Summary of Contents for Magnavox MDVDVCR5

  • Page 1 � � MDVDVCR5...

  • Page 2: Important Safeguards

    Congratulations on the purchase of your • Do not block and of the ventilation openings. Magnavox DVD and VCR player. It is hoped that Ensure that vents are not covered by you have a lot of enjoyment from your player.
  • Page 3 Compulsory Warning Caution If the supply cord is damaged it must be replaced • Do not open - do not attempt to repair, by the manufacturer or its service agent or a disassemble or modify this appliance. similarly qualifi ed person in order to avoid a hazard.

  • Page 4: Laser Safety

    Warning To prevent fi re or shock hazard, do not expose this appliance to rain or moisture. The apparatus should not be exposed to dripping or splashing and that no objects fi lled with liquids, such as vases, shall be placed on the apparatus.

  • Page 5: Read Carefully Before Using

    Advantages of This • The audio soundtrack can be heard in up to 8 languages and depends on the disc. (The Product Are..number of audio languages depends on the software.) • DVD, VCD, CD, CD-R(MP3), CD-RW, VHS • Multi Subtitle function (DVD) playback function •...
  • Page 6 • In case you don’t use the unit for a long time, Tape and Disc Handling the unit may not function properly in the future. Turn on and use the player Do not use any tape and disc as below. Damage occasionally.

  • Page 7: Identification Of Controls

    Identification of Controls Main body (front panel) 1. Standby/On button 10. Remote sensor Press to turn the VCR on or off. This receiver receives a signal from your remote control. NOTE: The Standby/On button is no function During OTR and Record mode. function During OTR and Record mode.
  • Page 8 Operation Display Window 1. VCR Operation 7. Disc In Operation 2. Child (Lock) 8. DVD Disc Operation 3. TIMER REC display 9. Dolby Sound Indicator • TIMER Recording, • To be Timer-recorded, 10. dts Sound indicator In Timer record state - will fl ash on/off indicating ‘No tape’...

  • Page 9: Rear Panel

    Rear Panel 1. DVD 5.1 CH Audio Out 2. Audio Out (R/L) 3. Video/Audio RCA IN/OUT (AV) 4. TV Antenna In 5. DVD Digital Audio Out(Optical) 6. DVD S-Video Out 7. DVD Component Video Out (Green / Blue / Red) Engineering note: Please check correct color on sockets.

  • Page 10: Remote Control

    Remote Control Remote 1. Display Button 2. Open/close Button (DVD) Eject (VCR) 3. +10 Button 4. SP/LP Button 5. Enter Button 6. Set up Button 7. Stop Button 8. Fast Backward Button 9. Fast Forward Button 10. PBC Button 11. Return Button 12.

  • Page 11: Setting Up Your Player

    Instructions in Using Remote Connecting Your TV Through Antenna • Operate REMOTE within 5m from the unit. • Before you start, unplug all the equipment from the mains supply. • Do not press 2 (two) buttons at the same time. Option 2 •...

  • Page 12: How To Connect Your Player To A Camcorder

    Setting Up Your Player How to Connect Your Player to a Camcorder Connecting your player through extra equipment (satellite system) • Before you start, unplug all the equipment from the mains supply. • Before you start, unplug all the equipment from the mains supply.

  • Page 13: How To Connect

    AV RCA Connecting How to connect The product has the AV input, shown in the dia- gram below, you can connect other equipment. When connecting other equipment please refer to their manuals for further information. Recording from Other Equipment Simple recording can be performed, ensure the equipment is turned on and is displaying the correct channel.

  • Page 14: Auto Setting

    Auto Setting 1. Press the [ ] buttons to select the desired country on the setup manu. And press the [ENTER] button to confi rm the selected (Only on the fi rst time setup off the factory) country. Then VCR will auto-search and setup all your channels automatically.

