LPX-250
USER'S MANUAL
Thank you very much for purchasing the LPX-250.
•
To ensure correct and safe usage with a full understanding of
this product's performance, please be sure to read through this
manual completely and store it in a safe location.
•
Unauthorized copying or transferral, in whole or in part, of this
manual is prohibited.
•
The contents of this operation manual and the specifications of
this product are subject to change without notice.
•
The operation manual and the product have been prepared and
tested as much as possible. If you find any misprint or error,
please inform us.
•
Roland DG Corp. assumes no responsibility for any direct or
indirect loss or damage which may occur through use of this
product, regardless of any failure to perform on the part of this
product.
•
Roland DG Corp. assumes no responsibility for any direct or
indirect loss or damage which may occur with respect to any
article made using this product.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Picza LPX-250 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Roland Picza LPX-250

Summary of Contents for Roland Picza LPX-250

  • Page 1 If you find any misprint or error, please inform us. • Roland DG Corp. assumes no responsibility for any direct or indirect loss or damage which may occur through use of this product, regardless of any failure to perform on the part of this product.
  • Page 2 AVIS Cet appareil numérique de la classe A respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada. ROLAND DG CORPORATION 1-6-4 Shinmiyakoda, Hamamatsu-shi, Shizuoka-ken, JAPAN 431-2103 MODEL NAME : See the MODEL given on the rating plate.
  • Page 3 To Ensure Safe Use To Ensure Safe Use Please read this document completely before operating the machine. It contains safety cautions and information essential in assuring safe operation. Observe all cautions in operation. Cautions related to the safe operation of this machine are indicated as shown below. About Notices Used for instructions intended to alert the user to the risk of death or severe injury...
  • Page 4 Roland DG Corp. dealer or service center. Do not use with any electrical power Use only with the power cord included supply that does not meet the ratings with this product.

  • Page 5: Items That May Not Be Copied

    Items That may Not Be Copied Unauthorized reproduction of a copyrighted item for any purpose other than personal use may be a violation of copyright. Roland DG Corp. will not be responsible for any violation of third-party copyright by any article made through use of this product.

  • Page 6: About The Labels Affixed To The Ac Adapter And Unit

    To Ensure Safe Use About the Labels Affixed to the AC Adapter and Unit This machine bears caution labels. These are intended to ensure the safety of the operator. They must be affixed at the appropriate locations. Do not allow them to become soiled or attempt to peel them off. Also, be sure to observe the stated cautions during use. Model name Rating label Do not use with any electrical power...

  • Page 7: Table Of Contents

    Pentium is registered trademark of Intel Corporation in the United States. IBM is trademark of International Business Machines Corporation. Other company names and product name are trademarks or registered trademarks of their respective holders. http://www.rolanddg.com/ Copyright © 2001 Roland DG Corporation...

  • Page 8: Checking The Accessories

    • Dr. PICZA3 User's Manual (PDF) • 3D Editor User's Manual (PDF) • Adobe Acrobat Reader ver. 4 program Also included are programs and documentation for MODELA series modeling machines from Roland DG Corp., but they are not for use with the LPX-250.

  • Page 9: Three Manuals For Using The Lpx-250

    3D Editor programs. These manuals are in electronic (PDF) format, and printed versions are not included. They are found on the included "Roland Software Package" CD-ROM. You can easily view them or even print them 3D Editor User's Manual out by following the steps below. You can also view the same information from the online help for (electronic-format manual) each program.

  • Page 10: Lpx-250 System Configuration

    2. Three Manuals for Using the LPX-250 3. LPX-250 System Configuration 3. LPX-250 System Configuration The LPX-250 system is made up of the 3D scanner unit, a computer running Windows (available separately), a scanning program, and a program for editing 3D data. 3D scanner unit Computer running Windows Scanning program...

  • Page 11: Names And Functions

    Part 1 Startup 4. Names and Functions Door Be sure to keep this closes during scan- Standby key ning operations. This button switches the power on and off. When on, it lights up green. It flashes when the door is open. When an error occurs, it lights up or- ange and red.

