- Page 1 SVW900 Wifi SIP Phone User Guide SVW900 Wifi SIP Phone User Manual All Rights Reserved Stephen Technologies Co.,Limited www.stephen-tele.com...
-
Page 2: Table Of Contents
SVW900 Wifi SIP Phone User Guide Content For your safety--------------------------------------------------------------------------------------------- 2 Start---------------------------------------------------------------------------------------------------------- 3 Package Contents-----------------------------------------------------------------------------------3 Phone Specification--------------------------------------------------------------------------------3 Handset Description--------------------------------------------------------------------------------4 Key Pad define and text entry---------------------------------------------------------------------5 Write Text--------------------------------------------------------------------------------------------5 Fit Battery--------------------------------------------------------------------------------------------5 Charge Battery--------------------------------------------------------------------------------------6 Power on /off----------------------------------------------------------------------------------------6 Keypad lock-----------------------------------------------------------------------------------------6 WLAN and VOIP Setting------------------------------------------------------------------------- 7... -
Page 3: For Your Safety
SVW900 Wifi SIP Phone User Guide For your safety Read these simple guidelines. Not following them may be dangerous or illegal. Read the complete user guide for further information. SWITCH ON SAFELY Do not switch the phone on when wireless phone use is prohibited or when it may cause interference or danger. -
Page 4: Start
SVW900 Wifi SIP Phone User Guide Start Package Contents Wifi phone Battery USB line Adapter Quick guide Phone Specification Dimension 90x 40x 15 mm Weight Battery Rechargeable battery, 3.7V, 550mAh Adapter Input AC 100-220V / output DC 5V 500mA Protocol SIP v2 ¨RFC3261/STUN ˆRTP... -
Page 5: Handset Description
SVW900 Wifi SIP Phone User Guide Handset Description 5-direction key Up\down\left\right\middle for OK Right soft key Menu \select\OK Left soft key Phonebook\back\cancel\delete End key End a call\Power on or power off \back to the standby mode Answer key Dial\answer Number key... -
Page 6: Key Pad Define And Text Entry
SVW900 Wifi SIP Phone User Guide Key Pad define and text entry Write Text Press the number keys 1 to 9 continuously until the right character appear. The number keys are not labeled all the letters that they can input. Letters that can be input refer to the language you select. -
Page 7: Charge Battery
SVW900 Wifi SIP Phone User Guide Charge Battery 1 Link the usb line to the usb interface of PC, or link the usb line to the adapter, then link the adapter to the voltage of 220V for charging. 2 After that, the battery indication will start to roll while charging; when the phone finish charge, the indication will stop rolling, please pull out the adapter to use. -
Page 8: Keypad Lock
SVW900 Wifi SIP Phone User Guide Searching WLAN Standby mode Power off Press the End key for 2 seconds, the phone start to respond and power off. Keypad lock Active: at standby mode, press * key first, and then # key... - Page 9 SVW900 Wifi SIP Phone User Guide A: Search Available WLAN 1 At standby mode, press the right soft key or OK key to enter the main menu. 2 Select 4 setting> 2 WLAN setting > 2 WLAN search, press right soft key or OK key to start WLAN searching.
-
Page 10: Dial/Answer Call
SVW900 Wifi SIP Phone User Guide Wifi phone number setting You should get SIP phone number (SIP user name) , password and SIP server domain from operator first. Select 3 VOIP setting> change> VOIP identify> SIP number, press right soft key or OK key , input SIP phone number, press right soft key or OK key and enter the VOIP change menu again. -
Page 11: Menu Function
SVW900 Wifi SIP Phone User Guide Menu Function You can press right soft key to enter the main menu at standby mode, then choose the function you want. Press left key “back” you will back to the higher level menu. Press the End key you will back to the standby mode. -
Page 12: Play
SVW900 Wifi SIP Phone User Guide Dail Select Menu>Call >Dial, you can enter the number you want and call it then. Recent Calls Select Menu>Call>Recent calls, The phone logs 10 phone numbers each of missed, received, and dialed calls; the approximate duration of all calls. - Page 13 SVW900 Wifi SIP Phone User Guide Alert/Ring Select Menu>Setting>Phone setting> Alert/Ring, you can select special ring, or s set the phone to vibrate when you receive a call Screen/Keys Select Menu>Setting>Phone setting> Screen/Keys, you can set contrast, backlight, key repeat, key click volume here.
-
Page 14: Status Summary
SVW900 Wifi SIP Phone User Guide Remote Access Select Menu>Setting> Remote Access, you can enable or disable the remote access. Status Summary This handset provide user shortcut to look over the settings , there will be a detail list after you setup your phone. - Page 15 Stephen Technologies Co.,Limited. Disclaimer Notice: No license is granted, implied or otherwise, under any patent or patent rights of Stephen Technologies Co.,Limited. Stephen Technologies Co.,Limited, makes no warranties, implied or otherwise, in regard to this document and to the products described in this document. The information provided by this document is believed to be accurate and reliable to the publication date of this document.