  • Page 15: Setup Operation

    Setup Operation (4) The [ENTER] button is pressed to confi rm the new clock, the Main SETUP will appear after storing the changed data in VCR. And the 1. Display Color [SETUP] button is pressed to interrupt before confi rming the changed data and the main All lines have gray background and selected line SETUP will appear without the data change.
  • Page 16 SETUP CLOCK SET Clock set Record timer Installation Time --:-- Search Preferences Date -- / -- / - - - - ----------> ENTER: Confirm SETUP: SETUP: CLOCK SET CLOCK SET Time 11:-- Time 11:11 --------> ----------> Date -- / -- / - - - - Date -- / -- / - - - - SETUP:...

  • Page 17: Record Timer

    Record Timer • DAILY(MON-FRI) [In the case of selecting the type to “DAILY(MON-FRI)”] 1. Recording Programming All the procedures of daily (Mon-Fri) recording are the same as “once timer recording”. 1-1.MENU OPERATIONS • DAILY(MON-SAT) [In the case of selecting the (1) Press the [SETUP] button to call the Setup type to “DAILY(MON-SAT)”] Menu in TV state.
  • Page 18 * ONCE TIMER 1 TIMER 1 TIMER 1 Starttime --:-- Starttime 12:-- Starttime 11:11 Endtime 12:12 Endtime --:-- Endtime --:-- Startdate 11/11(Wed) Startdate 11/11(Wed) Startdate 11/11(Wed) --> --> --> Howoften Once Howoften Once Howoften Once Tapespeed Tapespeed Tapespeed SETUP: SETUP: SETUP: TIMER 1 Starttime...
  • Page 19 TIMER 1 TIMER 1 Starttime 12:20 Starttime 12:20 Endtime --:-- Endtime 14:-- Startdate 11/11(Wed) Startdate 11/11(Wed) --> --> Howoften Once Howoften Once Tapespeed Tapespeed SETUP: SETUP: TIMER 1 TIMER 1 TIMER 1 Starttime 12:20 Starttime 12:20 Starttime 12:20 Endtime 14:20 Endtime 14:20 Endtime...
  • Page 20 2. Timer Review (Erasure & Correction) (3) The [ ] buttons are pressed to correct the record timer program, the OSD screen 2-1.Erasure will be changed to the screen of (3). (1) Press the [SETUP] button to call the SETUP (4) How to correct: See the NEW menu in TV state or press the [PROGRAM] PROGRAMMING procedures.
  • Page 21 SETUP SETUP Clock set Clock set -> Record timer Record timer (1) GO TO “Clock set” Installation Installation Search Search ---> Preferences Preferences -> (2) GO TO “Installation” ENTER: Confirm SETUP: ENTER: Confirm SETUP: ENTER Start Date TIMER 2 14:10 16:00 19/11 10:00...

  • Page 22: Installation

    Installation This function is for you tune your TV to fi nd the VCR channel. 1. Auto Installation 1. Test Signal Generation Mode (1) Press the [SETUP] button to display the Setup (1) If you use the TV Aerial RF input for the VCR. Menu screen in TV mode.
  • Page 23 • Auto search -The user can either launch the auto search using right and left keys, or directly enter the channel number. Auto search SETUP moves automatically from last cable to fi rst Clock set Record timer antenna channel found and vice versa. Installation Search •...
  • Page 24 ENTER: Confirm SETUP: 3-3. Swap With PR (1) Press the [SETUP] button to call the Setup Menu in TV mode. Name ---- Press the [ ] buttons to select the line of Swap with PR “Installation” an press the [ENTER] button Delete program.
  • Page 25 4. RF Output Set SETUP Clock set In case, your VCR RF output interface the TV Record timer channel output, your need to change the RF Installation setup as per following steps. Search Preferences (1) Press the [SETUP] button to call the Setup Menu in TV mode.
  • Page 26 Preferences 1. OSD On/Off. (OSD - On Screen SETUP Display) Clock set Record timer Installation The OSD On/Off control is set to “ON” mode Search before shipping and it can be changed to Preferences “OFF” mode. (1) Press the [SETUP] button to call the Main SETUP screen.

