Model SP7015 TRX
Carlton
J. P. Carlton Company
Div. DAF Inc.
121 John Dodd Road
Spartanburg, SC 29303
Ph. (864) 578-9335
Fax (864) 578-0210
www.stumpcutters.com
Machine Serial #
Engine Model #
Engine Specification #
Engine Serial #
Purchase Date
Dealer
_____________
_____________
_____________
_____________
_____________
_____________

Advertisement

Table of Contents
loading

Summary of Contents for Carlton SP7015 TRX

  • Page 1 Model SP7015 TRX Machine Serial # _____________ Engine Model # _____________ Engine Specification # _____________ Engine Serial # _____________ Purchase Date _____________ Dealer _____________ Carlton J. P. Carlton Company Div. DAF Inc. 121 John Dodd Road Spartanburg, SC 29303 Ph. (864) 578-9335 Fax (864) 578-0210 www.stumpcutters.com...
  • Page 3 DIESEL ENGINE EXHAUST WARNING CALIFORNIA Proposition 65 Warning Diesel engine exhaust and some of its constituents are known to the State of California to cause cancer, birth defects, and other reproduction harm.
  • Page 5 SP7015 TRX SAFETY ALERT...
  • Page 7 SP7015 TRX SAFETY ALERT...
  • Page 9 SP7015 TRX SAFETY ALERT...
  • Page 11 SP7015 TRX SAFETY ALERT...
  • Page 13 STUMP GRINDER LIMITED WARRANTY J.P. Carlton Co. Inc., hereafter referred to as the “Manufacturer”, warrants each new Carlton Grinder to be free of defects in workmanship and material for a period of one year. This warranty takes effect upon delivery to the original retail purchaser. The manufacturer, at its option, will replace or repair, at a point designated by the manufacturer, any parts which appear to have been defective in material or workmanship.
  • Page 15: Important Notice

    The manufacturer will provide replacement parts at no cost to the customer for defective parts during the warranty period. Defective parts must be returned to J.P. Carlton Company. It will be the customers’ responsibility to install the replacement parts unless arrangements are made with the selling dealer.
  • Page 17 Warranty Validation Form Congratulations on your purchase of a Carlton Stump Grinder. This product has been designed and manufactured to provide years of profitable service while minimizing maintenance and downtime. Please take the time now to complete this warranty validation form. This information is necessary for Carlton to instate your warranty.
  • Page 19: Table Of Contents

    SP7015 TRX TABLE OF CONTENTS INTRODUCTION FOREWORD GENERAL INFORMATION MACHINE FEATURES MACHINE SPECIFICATIONS OPERATION SAFETY PRECAUTIONS DAILY CHECKLIST MACHINE CONTROLS TRANSPORTING MACHINE OPERATION MAINTENANCE MACHINE MAINTENANCE LUBRICATION CHART TROUBLESHOOTING GUIDE SERVICING BELTS SERVICING BEARINGS SERVICING CUTTER WHEEL SERVICING HYDRAULICS SERVICING STUB SHAFT...
  • Page 21: Foreword

    Model SP7015 TRX machine is designed for use in unique situations where size ® and maneuverability are foremost. As a result, the Model SP7015 TRX has it's own unique operational requirements. Read this manual carefully and TAKE RESPONSIBILITY for thoroughly familiarizing yourself with the controls and the concepts behind the operation of this machine before attempting to operate it.
  • Page 22: General Information

    Any reference made to right, left, front or rear in relationship to the stump cutter is illustrated in the following picture. Please refer to these any time you call your dealer or J. P. Carlton Company for parts or assistance.
  • Page 23: Machine Features

    SP7015 TRX MACHINE FEATURES • Diesel Power • Dual swing cylinders • 35” width to clear narrow • Direct drive hydraulic • Hour meter fence gates • Tracks hydraulically • Hardened bushings in pump • Hydraulic motor expand from 35” to 48”...
  • Page 24: Machine Specifications

