I n s t a l l a t I o n n o t e s
Ness uNiversal traNsmitter
With
oN‑board
vibratioN
aNalyser
Part Number: 100-527
model: RR2 Ness Universal Transmitter
Features
• External input for reed switches, vibration
sensors, push buttons or any N.C. device.
• On-board adjustable vibration analyser for
Nessensor™ vibration sensors.
• On-board reed switch.
• 9V battery operation.
• Fully supervised, encrypted signals.
• Compatible with all Ness radio receivers.
• Ultra low standby current draw.
Advertisement
Table of Contents
Related Manuals for Ness RR2
Summary of Contents for Ness RR2
- Page 1 I n s t a l l a t I o n n o t e s Ness uNiversal traNsmitter Part Number: 100-527 With model: RR2 Ness Universal Transmitter oN‑board vibratioN aNalyser Features • External input for reed switches, vibration sensors, push buttons or any N.C. device.
- Page 2 Battery wireless vibration sensing. The onboard vibration analyser can be easily adjusted for sensitivity. a 9V lithium battery is supplied. Connects to the The onboard reed switch allows for standalone fixed battery terminals. door or window protection without using the The Ness Universal Transmitter will send a low external input. (The Ness 100-662 RR1 miniature battery signal when the battery voltage drops to radio reed switch can also be used for this 6 volts. Battery life will depend on the number of purpose). transmissions per day. The Ness Universal transmitter also features...
- Page 3 The on-board vibration analyser operates on the Message when the battery is first connected. External input and provides adjustable sensitivity This is used to teach the transmitter’s unique for Nessensor™ vibration sensors. code to the Ness control panel/receiver being Sensitivity is adjusted using the onboard rotary programmed. Refer to the control panel’s trimpot. Turn fully anti-clockwise for lowest programming instructions. sensitivity, fully clockwise for highest sensitivity.
- Page 4 1. alarm/restore from reed switch or external input. 2. Tamper. 3. Low battery signal (~6V). 4. Learn message (on power up). 1. Encrypted signals. RaDiO SECURiTy 2. Supervised operation. (When used with a compatible Ness Receiver) iNpUT SELECTiON LiNk internal reed or external input or both in series. accepts N.C. devices. ExTERNaL iNpUT 400mm maximum cable length to input. Cover tamper switch. TaMpER SWiTCh REED SWiTCh Miniature glass envelope, matching magnet supplied. Rotary min/max sensitivity adjustment. ViBRaTiON aDJUSTMENT RaDiO FREQUENCy 303.85Mhz 100µW TRaNSMiT pOWER COMpaTiBiLiTy all Ness radio receivers. 78(h) x 73(w) x 27(d) mm DiMENSiONS Ness RR2 UNiVERSaL TRaNSMiTTER www.nesscorporation.com installation Notes Revision 2.1 Jan 2015 National Customer Service Centre Document part number 890-324 ph: 1300 551 991 For the product 100-527 RR2 Universal customerservice@ness.com.au Transmitter 304Mhz © Ness Corporation pty Ltd aBN 28 069 984 372 Specifications may change without notice.