  • Page 27: Searching A Cassette Tape For Programs (Indexing)

    2. Index + SETUP Searching a cassette tape for programs Clock set (indexing) Record timer Installation Search When you record a programs, the VCR places an Preferences index mark at the start of the recording. To search for an index mark: (1) Press the [SETUP] button to call the Main ENTER: Confirm...
  • Page 28 3. Index- SETUP (1) Press the [SETUP] button to call the Main Clock set SETUP screen in [cassette-in] state. Record timer Installation Search Press the [ ] buttons to select the line of Preferences “Search” and press the [ENTER] button to confi...
  • Page 29 4. VISS (2) The index marks are automatically recorded (VHS Index Search System) on the tape at the recording start time. It is impossible to record and erase the index Remarks : Subtitle after the point 4 diagrams. marks at any time. (1) Under the following conditions, VISS can be (3) Press the [INDEX+/-] buttons, the VCR will executed.

  • Page 30: Picture Adjustment

    Special Playback/ 3-2.review Picture Search (1) During playback mode, press the [REW] button once, VCR will search the picture backward: SP (x3), LP (x5). 1. Variable Slow (2) Press the [REW] button again, the tape will (1) During playback mode, press the [SLOW] advance more rapidly.
  • Page 31 (2) In special playback mode, tracking data is obtained in slow mode. 2. V-LOCK Control In still mode, press the [ ] buttons to adjust V-LOCK. But, the optimal V-LOCK position, which has no picture movement in still mode, can be recognized by TV screen only because there is no display for this operation.
  • Page 32 Front Display (Array) The Other Operations Synopsis 1. Child Lock 1. TAPE running mode In power-off state, if press the [STANDBY/ON] button for 5 seconds sequentially, the VCR will The tape running displays (PLAY, FF, REW, ..) switch to power-on state, and then will go to the appear.

  • Page 33: Vcr Playback

    VCR Playback • Place the desired DVD dis c on DVD tray, press [VCR/DVD] button to DVD mode and press [PLAY] button. Then, you can watch 1. Press [ ] button to power on. DVD. Press [VCR] button of remote control to change To Copy From DVD To Videotape into VCR mode.

  • Page 34: One-Touch Timer Recording (Otr)

    One Touch Timer Recording (OTR) When your urgent business happens suddenly in watching TV or you want to record the current TV program for the desired time, follow the procedures below. 1. First, follow the steps 1 to 4 in “Recording With VCR”.
  • Page 35 About VCR Erasure Protection Video cassettes are equipped with a safety tab Video Head Cleaning to prevent accidental erasure. When the tab is removed, recording can not be performed. The video heads enable the VCR to read video information pictures from the tape during To Prevent Accidental Erasure playback.

  • Page 36: Dvd Player Operation

    What Is Dew Condensation Symptom? 3. The Disc will be played automatically. • If it is a DVD disc, it will show the Menu/ If a VCR is moved from a cool place to a warm Title Page on the screen. and damp place or a place facing a direct cool wind from air-conditioner...and others, •...
  • Page 37 DVD Player Operation Set Menu Items: . . General Setup Page . . Press the SETUP Button on the remote controller. The following menu will be shown: TV Display Angle Mark 1. GENERAL SETUP OSD Lang Captions TV DISPLAY Screen Saver Go To General Setup Page •...
  • Page 38 Screen Saver - GENERAL SETUP PAGE- Start the screen saver, the screen saver image TV Display PS appears when the player stops or the image is Angle Mark On frozen for a few minutes. This saver can keep the screen from being damaged. OSD Lang ENG Captions On •...