    SP7015 TRX MACHINE SPECIFICATIONS Engine............Deutz 60 HP Turbo Diesel Weight ............4300 Lbs Length............10’ 6” Height ............57” Machine Width Track Width Retracted ......35” Track Width Extended....... 48” Track Dimension ........9 1/2” x 75” Long Controls ............. Wireless Remote...
  • Page 25 SP7015 TRX MACHINE SPECIFICATIONS...
  • Page 26: Safety Precautions

    SP7015 TRX SAFETY PRECAUTIONS Before operating the stump cutter, read this manual, the engine manual, and all the safety decals on the machine. Know all parts of the machine and their functions, especially the shut down procedures in case of emergency. No inexperienced person may operate machine.
  • Page 27 (i.e. clearing rocks, wood chips, etc.). • DO NOT modify or change any part without written approval from J. P. Carlton Company. • Do not ride, sit, stand, lay or climb anywhere on this machine during operation, while running, or during transport.
  • Page 28 SP7015 TRX SAFETY PRECAUTIONS • Never allow spectators to stand and watch machine in operation without proper hearing and eye protection and standing at a safe distance. Loud noise and flying debris may cause severe injury. • Do not operate around water, gas, power or phone lines.
  • Page 29 SAFETY PRECAUTIONS ATTENTION: ® The Carlton Model SP7015 TRX Stump Grinder CAN be overturned on steep inclines. This can cause serious injury to operator and machine. DO NOT OVERTURN! P/N 0700024 • Avoid steep side inclines when operating this machine! The narrow design width...
  • Page 30: Daily Checklist

    SP7015 TRX DAILY CHECKLIST DAILY CHECKS SHOULD BE PERFORMED BEFORE STARTING THE ENGINE FOR THE DAY. DO NOT INSERT KEY INTO ENGINE UNTIL ALL CHECKS HAVE BEEN COMPLETED. • Check engine oil at dipstick. Engine must be level. Boom in raised position will not affect the engine position;...
  • Page 31: Machine Controls

    ENGINE CONTROLS – Refer to the engine manufacturers owners’ manual for controls, operation, and service. • THE CUTTER WHEEL MUST BE DISENGAGED BEFORE STARTING THE MACHINE. • The SP7015 TRX stump grinder is a radio FLOW AND GEAR SWITCHES MUST control machine. To start the engine and BE IN LOW radio control transmitter, follow these instructions.
  • Page 32 SP7015 TRX MACHINE CONTROLS • Use the radio transmitter to operate the machine when positioning the machine at the job site and when grinding the stumps. The five operation and positioning functions operate the same on the machine as on the radio transmitter.
  • Page 33 SP7015 TRX MACHINE CONTROLS HYDRAULIC CONTROLS • A series of hydraulic controls are located on the machine and radio transmitter, which are clearly marked for use. There are five operating and positioning functions on the machine and radio transmitter. To operate...
  • Page 34 SP7015 TRX MACHINE CONTROLS The Cutter head may be moved in two directions; either up and down or side to side: CUTTER WHEEL (LIFT) (Shown as CUTTER HEAD –UP/DOWN on transmitter.) • Raises cutter head (boom) up and down. SWING ROTATION (Shown as CUTTER HEAD –RIGHT/LEFT on...
  • Page 35 SP7015 TRX MACHINE CONTROLS FLOW CONTROL • Flow control affects how fast the machine travels. High flow is for moving the machine from one place to another very quickly. Low flow is used for more precision in tight places or when positioning the cutter wheel close to the stump.
  • Page 36 SP7015 TRX MACHINE CONTROLS SAFETY • NEVER SERVICE A MACHINE WITH THE ENGINE RUNNING, SEVERE PERSONAL INJURY COULD OCCUR. TURN ENGINE OFF THEN REMOVE IGNITION KEY AND DISCONNECT POSITIVE BATTERY CABLE TO AVOID STARTING MACHINE ACCIDENTALLY. • CUTTER WHEEL MUST BE DISENGAGED BEFORE TURNING ENGINE ON/OFF AND BEFORE SERVICING A MACHINE.
  • Page 37: Troubleshooting

