Instructions for
installation and use
EN
English,1
AQUALTIS
AQ113D 697 E
WASHING MACHINE
Contents
Installation, 2-3-4-5
Cutting off the water and electricity supplies
Trouble shooting, 13-14
Assistance, 15-16
EN
1
Advertisement
Table of Contents
Related Manuals for Hotpoint AQUALTIS AQ113D 697 E
Summary of Contents for Hotpoint AQUALTIS AQ113D 697 E
-
Page 1: Table Of Contents
Instructions for installation and use WASHING MACHINE Contents Installation, 2-3-4-5 Unpacking and levelling Connecting the electricity and water supplies English,1 Technical data Description of the machine, 6-7 Touch control panel Running a wash cycle, 8 Wash cycles and options, 9 Table of wash cycles Wash options Detergents and laundry, 10... -
Page 2: Installation
Installation ! This instruction manual should be kept in a safe place ! If the appliance is levelled correctly, it will be more stable for future reference. If the washing machine is sold, given and much less likely to cause vibrations and noise while it away or moved, please ensure the manual is kept with is operating, particularly during the spin cycle. -
Page 3: Aqualtis
Connecting the drain hose • the supply voltage is included within the values indica- ted on the Technical Data Plate fixed on the machine. Connect the drain hose, • the socket is compatible with the washing machine’s without bending it, to a plug. -
Page 4: Aqualtis
As the colours of the wires in the lead may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows: Connect Green & Yellow wire to terminal marked E or or coloured Green or Green & Yellow. Connect Brown wire to terminal marked L or coloured Red. -
Page 5: Technical Data
Technical data Model AQ113D 697 E width 59.5 cm Dimensions height 85 cm depth 64,5 cm Capacity from 1 to 11 kg Electrical please refer to the technical data plate fixed to the machine connections maximum pressure 1 MPa (10 bar) Water connections minimum pressure 0.05 MPa (0.5 bar) drum capacity 71 litres... -
Page 6: Description Of The Machine
Description of the machine CONTROL PANEL PORTHOLE DOOR PORTHOLE DOOR HANDLE KICK STRIP PORTHOLE DOOR Always use the handle to washing additives compartment: for fabric softener open the porthole door (see or liquid additives. We recommend that the maximum level indicated by the grille is not exceeded, and that figure). -
Page 7: Touch Control Panel
START/PAUSE Touch control panel button with indicator light SPIN WASH button CYCLE WASH CYCLE PHASE TEMPERATURE SELECTOR knob indicator light button icons DISPLAY CHILD LOCK button OPTION ON/OFF Button with with indicator light DELAYED START buttons indicator light button LOCK indicator light button again;... -
Page 8: Running A Wash Cycle
Running a wash cycle WARNING: before you use the washing machine for the To remove the delayed start option, press the button first time, run a wash cycle with detergent and no laundry, until the display shows the text OFF; the symbol will using the 90°... -
Page 9: Wash Cycles And Options
Wash cycles and options Table of wash cycles Detergent and addi- Max. load (kg) Max. tives Max. temp. Cycle Icon Description of the wash cycle speed (°C) Detergent Fabric duration Normal (rpm) for wash softener Cotton Coloureds (2-3): lightly soiled whites and delicate colours. 40°... -
Page 10: Detergents And Laundry
Detergents and laundry Coloureds: use this cycle to wash bright coloured Detergent clothes. The programme is designed to maintain bright The type and quantity of detergent required depend on the colours over time. type of fabric you are washing (cotton, wool, silk, etc.), as Darks: Use programme to wash dark-coloured well as its colour, the washing temperature, the level of soiling... -
Page 11: Precautions And Advice
Precautions and tips ! The machine was designed and constructed in The crossed-out dustbin is marked on all products accordance with international safety regulations. The to remind the owner of their obligations regarding following information is provided for safety reasons and separated waste collection. -
Page 12: Care And Maintenance
Care and maintenance Cutting off the water and electricity To access the pre-chamber: supplies • Turn off the water tap after every wash cycle. This will limit wear on the hydraulic system in the machine and help to prevent leaks. •... -
Page 13: Trouble Shooting
Trouble shooting Your washing machine could occasionally fail to work. Before contacting the Technical Assistance Centre (see “Assistance”), make sure that the problem cannot be not solved easily using the following list. Problem: Possible causes / Solutions: • The appliance is not plugged into the socket fully, or not enough to make contact. The machine does not switch on. - Page 14 The machine is noisy. • There will always be some motor, pump and drum noise during spin. The machine wont spin properly. • Out of Balance detected when attempting to go into a spin cycle - If this happens the machine will continue to try to repeat the distribution of the load required before the machine will go into higher spin speeds - This will increase the programme time accordingly.
-
Page 15: Assistance
OR NON-DOMESTIC PREMISES. 5 Year Parts Guarantee Hotpoint also offers you a free 5 year parts guarantee. This additional guarantee is conditional on you registering your appliance with us and the parts being fitted by one of our authorised engineers. There will be a charge for our engineer’s time. -
Page 16: After Sales Service
Republic of Ireland: 0818 313 413 www.hotpointservice.co.uk Appliance Registration We want to give you additional benefits of Hotpoint ownership. To activate your free 5 year parts guarantee you must register your appliance with us. UK: 08448 24 24 24 Republic of Ireland: 01 230 0800 www.hotpointservice.co.uk...
