Summary of Contents for Gi spark2

  • Page 2: Table Of Contents

    1.4 Real panel of spark2 ....................................6 1.5 Remote control ......................................7 1.5.1 What does the function of power key on spark2 remote control? ................8 1.5.2 How to check working status of spark2 remote control? ....................8 1.5.3 How to activate air mouse? ..............................8 1.5.4 How to pair your spark2 remote control as a game handle? ..................
  • Page 3 5.5.3 3Gnetwork ..................................... 26 5.5.4 Network harddrive ..................................26 5.5.5 DLNA ........................................ 27 5.5.6 Airplay ......................................28 5.5.7 VPN ........................................28 5.5.8 PVR ........................................28 5.5.9 Language ....................................... 29 5.5.10 DATE & TIME ..................................... 29 5.5.12 Upgrade ....................................... 30 5.5.13 Remote control ..................................31 5.5.14 Reset ......................................

  • Page 4: Product Introduction

    1. Product introduction 1.1 Spark2 specifications Main Processor Dual core Cortex-A9 CPU up to 1.5Ghz Flash Memory SPI Flash:2Mbytes; Nand Flash :8Gbytes DDR SDRAM 1GBytes Tuner Type DVB-S/DVB-S2 Input Connector F-type,Connector,Female Input Voltage DC 12V/2A Power Consumption MAX:20W, Standby:<0.5W Remote 2.4G RF,support mouse and G-sensor...

  • Page 5: Packing List

    1.2 Packing list Please check all package contents before using your spark2.

  • Page 6: Front Panel Of Spark2

    1.3 Front panel of spark2 1.4 Real panel of spark2 What does the function of power key on front panel? Short press power key to turn the spark2 power  on or off. Press and hold power key for 3 seconds to call up ...

  • Page 7: Remote Control

    1.5 Remote control 1, POWER – switch on or switch off receiver & remote control 2, Operation light-indicates RCU’s operation status such as connection, battery 3, MUTE- switches on or switch off receiver’s sound 4, Game- activate or deactivate G-sensor function 5, Game light- indicates G-sensor is active or not 6, BACK- back to the previous menu 7, MENU-the entry of application’s function...

  • Page 8: What Does The Function Of Power Key On Spark2 Remote Control

    -What does the game light color mean? Press and hold power key for 3 seconds on the remote Lights up blue when short press the game key. control to switch on or switch off spark2 remote control. A faint blinking blue indicates the remote control ...

  • Page 9: How To Pair Your Spark2 Remote Control As A Game Handle

    90 1, Open the game, short press key on remote degree parallel to the spark2 screen.

  • Page 10: How To Scrolling Quickly Through Long Lists

    3, Once paired, remote control will response with a vibrating alert and the operating status light changes to solid blue , at the same time spark2 TV displays success message " the remote control with ID: XXXXXXX has been paired successfully with spark2 box" .

  • Page 11: Power-Saving Feature

    1.5.9 Power-saving feature 1.6 Setting up spark2 The power-saving feature automatically switches spark2 remote control to off if no control is operated in 3 hours. In this case, long press the power key on the remote control to turn on remote control.

  • Page 12: First Time Installation

    Select the save option to confirm your settings. The wifi submenu is used when spark2 connects to network via a wireless connection. Select wifi submenu, a screen appears showing the search results for available Use UP/DOWN key to scroll up and down to select the desired language and confirm with OK.

  • Page 13: Step3 Time Setting

    2.3 Step3 time setting You can set the time Auto update by DVB or network Then press key then below screen appears:. mode. Set the Auto update to OFF if you want to use a certain fixed time. In this case, you need to enter correct time in date and time field with number keys.

  • Page 14: Step5 Simple Install

    2.5 Step5 simple install When you have completed your settings by pressing key, the Simple Install appears. This menu allows you to configure 4 satellites with diseqc1.0 or 16 satellites with diseqc1.1. Use the left/right arrow keys to move the highlight to the diseqc column and use the up/down arrow keys to switch between diseqc1.0 and diseqc1.1.

  • Page 15: Home Page

    3 Home page 4 TV After you finish easy install setup and exit, spark2 will 4.1 TV Home Page automatic play TV programs. Press to display the TV Home page. There are five Home pages in spark2: App, TV, OTT, Media and Browser, you are able to press keys switch them.
  • Page 16 In all page you are allow to do below operations: Press key to select channel. Press key to display type list for selection. Press key add the selected channels to FAV group. Press key to sort the list. Press key to display the detailed information of the highlight channel.

  • Page 17: Switching Channel

    4.2 Switching Channel Spark2 offers various channel zapping methods: Press UP and DOWN arrow keys to switch channel while watching a program on full screen. Use the navigation arrow keys to browse the channel in TV home page. Enter a channel number instantly switch to the channel you want.

  • Page 18: Simple Tv Setting

    4.5 Simple TV Setting Press Menu key to display Simple TV Setting menu while watching a program. Screen ratio: Using up and down arrow keys to select Adjust time: adjust subtitle delay time to sync subtitle a proper screen ratio and confirmed your setting with OK with program.

  • Page 19: Electronic Program Guide

    4.6 Electronic Program Guide reservation. Select ON for repeated reserve zapping or recording per Daily / Weekly / User defined. Press key or right arrow key to access the electronic start Date & End date  program guide. The electronic program guide displays This entry is given only when you selected off in the program information for all available channels Repeat Type, in this case you can manual set the...

  • Page 20: Timeshift

    • press right /left arrow keys jump forward/ backward 20 Spark2 can not record a program from one channel while seconds at a time and then press ok key to confirm jump. you are watching another program on two different channels at the same time.

