NETGEAR TA612V Installation Manual

I I N N S S T T A A L L L L A A T T I I O O N N G G U U I I D D E E T T A A 6 6 1 1 2 2 V V V V O O I I C C E E A A D D A A P P T T E E R R
M M I I N N I I M M U U M M S S Y Y S S T T E E M M R R E E Q Q U U I I R R E E M M E E N N T T S S
Before installing the NETGEAR TA612V Broadband Voice Adapter,
please make sure that your computer system has the following:
• Broadband Internet connection via cable or DSL modem.
Note: If you have a DSL modem that requires PPPoE, refer to the
User Manual for the TA612V.
• Home analogue telephone with a single line.
S S I I N N G G L L E E U U S S E E R R I I N N S S T T A A L L L L A A T T I I O O N N
1. Set Up The Network Connections
a. Unplug the power cable for your modem. Make sure that you
have turned your computer off and that you DO NOT plug in
the TA612V voice adapter until instructed to do so.
b. Disconnect the Ethernet cable from the back of your PC and
then plug it into the Internet Port on the TA612V.
c. Connect one end of the Ethernet cable we provide into the PC
port on the TA612V. Connect the other end of this Ethernet
cable into the Ethernet port on the computer.
d. Connect a telephone to the TA612V Phone 1 port using the
adapter provided.
e. Power on the modem. Wait about two minutes for it to start
up.
2. Then, Install The Ta612V Voice Adapter
a. Plug the power cable into the TA612V Power port, and plug the
other end into an electrical outlet. This turns on your TA612V
Broadband Voice Adapter. You do not need to unplug it when
not in use.
b. Check that the Power light on the Voice Adapter is illumi-
nated. Wait at least five minutes for the phone adapter to
start up.
12VDC, 1.2A Restore PC
Power Factory
Settings
Phone 2 Phone 1
(inactive)
There may be updates that need to be downloaded such as new
firmware or changes to your features. Do not interrupt the
registration process by unplugging the power or lifting the
receiver on your phone during the start-up process.
Interruption of the startup may result in interruption of
service.
c. The status light on the front of the TA612V will flash. Wait five
minutes before continuing.
Blink=Activity Ethernet: Green=100Mbps/Amber =10Mbps
Power Internet Phone 1
Status PC
d. If you have a DSL modem that requires PPPoE you need to set
up your PPPoE username and password in the TA612V.
Point your browser to:
http://192.168.61.1/
Log in using the username and password printed on the back of
the TA612V. After setup reboot your TA612V.
3. Set Up An Account At Sipgate
a. Power up the computer.
b. Use a Web browser to go to the sipgate Web site,
http://www.sipgate.co.uk/netgear/
Follow the instructions to set up your account. During this
process, sipgate will verify your system configuration and phone
Internet
set up.
c. Pick up your telephone handset and listen for a dial tone.
If you hear a dial tone then you have finished installation and
may begin making calls. For dialing instructions, see the Helpful
Hints on this card.
If you do not hear a dial tone, see Troubleshooting. For more
tips about troubleshooting, see the User Manual.
H H E E L L P P F F U U L L H H I I N N T T S S
• If you experience any problems concerning the sipgate service please
check out our extensive help centre at:
http://www.sipgate.co.uk/help-centre/
• To set up your voicemail e-Mail forwarding / SMS notifying service,
log into your Web account and click on Voicemail
• The LEDs for the Phone 1 and Phone 2 ports work as shown below:
Amber On: The phone is off the hook.
Amber Fast Blink: Not ready, registering to server.
Green On: Ready to use.
Phone 2
Green Blink: The phone is connected.
Off: The port is disabled or the power is off.