    FOR ANY OPERATING PROBLEMS WITH THE RADIO RECEIVER & TRANSMITTER (Included in the back of this manual) • Contact your Carlton dealer if you need assistance not the radio control manufacturer. • First check the batteries to make sure they are providing enough power to operate the transmitter.
  • Page 38: Transporting

    SP7015 TRX TRANSPORTING DO NOT TOW! THE MODEL SP7015 TRX IS DESIGNED TO BE TRANSPORTED TO THE JOB SITE AND WILL MOVE UNDER ITS OWN POWER ONCE ON SITE. Transport machine in a suitable vehicle designed for a load of these dimensions and weight.
  • Page 39 SP7015 TRX TRANSPORTING THE TRAILER MUST BE SECURELY ATTACHED TO THE TOW • VEHICLE BEFORE LOADING OR UNLOADING THE STUMP GRINDER. • DO NOT LOAD OR UNLOAD ON ANYTHING OTHER THAN LEVEL GROUND. LOADING • Start engine as recommended by the engine manufacturers manual.
  • Page 40: Machine Operation

    • THE CUTTER WHEEL MUST BE BE IN LOW DISENGAGED BEFORE STARTING THE MACHINE. • The SP7015 TRX stump grinder is a radio control machine. To start the engine and radio control transmitter, follow these instructions. • On the machine, turn the ignition key...
  • Page 41 SP7015 TRX MACHINE OPERATION • Now start the engine, turn the key switch while pressing the by-pass switch to start the machine. If the engine doesn’t start BY-PASS right away and you have to restart it, SWITCH turn the key switch OFF and back ON.
  • Page 42 SP7015 TRX MACHINE OPERATION • Cutter head swing speed should be adjusted to a rate that will allow cutter wheel to pass through stump smoothly. If jerking, bouncing or significant drops in engine speed occur, swing rate is too rapid and must be decreased.
  • Page 43 SP7015 TRX MACHINE OPERATION • Raise cutter wheel clear of stump and return to center position. • Reduce engine speed to idle. DO NOT TURN OFF MOTOR. Engine must be allowed to cool slowly at idle for 3-5 minutes to avoid damage.
  • Page 44: Machine Maintenance

    SP7015 TRX MACHINE MAINTENANCE SAFETY • NEVER SERVICE A MACHINE WITH THE ENGINE RUNNING, SEVERE PERSONAL INJURY COULD OCCUR. TURN ENGINE OFF THEN REMOVE IGNITION KEY AND DISCONNECT POSITIVE BATTERY CABLE TO AVOID STARTING MACHINE ACCIDENTALLY. • CUTTER WHEEL MUST BE DISENGAGED BEFORE TURNING ENGINE ON/OFF AND BEFORE SERVICING A MACHINE.
  • Page 45 SP7015 TRX MACHINE MAINTENANCE Clean Poly Chain belt guard weekly by • ® removing the bottom guard. Chip build-up will wear the Poly Chain belt. ® Check cutter wheel, pockets, and teeth for wear • daily. If any repair is needed, see Servicing Cutter Wheel section for further instruction.
  • Page 46 SP7015 TRX MACHINE MAINTENANCE Always clean tip of grease gun fitting and grease fitting on machine before attaching hose to prevent dirt from being forced into machine parts. • Grease the bearing supported stub shaft every 1000 hours of operation using Texaco Starplex ®...
  • Page 47: Machine Maintenance