  • Page 39: Video Setup

    Rear Speaker - SPEAKER SETUP PAGE- User can setup the rear speakers. The option Downmix is available when DOWNMIX is off. Front Speaker Center Speaker SML • LARGE Large Rear Speaker • SMALL Small Subwoofer • Setup Rear Surround Speaker They are for 5.1 Channel speaker output only.
  • Page 40 Component User can set the S-Video or YUV video output. . . Video Setup Page . . S-Video Component S-Video TV Mode Quality Component TV Mode In YUV video mode, user can selete Interlace or Progressive scan mode. . . Video Setup Page . . Component S-Video TV Mode P-SCAN...

  • Page 41: Preference Setup

    4. Preference Setup - Preference Page - (Under in DVD Stop mode) . . Preference Page . . TV Type Audio Subtitle Disc Menu Parental Password Default Go To Preference Page - Preference Page - TV Type TV Type The DVD palyer supports PAL, Multi and NTSC system TV type Audio Multi...
  • Page 42 Disc Menu - Preference Page- If a language listed below is record on the disc, TV Type you can set the Menu to be displayed in such language. If not, the language recorded will be Audio used. English Subtitle • English French Disc Menu ENG German...
  • Page 43 Default DVD Root menu User can load the original factory setting by The DVD Menu Play function is only applicable choose RESET and press ENTER. for DVD movie. User can access the casting information, Production History, Movie • RESET Introduction etc. directly through this function. 6.
  • Page 44 PREV./NEXT ( Subtitle During playback, press one of the PREV./NEXT This function is only applicable for DVD disc. It buttons (PREVIOUS button and NEXT button) can change the subtitle language shown on the screen. • When the PREV. button is pressed once, the pickup returns to the beginning of the Note : Number of subtitle available PREVIOUS playing chapter or track.
  • Page 45 Display (Remain Time) This function is applicable for DVD only. It will display the timing information of the playback on the screen. • For DVD playback, subsequent key press on the DISPLAY Button will show the Title Elapsed Time, Title Remain Time, Chapter Elapse Time and Chapter Remain Time one by one.
  • Page 46 Program Mode Program : TT(- -)/CH (- -) This function is applicable for DVD and CD audio. User can assign the playback sequence according to his/her preference. For CD audio, user can assign the track sequence while for DVD disc, user can assign both the Title and Exit NEXT Chapter sequence.
  • Page 47 Operations MP3 Operation This unit can support ISO9660 fi le system During Slide Show Mode: CD-ROM navigation. Multi-Media fi les such as MP3 thus can be played in the player. • Press the PAUSE Button will freeze the screen so that the current picture can be held for a long time.

  • Page 48: Before Doubting About Troubles (Dvd)

    Before Doubting About Troubles (DVD) Symptom Checks The recorder does not • If a DVD is from overseas, it may not be played. Please play. check a DVD’s region code whether it has the relative region code. • Please check whether a DVD is inserted in a right direction. •...
  • Page 49 Symptom Checks “Power On” does not work. • Please check whether a powre plug is inserted in an electric outlet. It does not work even in “Power • Please check whether a videotape is inserted in. On”. • Try to insert a plug again. A videotape is not inputted in.
  • Page 50 Symptom Symptom Checks While recording and playing, • Since VCR Play signals are not stable like a TV signals, the top of screen extremely screen may be unstable or curved while in playing. To fi x waves. the problem, please horizontal adjustment. A screen is not clear.

  • Page 51: Specifications

    Specifications Power 240V~50Hz Consumed electricity Weight 5.7kg Dimension (WxHxD) 430mm x 91mm x 355.5mm Operative temperature +5°C~40°C Installation condition Horizontal/Relative humidity under 80% Signal type PAL B/G COLOR Antenna Input/output U/V-mixed:75Ω unbalanced VIDEO input 1.0 Vp-p (unbalanced, RCA JACK) AUDIO input RCA JACK UHF output 21~69 CH...

  • Page 52: Warranty Conditions

    Your Purchase Receipt/Invoice is proof of date of purchase. You must be able to present it at The original purchaser of this Magnavox product the place of purchase to obtain a replacement or is provided with the following warranty subject to service under warranty.
