Instruction Manual
DVI to DisplayPort Adapter with Audio
DVI2DPA
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
The DVI2DPA DVI to DisplayPort Adapter (with 2-Channel Audio)
converts a DVI-D (Digital), Mini-DVI or HDMI source signal and
accompanying audio, for use with a DisplayPort monitor.
Supporting resolutions up to 1920x1200, this USB-Powered device
offers easy plug-and-play installation with both PC and Mac®
platforms, ensuring seamless operation with your DisplayPort
display to save the time and hassle of hardware upgrades.
A complete, out-of-the-package solution, this DVI DisplayPort
adapter includes all cables necessary for connecting a DVI-D video
source and accompanying audio (3.5mm stereo audio) to any
DisplayPort monitor, and can also be used with Mini DVI or Mini
HDMI sources using additional cables (sold separately).
Packaging Contents
• 1 x DVI to DisplayPort Adapter
• 1 x DisplayPort Cable
• 1 x 1 x 3.5mm Audio Cable
• 1 x USB type mini-B to USB A Cable
• 1 x Instruction Manual
System Requirements
• DVI-D enabled video source device (e.g. computer)
• Two adjacent USB ports on the video source device
• DisplayPort enabled display device (e.g. monitor)
For the most up-to-date information, please visit: www.startech.com
Installation
To ensure the best results, make sure all devices are powered off
before beginning the installation.
1. Connect the DVI connector on the video converter directly to a
DVI-D enabled video source (i.e. computer).
2. Connect the USB cable from the video converter to two adjacent
USB ports on the video source device. NOTE: Some high powered
USB ports can power the adapter with a single USB port, however
having both connectors plugged in is recommended.
3. OPTIONAL: If using audio, connect a 3.5mm audio cable from the
sound card to the video converter.
4. Connect a DisplayPort cable (sold separately) from the DisplayPort
connector on the video converter, to the external display
(i.e. monitor).
5. Power on the display.
6. Power on the video source.
*actual product may vary from photos
Manual Revision: 02/26/2013
