Jensen Groove 310 Instructions

Congratulations in purchasing one of JENSEN's finest Speaker Systems to date.
Read this manual carefully to ensure your system will provide you with many

Voltage and fuse.

fuse. Fuse compartment is located at power lead input area on amplifier.
Room Placement – Subwoofer:
wall or better still, across a corner. Do not block or obstruct front Port hole as this Port needs to
"breath" efficiently and provide maximum "acoustic coupling" into your room i.e. more Bass.
Room Placement – Mini speakers:
to Wall mount with 78mm screw spacing or simply sit on tabletop.
Room Placement – Centre speaker:
at the ends and you will notice one "C" curve is
longer than the other. This allows you to mount
Your Centre Speaker 3 separate ways:
1. Tabletop – aiming forward:
Peel away adhesive tape on the
25mm Rubber Blocks (supplied)
and by sitting bracket on it will result
in Speaker to aim forward, conversely, by not
using Rubber blocks Speaker will aim upwards.
2. Wall mount – aiming downward:
wall mounting bracket horizontally and with long
"C curve" at Top will allow Speaker to aim downwards.
Screws supplied and screw spacing is 124.0 mm.
3. Wall mount –aiming forward:
mounting bracket horizontally and with short "C curve"
at Top will allow Speaker to aim level and forward.
Screws supplied and screw spacing is 124.0 mm.
Groove 310
6 pce Home Theatre Speaker System.
years of musical enjoyment.
Your Subwoofer has been factory set to 220/240 volts using 1.0 amp
Best positioning for your Subwoofer is against a
With the 4 x Short Brackets you can choose
With this 1 x Long Bracket, look closely
By
By wall
