope 2.4GHZ Thank you for Purchasing our S05-200X Digital Microscope, it is a slim type tool and can be easily used in different fields including 1. Textile industrial for textile inspection 2. Printing inspection 3. Industrial inspection: PCB, Precision machinery…... -
Page 3: Parts Of Microscope
Wireless Digital Microscope 2.4GHZ Parts of Microscope ① DC 5V socket ② Switch On/Off & light brightness adjust wheel ③ 2.4GHZ indicator light ④ Focus Roller ⑤ Ratio scale ⑥ Lens ⑦ LED Light source Specification Image CMOS Sensor Controller High Speed DSP (Driver Free available) Focus Range 0mm ~ 40mm Snap Shot Software Frequency 2.4GHZ... -
Page 4: Notes Before Use
Wireless Digital Microscope 2.4GHZ 1600*1200 ,800*600, Frame Rate 25 f/s VGA under 600 LUX Brightness 20f/s QVGA under 600 LUX Brightness Brightness Control Manual adjustment Magnification Range 5X ~ 200X (Manually) Power Supply TX Rechargeable lithium battery RX 5V DC from USB port USB 2.0 &... - Page 5 Wireless Digital Microscope 2.4GHZ 7. Measurement Data only for reference. 8. The effective range is 10m. Standard parts and accessories 1. Digital Microscope (1pc) 2. Charger (1pc) include power line 3. Signal receive base (1pc) 4. CD ROM (Driver & Measurement) 5.
-
Page 6: Hardware And System Requirements
Wireless Digital Microscope 2.4GHZ 2 Connect the signal receive base to the PC, after connected, the indicator light on. indicator USB port Wireless Signal Receive Base 3 If the transmitter indicator stops blink, and lights on all the time, it means the signal connected already. -
Page 7: How To Install The Measurement Software
Wireless Digital Microscope 2.4GHZ If you can’t find the Video device, or if your computer can’t recognize it, please follow below steps to install the software Insert the attached CD, system will auto run to the interface as below and follow the steps to complete the installation: (NOTE：If the computer can’t auto run the disc, you need to operate manually by click “My Computer”... - Page 8 Wireless Digital Microscope 2.4GHZ 2 Measurement installations 1 Click to continue, as followings 2 Click “next” to continue, as followings 8/22...
- Page 9 Wireless Digital Microscope 2.4GHZ 3Click “next” to continue, as followings 4 Click “next” to continue, as followings 9/22...
- Page 10 Wireless Digital Microscope 2.4GHZ 5 Click “next” to continue, as followings 6Click “Install” to continue, as followings Wait a few seconds while the installation taking place. 10/22...
- Page 11 Wireless Digital Microscope 2.4GHZ 7Click “Finish” and the installation completes. 8After the installation completes, double click at computer desktop to start using the software. Plug-in the devices, Display in operation window 11/22...
- Page 12 Wireless Digital Microscope 2.4GHZ 9 Click ,open the operation system 10Click “OK” 12/22...
-
Page 13: Function Options
Wireless Digital Microscope 2.4GHZ 11Click to use measurement function. 12Tool bar open the operation system open picture Photo save pictures a s Bump or Jpeg format export word or excel format. 13/22... - Page 14 Wireless Digital Microscope 2.4GHZ Video PLAY(Pause) ,STOP Image Parameter including Image setting and special effects Do undo Zoom Ruler Line & calibration Color setting &图形组合 13How to Measure Line 14/22...
- Page 15 Wireless Digital Microscope 2.4GHZ rectangle ellipse 15/22...
- Page 16 Wireless Digital Microscope 2.4GHZ folding line 16/22...
- Page 17 Wireless Digital Microscope 2.4GHZ polygon Point to point 17/22...
- Page 18 Wireless Digital Microscope 2.4GHZ point to line、 circle 18/22...
- Page 19 Wireless Digital Microscope 2.4GHZ angle Measure angle from 4 points 19/22...
- Page 20 Wireless Digital Microscope 2.4GHZ Measure parallel 14 Calibration Click start calibration make sure certain accuracy. Our experience told us that measurement could be controlled at 99% high precision. Measure tolerance could be caused from human eye distortion and defocus. More practice is helpful to measurements. 1 Click as followings 2 Click ‘next’as followings...
- Page 21 Wireless Digital Microscope 2.4GHZ 3，Click ‘Finish’as followings 4 Put the calibration ruler under the microscope, the measure standard unit like 1mm as below y 轴 X轴 Then use the standard unit 1mm divide measurement data, so you got the deviate data, for example（X :1/0.056=17.86 Y: 1/0.044=22.73) Put the deviate data to below column, please do calibration again once Magnification Ratio changed.
-
Page 22: How To Do The Calibration
Wireless Digital Microscope 2.4GHZ Warning: Please do calibration again once Magnification Ratio changed. 3Please click to Continue when the NET Framework2.0 is necessary 22/22...