    SP7015 TRX MACHINE MAINTENANCE Grease engine slide and engagement handle • weekly. Use Texaco Starplex II grease. ® ENGINE SLIDE (6) AND ENGAGEMENT (2) GREASE FITTINGS TRACK TENSIONING • The tracks are tensioned by adding grease to the tensioning cylinder. This is accomplished by using a standard hand operated grease gun.
  • Page 48 SP7015 TRX MACHINE MAINTENANCE WASHER 1/2” FROM PLATE • The washer shown here should have a gap of 1/2” between it and the plate when the track is tensioned properly. Apply a few pumps of grease and then check the distance between the washer and the plate shown.
  • Page 49: Lubrication Chart

    SP7015 TRX LUBRICATION CHART • The model SP7015 TRX, as well as all of • A regularly scheduled maintenance our machines, is built to be a rugged program will pay big dividends in machine performer. Your new machine is sturdy life, performance and avoided downtime.
  • Page 50: Troubleshooting Guide

    SP7015 TRX TROUBLESHOOTING GUIDE COMPLAINT CAUSE CORRECTION Engine will not start. (See Loose ground wire. Clean and tighten. • • Engine Manufacturer Manual Loose hot wire. Clean and tighten. • • for further information.) Dead battery. Recharge or replace. •...
  • Page 51 SP7015 TRX TROUBLESHOOTING GUIDE COMPLAINT CAUSE CORRECTION Roar in machine when cutter Belt guards rubbing on Re-position guards away • • wheel is engaged. jackshaft or cutter wheel from shafts. shaft. Replace bearings. • Jackshaft or cutter wheel • bearings going bad.
  • Page 52: Servicing Belts

    SP7015 TRX SERVICING BELTS Replacing Engine Belt SAFETY • NEVER SERVICE A MACHINE WITH THE ENGINE RUNNING, SEVERE PERSONAL INJURY COULD OCCUR. TURN ENGINE OFF THEN REMOVE IGNITION KEY AND DISCONNECT POSITIVE BATTERY CABLE TO AVOID STARTING MACHINE ACCIDENTALLY. • CUTTER WHEEL MUST BE DISENGAGED BEFORE TURNING ENGINE ON/OFF AND BEFORE SERVICING A MACHINE.
  • Page 53 SP7015 TRX SERVICING BELTS Replacing Engine Belt • Slide the engine back toward the cutter wheel with the engagement handle as far as it will go, then remove the belt and put on the new belt. • After replacing the belt, check it for tension.
  • Page 54 SP7015 TRX SERVICING BELTS Replacing Engine Belt • Replace and tighten the belt keepers. • Replace the v-belt guard cover and tighten bolts. • NEVER RUN MACHINE WITHOUT ALL GUARDS IN PLACE AND SECURED. GENERAL TENSIONING OF V-BELT DRIVES A few simple rules about tensioning will satisfy most of your requirements.
  • Page 55 SP7015 TRX SERVICING BELTS Replacing Poly Chain Belt ® SAFETY • NEVER SERVICE A MACHINE WITH THE ENGINE RUNNING, SEVERE PERSONAL INJURY COULD OCCUR. TURN ENGINE OFF THEN REMOVE IGNITION KEY AND DISCONNECT POSITIVE BATTERY CABLE TO AVOID STARTING MACHINE ACCIDENTALLY.
  • Page 56 SP7015 TRX SERVICING BELTS REAR JAM BOLT FRONT JAM BOLT Replacing Poly Chain Belt ® • Loosen the front jam bolts on the underside of the boom box and move the cutter wheel toward the engine as far as possible. This will loosen the Poly Chain belt.
  • Page 57 SP7015 TRX SERVICING BELTS Replacing Poly Chain Belt ®...
  • Page 58: Servicing Bearings

    SP7015 TRX SERVICING BEARINGS SAFETY • NEVER SERVICE A MACHINE WITH THE ENGINE RUNNING, SEVERE PERSONAL INJURY COULD OCCUR. TURN ENGINE OFF THEN REMOVE IGNITION KEY AND DISCONNECT POSITIVE BATTERY CABLE TO AVOID STARTING MACHINE ACCIDENTALLY. • CUTTER WHEEL MUST BE DISENGAGED BEFORE TURNING ENGINE ON/OFF AND BEFORE SERVICING A MACHINE.
  • Page 59 SP7015 TRX SERVICING BEARINGS SERVICING PIVOT TABLE BEARING While turntable bearings require almost no attention, what little they are given will pay big dividends in long life, high performance, and trouble free service. Lubricate the bearing every 100 operating hours for relatively slow rotating applications.
  • Page 60: Servicing Cutter Wheel

