XS708E IG 28Nov2012.fm Page 1 Wednesday, November 28, 2012 6:51 PM
Installation Guide
ProSafe Plus
10GBASE-T Switch 8-Port 10Gbps XS708E
Step 1. Connect equipment
Computer
XS708E
8T
10G 1G
8F
Step 2. Connect power
Server
8T
10G 1G
8F
Step 3. Check status
Power LED
Left port LEDs
On
10 Gbps link
Off
Activity (blinking)
Fan LED
No link (off)
Fan failure (on)
Fan normal (off)
Right port LEDs
1 Gbps/100 Mbps link
Activity (blinking)
No link (off)
