TGB21xBX_UE(en).book Page 1 Friday, May 30, 2014 11:54 AM
Model shown is KX-TGB210.
Before initial use, see "Getting Started"
on page 8.
Thank you for purchasing a Panasonic product.
Please read these operating instructions before using the unit and save them for
future reference.
This unit is compatible with Caller ID. You must subscribe to the appropriate service
offered by your service provider/telephone company.

Operating Instructions

Digital Cordless Phone
KX-TGB210BX
Model No.
KX-TGB212BX
KX-TGB213BX
KX-TGB210UE
KX-TGB212UE
KX-TGB213UE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KX-TGB210BX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Panasonic KX-TGB210BX

Summary of Contents for Panasonic KX-TGB210BX

  • Page 1: Operating Instructions

    Model shown is KX-TGB210. Before initial use, see “Getting Started” on page 8. Thank you for purchasing a Panasonic product. Please read these operating instructions before using the unit and save them for future reference. This unit is compatible with Caller ID. You must subscribe to the appropriate service...

  • Page 2: Table Of Contents

    TGB21xBX_UE(en).book Page 2 Friday, May 30, 2014 11:54 AM Table of Contents Introduction Model composition....3 Accessory information ....3 Important Information For your safety.

  • Page 3: Introduction

    Quantity Accessory item/Part number KX-TGB210 KX-TGB212 KX-TGB213 AC adaptor Telephone line cord Rechargeable batteries Handset cover Charger — *1 PNLV226BX: KX-TGB210BX/KX-TGB212BX/KX-TGB213BX PNLV226E: KX-TGB210UE/KX-TGB212UE/KX-TGB213UE *2 See page 4 for replacement battery information. *3 The handset cover comes attached to the handset.
  • Page 4 TGB21xBX_UE(en).book Page 4 Friday, May 30, 2014 11:54 AM Introduction Additional/replacement accessories Please contact your nearest Panasonic dealer for sales information. Accessory item Model number Rechargeable HHR-4MY batteries Battery type: – Nickel metal hydride (Ni-MH) – 2 x AAA (R03) size for each handset...

  • Page 5: Important Information

    TGB21xBX_UE(en).book Page 5 Friday, May 30, 2014 11:54 AM Important Information L Do not allow the AC adaptor or telephone line cord to be excessively pulled, bent or For your safety placed under heavy objects. To prevent severe injury and loss of life/ Operating safeguards property, read this section carefully before using the product to ensure proper and safe...

  • Page 6: Important Safety Instructions

    Released electrolyte from the batteries is Base unit location/avoiding noise corrosive and may cause burns or injury to The base unit and other compatible Panasonic the eyes or skin. The electrolyte is toxic and units use radio waves to communicate with may be harmful if swallowed.

  • Page 7: Other Information

    0 °C – 40 °C, 20 % – 80 % relative air confidential information. To protect your humidity (dry) privacy/confidentiality, we recommend that you erase information such as phonebook *1 KX-TGB210BX/KX-TGB212BX/ or caller list entries from the memory before KX-TGB213BX you dispose of, transfer, or return the *2 KX-TGB210UE/KX-TGB212UE/ product.

  • Page 8: Getting Started

    TGB21xBX_UE(en).book Page 8 Friday, May 30, 2014 11:54 AM Getting Started ■ Charger Setting up Connections L Use only the supplied Panasonic AC Hook adaptor. To power outlet *1 PNLV226BX: KX-TGB210BX/ KX-TGB212BX/KX-TGB213BX PNLV226E: KX-TGB210UE/ KX-TGB212UE/KX-TGB213UE ■ Base unit Battery installation L USE ONLY Ni-MH batteries AAA (R03) Press plug firmly.

  • Page 9: Note When Setting Up

    L Use the supplied rechargeable batteries. batteries. For replacement, we recommend using the L The battery level may not be displayed Panasonic rechargeable batteries noted on correctly after you replace the batteries. In page 4, 6. this case, place the handset on the base...