  • Page 12: Installation And Cable Connections

    4. Names and Functions 5. Installation and Cable Connections 5. Installation and Cable Connections Removing the Head Retainers and Installing Lifting and carrying are operations that must be carried out by two persons, by grasping the bottom of the machine. Failing to do so may result in injury. Be sure to remove the head retainers before use.

  • Page 13: Connect The Cable

    COM port. Use a serial cable from Roland DG Corp. sold separately (for an IBM-compatible computer, use a crossover cable such as the XY-RS-34). Straight-wired cables like those used mainly for modem connections cannot be used for operation.
  • Page 14 5. Installation and Cable Connections Back of the scanner Serial connector AC adapter jack Serial cable (crossover cable such as the XY-RS-34. Refer to Part 7 and see “3. Specifications”.) AC adapter COM2 Power cord COM1 Computer COM ports After you make the connections, secure the cables.

  • Page 15: Switching The Power On And Off And Opening And Closing The Door

    To ensure safety, an emergency stop occurs when the door is opened while scanning is in progress. Scanning cannot be resumed even after the door is closed. If the Standby key does not flash when you open the door, the safety device may have failed. If this happens, immediately stop use and contact your authorized Roland DG Corp. dealer or service center.

  • Page 16: Preparing The Programs

    6. Switching the Power On and Off and Opening and Closing the Door 7. Preparing the Programs 7. Preparing the Programs Programs Installed and Set Up Dr. PICZA3 and 3D Editor are both installed and set up. System Requirements The computer's system requirements for Dr. PICZA3 and 3D Editor are as follows. Operating system Windows 95, Windows 98, Windows Me, Windows NT 4.0, and Windows 2000 Processor...

  • Page 17: Steps For Installing And Setting Up The Programs

    1. First switch on the power to the LPX-250. 2. Next, in Windows, click the [Start] button, then click [Programs], then [Roland PICZA], then [Dr. PICZA3]. When Dr. PICZA3 starts, it attempts to verify the name of the model of the 3D scanner that is connected. Be sure to turn on the LPX-250 before you run Dr.

  • Page 18: Part 2 Basics Of The Lpx-250

    1. Scanning System Part 2 Basics of the LPX-250 1. Scanning System The LPX-250 scans objects using laser light. It emits a spot beam onto the scan object and detects reflected light from the object with sensors. It performs scanning as it rotates the scan object and moves the laser beam from bottom to top. Laser emitter Sensor Rotating table...

  • Page 19: Suitable And Unsuitable Objects For Scanning

    Part 2 Basics of the LPX-250 2. Suitable and Unsuitable Objects for Scanning The LPX-250 cannot scan every single kind of object. Adequate thought must be given to the material of an object, because it greatly affects the scanning results. Objects that do not pass light Relatively smooth-surfaced objects Clear or transparent objects...

  • Page 20: Plane Scanning

    2. Suitable and Unsuitable Objects for Scanning 3. Plane Scanning 3. Plane Scanning Features of Plane Scanning This mode uses parallel laser beams to scan while rotating the table and laser head in synchronization. Because this mode can obtain comparatively stable scanning results regardless of the shape of the object, you can use it as an all-purpose mode. You can use it to scan up to six surfaces at one time (multi-plane composition).

  • Page 21: Rotary Scanning

    Part 2 Basics of the LPX-250 In general, increasing the number of scanning surfaces results in greater scanning precision with correspondingly fewer conspicuous seams. In the example of the doll, however, only one of the five scanning surfaces can capture the voids. From the standpoint of capturing voids, two surfaces are more effective.

  • Page 22: Mounted Position Of The Object And The Scannable Area

    4. Rotary Scanning 5. Mounted Position of the Object and the Scannable Area 5. Mounted Position of the Object and the Scannable Area The scannable area may differ slightly according to the scanning mode. The area that you can actually scan is affected by the mounted position of the object.

  • Page 23: Rotary Scanning

    Part 2 Basics of the LPX-250 Rotary Scanning The basic principle is to mount the object to be scanned at the center of the table. All areas to be scanned must be at the table center. The area away from the center of the base (the shaded portion in the figure) cannot be scanned correctly. 254 mm (10 in.) Scannable area...

