- Page 1 SVW909 Sip Wifi phone User Manual SVW909 1.8” Color Display Wifi Sip Phone User Manual STEPHEN TECHNOLOGIES CO.,LIMITED ALL RIGHTS RESERVED www.stephen-tele.com...
- Page 2 SVW909 Sip Wifi phone User Manual SVW909 Wifi Sip phone Hardware Overview: ----------------------------- Black Color --------------------------- Orange Color www.stephen-tele.com...
-
Page 3: Table Of Contents
SVW909 Sip Wifi phone User Manual Catalog Safety Use of the SVW909 Wifi Sip phone----------------------------------------------------------------------------------------------- 2 Start--------------------------------------------------------------------------------------------------------------------------------------------- 3 Package Contents----------------------------------------------------------------------------------------------------------------------------3 Phone Specification----------------------------------------------------------------------------------------------------------------------------3 Handset Description----------------------------------------------------------------------------------------------------------------------------4 Key Pad define and text entry---------------------------------------------------------------------------------------------------------------5 Write Text-----------------------------------------------------------------------------------------------------------------------------------------5 Fit Battery---------------------------------------------------------------------------------------------------------------------------------------5 Charge Battery----------------------------------------------------------------------------------------------------------------------------------6 Power on /off-----------------------------------------------------------------------------------------------------------------------------------6 Keypad lock------------------------------------------------------------------------------------------------------------------------------------6... -
Page 4: Safety Use Of The Svw909 Wifi Sip Phone
SVW909 Sip Wifi phone User Manual Safety Use of the SVW909 Wifi Sip phone: Read these simple guidelines. Not following them may be dangerous or illegal. Read the complete user guide for further information. SWITCH ON SAFELY Do not switch the phone on when wireless phone use is prohibited or when it may cause interference or danger. -
Page 5: Start
Color LCD 1.8”, 128*160 NOTE: The SVW909’s standby time depends on the network conditions, phone usage and surrounding area. The phone consumes more power under the following conditions: 1. Working in areas with poor wifi signals; Working outside the service coverage area;... -
Page 6: Handset Description
SVW909 Sip Wifi phone User Manual Handset Description function Left soft key Select/done Right soft key Back/clear/exit Answer key Answer/dial End key Reject/end/back/power on/power off Up/increase Down Down/decrease Left Before/decrease Right Next/increase Same to the left soft key Number key 1 Number 1 and symbols in common use“．”“－”“？”“＠”“１”... -
Page 7: Key Pad Define And Text Entry
The number keys are not labeled with all the letters you can input. You may need to refer to the selected language to check the letters that can be input with a key. The SVW909 Sip Wifi phone support English and Simplified Chinese INPUT. -
Page 8: Charge Battery
SVW909 Sip Wifi phone User Manual Charge Battery 1. Connect the usb line to the usb interface of PC, or connect the usb line to the Power charger, and process the circuit. After this operation, the charging status will be shown on the screen of the phone. It’s recommended that you pull out the charger when making a call. -
Page 9: Wlan And Voip Setting
Password/Text: WIFI ( or Hex key: 1016A386E) Example 2 --- Sip Account Configuration: SIP server（domain）: 51.108.26.31 (or maybe in the form of : sip.stephen-tele.com) User name (SIP phone number):123456 SIP phone number: 123456 (phone number could be the same to user name, depends on your server. ) - Page 10 But if your server doesn’t support STUN, you can find some open STUN resource through the internet, and configure it to the handset. 2. The default port of the SVW909 is 5060, If you want to change it, you can add a”: “ after your sip server address, and add the port number after the “:”...
-
Page 11: Dial/Answer Call
SVW909 Sip Wifi phone User Manual NOTE: Voice mail is NOT available with this edition Dial/Answer Call 1. Enter the integrity number, or you can search the number from the phonebook; 2. Press the Answer key to call the number, you can press the side keys or right/left key to set the volume of the speaker and mic 3. -
Page 12: Play
SVW909 Sip Wifi phone User Manual You can press # to switch the input method. Dial Select Menu>Call >Dial, you can enter the number you want and call it then. Recent Calls Select Menu>Call>Recent calls, The phone stores up 10 recent Missed/Received/Dialed/ phone numbers. And it stores up approximate talking time of all call. -
Page 13: Setting
SVW909 Sip Wifi phone User Manual Select Menu>Utilities>Stop Watch, press right soft key to activate the stop watch and start to time. Calculator Select Menu>Utilities>Calculator, Press keys 0 to 9 to insert digits and # to insert a decimal point. Press * to select algorithm, and right soft key to get result. -
Page 14: Status Summary
SVW909 Sip Wifi phone User Manual Select Menu>Setting> Upgrade Server Address, enter the updated server address in the blank, when you start to upgrade, the system will connect automatically. Firmware Upgrade Select Menu>Setting> Firmware Upgrade, the system will check for the new files and updates automatically. -
Page 15: Copyright Notice
Stephen Technologies Co.,Limited. Disclaimer Notice No license is granted, implied or otherwise, under any patent or patent rights of Stephen Technologies Co.,Limited. Stephen Technologies Co.,Limited, makes no warranties, implied or otherwise, in regard to this document and to the products described in this document.