  • Page 10: Controls

    TGB21xBX_UE(en).book Page 10 Friday, May 30, 2014 11:54 AM Getting Started ■ Control type A Navigator key Controls Navigator keys functions as follows. Symbol Meaning Handset Left Right – {^}, {V}, {3}, or {4}: Scroll through various lists and items. –...

  • Page 11: Turning The Power On/Off

    TGB21xBX_UE(en).book Page 11 Friday, May 30, 2014 11:54 AM Getting Started Note: Item Meaning L If you select a language you cannot read: Handset is on an outside call. {m} s {j/OK} s {V} 4 times s L When flashing: {j/OK} 2 times s {r}: Select your desired language.

  • Page 12: Making/Answering Calls

    TGB21xBX_UE(en).book Page 12 Friday, May 30, 2014 11:54 AM Making/Answering Calls Note: L When editing: Making calls – To erase a number, place the cursor to the right of where you want to erase the Lift the handset and dial the phone number, then press {C}.

  • Page 13: Useful Features During A Call

    TGB21xBX_UE(en).book Page 13 Friday, May 30, 2014 11:54 AM Making/Answering Calls If you subscribe to both Caller ID and Call Adjusting the handset ringer volume Waiting with Caller ID services, the 2nd caller’s information is displayed after you hear ■ While the handset is ringing for an the call waiting tone on the handset.

  • Page 14: Phonebook

    TGB21xBX_UE(en).book Page 14 Friday, May 30, 2014 11:54 AM Phonebook Edit the name if necessary (12 characters max.; page 23). s {j/OK} Handset phonebook Edit the phone number if necessary (24 digits max.; page 12). s {j/OK} The phonebook allows you to make calls 2 times without having to dial manually.
  • Page 15 TGB21xBX_UE(en).book Page 15 Friday, May 30, 2014 11:54 AM Phonebook L If you have rotary/pulse service, you need to press * before pressing {k} in step 1 to change the dialling mode temporarily to tone. When adding entries to the phonebook, we recommend adding * to the beginning of phone numbers you wish to chain dial (page 14).

  • Page 16: Programming

    TGB21xBX_UE(en).book Page 16 Friday, May 30, 2014 11:54 AM Programming Programmable settings You can customise the unit by programming the following features using the handset. Programming by scrolling through the display menus {j/OK} Press {V} or {^} to select the desired main menu. s {j/OK} Press {V} or {^} to select the desired item in sub-menu 1.
  • Page 17 TGB21xBX_UE(en).book Page 17 Friday, May 30, 2014 11:54 AM Programming Main menu Sub-menu 1 Sub-menu 2 Page – Setup Language <English> – – Contrast (Display contrast) <Contrast 04> – – Clock Disp. <On> – Auto Talk <Off> – Register HS –...

  • Page 18: Special Programming

    TGB21xBX_UE(en).book Page 18 Friday, May 30, 2014 11:54 AM Programming L We recommend selecting a different ringer tone from the one used for Special programming outside calls. {r}: “Volume” s {j/OK} Alarm {r}: Select the desired volume. s An alarm sounds at the set time (once or daily) {j/OK} for 2 minutes.

  • Page 19: Caller Id Service

    TGB21xBX_UE(en).book Page 19 Friday, May 30, 2014 11:54 AM Caller ID Service Using Caller ID service Caller list Important: Important: L This unit is Caller ID compatible. To use L Only 1 person can access the caller list at a Caller ID features, you must subscribe to a time.
  • Page 20 TGB21xBX_UE(en).book Page 20 Friday, May 30, 2014 11:54 AM Caller ID Service Erasing caller information {r}: Select the desired entry. s {j/OK} {r}: “Erase” or “Erase All” s {j/OK} {j/OK} s {m} Storing caller information to the phonebook {r}: Select the desired entry. s {j/OK} {r}: “Save TEL No.”...