  • Page 24: Part 3 Basic Operation

    1. Getting Ready to Scan Part 3 Basic Operation 1. Getting Ready to Scan Selecting a Scan Object Before you start scanning, give thought to what objects are suited to scanning. Conditions for suitable scanning Remedies when unsuitable Object material and Does the objects not pass light? Consider applying a white surfacer (primer).

  • Page 25: Scanning Operation

    Part 3 Basic Operation Do not touch any internal components other than the table. Doing so may result in breakdown. Do not attempt to move the table, laser head, or any other working parts by hand. Doing so may result in breakdown. Make sure the scan object does not extend beyond the table.

  • Page 26: Viewing The Results Of Scanning

    2. Scanning Operation 3. Viewing the Results of Scanning 3. Viewing the Results of Scanning You can check the scanning results while viewing the results in various ways. Manipulating the Perspective and the Zoom Rate Click one of these buttons to enable the mode for shifting the perspective or for zooming.

  • Page 27: Saving Data

    Part 3 Basic Operation 4. Saving Data Saving in Dr. PICZA Format You can save scanning results in Dr. PICZA format. In Dr. PICZA3, go to the [File] menu and click [Save As]. In addition to Dr. PICZA3, the 3D Editor program for editing 3D data can also open files in this format. Exporting Data In addition to Dr.

  • Page 28: Part 4 Features For Better Scanning

    1. Detailed Settings for Plane Scanning Part 4 Features for Better Scanning 1. Detailed Settings for Plane Scanning In addition to the automatic scanning-condition settings, you can also make the settings manually, to any values you like. Scanning Using Manual Settings 1.

  • Page 29: Detailed Scanning Conditions

    Part 4 Features for Better Scanning Detailed Scanning Conditions (1) This sets the number of scanning surfaces. For multi-plane composition, select a number from [2] to [6]. The preview window shows the scanning surfaces. (2) This manipulates the orientation that the preview window displays. You can do things like rotating the preview or displaying a three-dimensional view.

  • Page 30: Detailed Settings For Rotary Scanning

    1. Detailed Settings for Plane Scanning 2. Detailed Settings for Rotary Scanning 2. Detailed Settings for Rotary Scanning Scanning Using Manual Settings 1. In Dr. PICZA3, click the [SCAN] button. The [Scan] dialog box appears. 2. Click the [Make Settings and Scan] button for rotary scanning. The [Settings for Scanning] dialog box appears.

  • Page 31: Detailed Scanning Conditions

    Part 4 Features for Better Scanning Detailed Scanning Conditions (1) This manipulates the orientation that the preview window displays. You can do things like rotating the preview or displaying a three-dimensional view. (2) Click this to display a preview of the object. Use this as a guide for setting the scanning area. (3) These set the circumferential and height-direction scanning pitch.

  • Page 32: Finishing Detailed Areas Using Rescanning

    2. Detailed Settings for Rotary Scanning 3. Finishing Detailed Areas Using Rescanning 3. Finishing Detailed Areas Using Rescanning After you have scanned an entire object, this feature rescans just one portion with changed conditions. Basic scanning should always be performed using the best possible conditions, of course, but by using rescan to finish detailed portions you can make the data even more highly finished.
  • Page 33 Part 4 Features for Better Scanning 4. Hold down the SPACE key and drag to position the area you want to rescan at the front. This makes the front surface the direction of laser-beam emission. As you determine the orientation, try to angle it so that the laser light can penetrate sufficiently (or so that the laser light passes through).

  • Page 34: Scanning A Specific Area In Greater Detail

    3. Finishing Detailed Areas Using Rescanning Scanning a Specific Area in Greater Detail You perform coarse scanning of the entire object using rotary scanning, then rescan just the required areas at a finer pitch. This can reduce the size of the data and also shorten the scanning times. This feature is for rescanning a portion in the rotary-scanning mode. 1.

  • Page 35: Case Studies For Better Scanning

    Part 4 Features for Better Scanning 4. Case Studies for Better Scanning Scanning Results for Objects That Are Difficult to Scan These are some examples of scans of difficult materials. (The plated object was specially scanned for experimental purposes only. Avoid highly reflective objects because of danger of eye injury.) Black marker pen Plated object...
  • Page 36 4. Case Studies for Better Scanning This example involves using the two scanning modes to scan an object that has a nearly cylindrical shape. You can use either mode for scanning, but rotary scanning achieves the shortest scanning times. The scanning pitch is equivalent for both, but rotary scanning produces smoother surfaces.