  • Page 21: App

    5.1 APP Home page App home page is your starting point to access all the applications on your Spark2. Using navigation arrow keys or move to the desired application Select the Launcher icon to open application.
  • Page 22 new transponders. ‘NIT Off’ is used to scan the channels 1, Satellite List based on the current transponder. Use the UP/DOWN arrow keys to browse satellite list. Press the OK key to mark the selected satellite. You can Polarization: Select Horizontal or Vertical. This ...
  • Page 23 2. Edit Satellite This menu used to configure the satellite setting. This mode will allow you to set the antenna position for each satellite. In order to use antenna positioner you must use a motor controlled by DiSEqC 1.2 commands. To move the antenna, you need first set your desired move limit, then select the move dish by continue or step size and press the ok key to start move the antenna West...
  • Page 24 3, TP LIST transponder After entering TP frequency, symbol rate, polarization TP list display satellite’s default list. specific and select Modulation, press OK key to save this Use the UP/DOWN arrow keys to browse satellite list. Press the OK key to mark the selected satellite. You can transponder ransponder.

  • Page 25: Online Install

    5.4 Online install 5.5 Settings Highlight the Online install item in APP home page Highlight the settings item in APP home page then then press OK key enter, or press menu key in TV ok list press OK key enter, Press keys to switch choose...

  • Page 26: Lan Network

    5.5.4 Network harddrive Once a shared folder exists on your local computer, and your computer with your spark2 box is connected to your local network, it allows you to set the shared folder as a remote hard drive on your spark2.

  • Page 27: Dlna

    Once a DLNA media server is exist on your local network, set the DLNA option at ON will allows you to set your spark2 as a client to play audio, video and photo Disk name: press right arrow key to select the disk ...

  • Page 28: Airplay

    — Photos, Videos and Music with your iphone/ipad.Tap the Airplay icon to display a list of available Airplay devices, select the name of your spark2 box which set on Access point name option. If everything is ok, airplay will send your wirelessly Photos, Videos and Music from your iphone/ipad to your spark2 TV.

  • Page 29: Language

     Subtitle display: When you have this option on AUTO 5.5.9 Language that means spark2 will display subtitle automatically if the program provides a subtitle track. When you have this option on Manual that means you need open the subtitle manually if the program provides a subtitle track.

  • Page 30: Upgrade

    Stable update: output. Press key to start ‘stable update ‘, your spark2 PCM is used when you want to set the audio output will start searching for an update. If a newer version is always to be pcm.In this case even if the program you available, the selections ‘update now ‘will be highlight.

  • Page 31: Remote Control

    Air mouse speed: adjust the air mouse speed to control how fast the cursor moves across your screen when you move the mouse. 2, you are able to reboot spark2, wipe&reset spark2 and Speech language: select the language for voice input upgrade update. Zip from recovery mode Speech control: Enable or disable voice input.

  • Page 32: Reset

    5.5.14 Reset 5.5.15 Parental Setting Load from factory default: Censorship classification: set the Age rating as you Select this option, then a warning message will be want displayed. To confirm, all satellite and transponder lists will be set to the factory default. Time control&...

  • Page 33: Display Area

    Auto standby: ON is used to allow spark2 automatic go Press key to add a Google account, Follow the to standby mode if there is no operation in 3 hours. on-screen-instructions to set up your Google account. Press key to delete the selected account.

  • Page 34: File List

    5.6 File list To copy, cut and paste files to another folder, perform the following steps: Press blue key to select your desired files for copy or Select the folder where you want to paste it. Press the Menu button, and select the paste option. Highlight the file list item in APP home page then...

  • Page 35: Timermanage

    5.8 TimerManage 5.10 Downloads To download a file: You can download files and even applications from web pages. Different WebPages offer different mechanisms for downloading pictures, documents, applications, and other files. Click & hold an image or a link to a file or to another webpage start download.

  • Page 36: Backup

    With the Spark Web server you can Control your spark2 box using a browser on pc or mobile device, you can watch TV, look up EPG-information, set and handle timers, send messages, use its virtual Remote Control 5.12 Spark Player connector...

  • Page 37: Miracast

    5.13 Miracast Miracast lets you duplicate your Android device's screen on your Spark2 TV so you can watch HD movies, play music, or supersize your favorite apps. To make use of Miracast, you'll need a Miracast-compatible Android device. Turn the miracast feature on, and wait a moment while the device looks for your spark2.

  • Page 38: Ott

    Alternatively, if you cannot Press key to delete current city. find the applications you need on Spark2 app Store, you Press key to add a new city. may look for and download the application files in the form of “.apk”...

  • Page 39: Media

    7 Media 7.2 Record Highlight the record item in APP home page or Media home page then press OK key enter record player. Press 7.1 Movie keys to switch channel, file and Timeline page. Highlight the Movie item in APP home page or Media home page then press OK key enter...

  • Page 40: Music

    7.3 Music Highlight the Music item in APP home page or Media 7.4 Photo home page then press OK key enter music player. Press Highlight the Photo item in APP home page or Media keys to switch favorite, file and history list page. home page then press OK key enter Photo player.

  • Page 41: Browser

    8 Browser Highlight the browser item in APP home page then press OK key enter browser player open browser home page then choose a exist default browser label enter. Press keys to switch label, Browser, Favorite, Recommended and Most Visited page. Enter browser page it allows the users to do the operations as listed below: Press...

  • Page 42: Troubleshooting

    1. No video on TV • Check first if the product is powered on and in operational mode. • Check if the video cable is properly connected between TV and spark2. • Check if the satellite cable is properly connected to spark2.