  • Page 21: Voice Mail Service

    TGB21xBX_UE(en).book Page 21 Friday, May 30, 2014 11:54 AM Voice Mail Service Voice mail service Voice mail is an automatic answering service offered by your service provider/telephone company. After you subscribe to this service, your service provider/telephone company’s voice mail system answers calls for you when you are unavailable to answer the phone or when your line is busy.

  • Page 22: Intercom/Locator

    TGB21xBX_UE(en).book Page 22 Friday, May 30, 2014 11:54 AM Intercom/Locator Intercom Transferring calls, conference calls Available for: KX-TGB212/KX-TGB213 Available for: KX-TGB212/KX-TGB213 Intercom calls can be made between handsets. Outside calls can be transferred or a Note: conference call with an outside party can be L If you receive an outside call while talking made between 2 handsets.

  • Page 23: Useful Information

    TGB21xBX_UE(en).book Page 23 Friday, May 30, 2014 11:54 AM Useful Information Character entry The dial keys are used to enter characters and numbers. Each dial key has multiple characters assigned to it. The characters that can be entered depend on the character entry mode (page 23). –...
  • Page 24 TGB21xBX_UE(en).book Page 24 Friday, May 30, 2014 11:54 AM Useful Information Extended 1 character table (p) L The following are used for both uppercase and lowercase: Extended 2 character table (O) L The following are used for both uppercase and lowercase: Cyrillic character table (P)

  • Page 25: Error Messages

    TGB21xBX_UE(en).book Page 25 Friday, May 30, 2014 11:54 AM Useful Information Error messages Display message Cause/solution L The phonebook memory is full. Erase unwanted entries (page 14). Memory Full Troubleshooting If you still have difficulties after following the instructions in this section, disconnect the base unit’s AC adaptor and turn off the handset, then reconnect the base unit’s AC adaptor and turn on the handset.
  • Page 26 TGB21xBX_UE(en).book Page 26 Friday, May 30, 2014 11:54 AM Useful Information Programmable settings Problem Cause/solution The display is in a language I L Change the display language (page 11). cannot read. Battery recharge Problem Cause/solution The handset beeps and/or 8 L Battery needs charging.
  • Page 27 TGB21xBX_UE(en).book Page 27 Friday, May 30, 2014 11:54 AM Useful Information Caller ID Problem Cause/solution Caller information is not displayed. L You must subscribe to a Caller ID service. Contact your service provider/telephone company for details. L If your unit is connected to any additional telephone equipment, remove and plug the unit directly into the wall jack.
  • Page 28 TGB21xBX_UE(en).book Page 28 Friday, May 30, 2014 11:54 AM Useful Information Registering a handset to the base unit Handset: {j/OK} {r}: “Setup” s {j/OK} {r}: “Register HS” s {j/OK} Base unit: Press and hold {x} for about 5 seconds. (No registration tone) L If all registered handsets start ringing, press {x} again to stop, then repeat this step.

  • Page 29: Index

    TGB21xBX_UE(en).book Page 29 Friday, May 30, 2014 11:54 AM Index Index Alarm: 18 Answering calls: 12 Auto talk: 12 Battery: 8, 9 Caller ID service: 19 Caller list: 19 Caller list edit: 19 Call share: 13 Call waiting: 13 Call Waiting Caller ID: 13 Chain dial: 14 Character entry: 23 Conference calls: 22...
  • Page 30 TGB21xBX_UE(en).book Page 30 Friday, May 30, 2014 11:54 AM Notes...
  • Page 31 TGB21xBX_UE(en).book Page 31 Friday, May 30, 2014 11:54 AM Notes...
  • Page 32 Date of purchase (found on the bottom of the base unit) Name and address of dealer Attach your purchase receipt here. 1-62, 4-chome, Minoshima, Hakata-ku, Fukuoka 812-8531, Japan Web Site: http://www.panasonic.net/ © Panasonic System Networks Co., Ltd. 2014 PNQX6573ZA TC0614MU0...