  • Page 37: The Scanning-Start Direction For Plane Scanning

    Part 4 Features for Better Scanning The Scanning-start Direction for Plane Scanning This is an example where the scanning-start direction is changed with plane scanning. It is a good idea to give thought to the direction in which cavities and voids can be most easily captured (that is, the direction in which the laser beam passes), and also to keep in mind what area of the object is most important.

  • Page 38: Object Mounting Location For Rotary Scanning

    4. Case Studies for Better Scanning Object Mounting Location for Rotary Scanning In rotary scanning, the laser light is beamed toward the center of the table. This means that when the object is uneven, the penetration of the laser light varies greatly according to the object's mounting location. This case takes this point into account and deliberately shifts the mounted position away from the center.

  • Page 39: Part 5 Editing Scanning Results - Using 3D Editor

    Part 5 Editing Scanning Results - Using 3D Editor Part 5 Editing Scanning Results -- Using 3D Editor 1. What You Can Do Using 3D Editor 3D Editor lets you do things like the following. Enlarge and reduce Deforming operations such as stretching in one direction are also possible. Move and rotate Specifying numerical values for the movement distance and angle of rotation is also possible.

  • Page 40: Importing More Than One Set Of Data

    1. What You Can Do Using 3D Editor 2. Importing and Exporting Data Importing More Than One Set of Data You can use the [Import] button to import more than one set of data and place a number of object in the 3D Editor window. You can import Dr.

  • Page 41: Basic Operations For Objects

    Part 5 Editing Scanning Results - Using 3D Editor 3. Basic Operations for Objects How to View the 3D Editor Window 3D Editor displays an object from four different perspectives at the same time. You can manipulate any one of these at any time. The important point is that you get four different views from four angles.

  • Page 42: Let's Try Editing Data With 3D Editor

    3. Basic Operations for Objects Let's Try Editing Data with 3D Editor Let's try some simple editing. We'll scan an apple with the LPX-250, then try cutting and moving it. 3D Editor starts and 1. First, do a scan of an apple. Then, in Dr. PICZA3, data is imported.
  • Page 43 Part 5 Editing Scanning Results - Using 3D Editor 5. Click the [Move Object] button, then drag the portion you se- lected to the left. The two parts separate. When you're done with the operation, right-click to quit the [Move Object] mode. [Move Object] button Drag the object you want to move.

  • Page 44: Part 6 Troubleshooting

    If operation is not as expected, try taking corrective action as described below. If that doesn't correct the problem, or if you determine that there is a breakdown, then contact your authorized Roland DG Corp. dealer or service center. Symptom...
  • Page 45 Part 6 Troubleshooting Symptom Remedy If the problem persists The message "Cannot commu- - Switch on the power to the scanner before you run Dr. PICZA3. The cable used for the connection - Make sure the correct COM port number is set in the preferences for Dr. with the computer may not be the nicate with present scanner"...

  • Page 46: Part 7 Appendix 1. Sample Data Sheet

    1. Sample Data Sheet Part 7 Appendix 1. Sample Data Sheet This is a data sheet from an actual scan. Refer to it when you are setting scanning conditions. Object Material: plaster Scanning mode Rotary scanning Scanning area Height direction 0 to 325 mm, Circumferential 0 to 360 degrees Scanning pitch Height direction 1.0 mm, Circumferential 1.0 degrees Scanning time...

  • Page 47: Table Dimensional Drawing

    Part 7 Appendix 2. Table Dimensional Drawing 9 screw holes (M6, depth 7 mm)

  • Page 48: Specifications

    35 to 80% (no condensation) included items and accessories AC adapter: 1, power cord: 1, 2.5-mm hexagonal wrench: 1, 3-mm hexagonal wrench: 1, caps: 3, Roland Software Package CD-ROM: 1, user's manual: 1, Roland Pixform™: 1 Serial connector (RS-232C) XY-RS-34/14 cable connection...
  • Page 49 Roland may change the specifications of this Software or its material without notice. Roland shall not be liable for any damage that may caused by the use of the Software or by exercise of the right licensed by this agreement.