    • PLACE THE CUTTER WHEEL ON THE GROUND WHEN PERFORMING SERVICE ON A MACHINE. • There are thirty-two (32) teeth to a complete set on the model SP7015 TRX. Two (2) straight teeth, fifteen (15) left 45° teeth and fifteen (15) right 45° teeth.
  • Page 61 SP7015 TRX SERVICING CUTTER WHEEL TOOTH ARRANGEMENT • Inspect pockets, teeth, and bolts for damage • Use anti-seize on threads to prevent bolts and replace as required. from “freezing up” in cutter wheel pockets. • When replacing pockets, always replace •...
  • Page 62 Dura Disk II cutter wheel, there are fifty (50) teeth to a complete set. There are ten (10) Short Plow Bolt Bits (Carlton part #0450121) and forty (40) Plow Bolt Bits (Carlton part #0450120). • DO NOT OPERATE A MACHINE...
  • Page 63 SP7015 TRX SERVICING CUTTER WHEEL TOOTH ARRANGEMENT • • Inspect pockets, teeth and bolts for damage and Outside pocket teeth are Short Plow Bolt Bits. replace as required. These pockets are angled and welded in place. • You can switch teeth from one outside pocket...
  • Page 64 SP7015 TRX SERVICING CUTTER WHEEL TOOTH SHARPENING Begin by chamfering shank back past edge of carbide. You do this because if it is not back far enough the shank will hit the stump instead of the carbide, thus causing a lot of vibration. Once the shank is angled far enough back, then begin sharpening carbide.
  • Page 65 • PLACE THE CUTTER WHEEL ON THE GROUND WHEN PERFORMING SERVICE ON A MACHINE. • There are thirty-two (32) teeth to a complete set on the model SP7015 TRX. Two (2) straight teeth, fifteen (15) left 45° teeth and fifteen (15) right 45° teeth.
  • Page 66 SP7015 TRX SERVICING CUTTER WHEEL TOOTH ARRANGEMENT • Inspect pockets, teeth, and bolts for damage • Use anti-seize on threads to prevent bolts and replace as required. from “freezing up” in cutter wheel pockets. • When replacing pockets, always replace •...
  • Page 67 Dura Disk II cutter wheel, there are fifty (50) teeth to a complete set. There are ten (10) Short Plow Bolt Bits (Carlton part #0450121) and forty (40) Plow Bolt Bits (Carlton part #0450120). • DO NOT OPERATE A MACHINE...
  • Page 68 SP7015 TRX SERVICING CUTTER WHEEL TOOTH ARRANGEMENT • • Inspect pockets, teeth and bolts for damage and Outside pocket teeth are Short Plow Bolt Bits. replace as required. These pockets are angled and welded in place. • You can switch teeth from one outside pocket...
  • Page 69 SP7015 TRX SERVICING CUTTER WHEEL TOOTH SHARPENING Begin by chamfering shank back past edge of carbide. You do this because if it is not back far enough the shank will hit the stump instead of the carbide, thus causing a lot of vibration. Once the shank is angled far enough back, then begin sharpening carbide.
  • Page 70: Servicing Hydraulics

    SP7015 TRX SERVICING HYDRAULICS SAFETY • NEVER SERVICE A MACHINE WITH THE ENGINE RUNNING, SEVERE PERSONAL INJURY COULD OCCUR. TURN ENGINE OFF THEN REMOVE IGNITION KEY AND DISCONNECT POSITIVE BATTERY CABLE TO AVOID STARTING MACHINE ACCIDENTALLY. • CUTTER WHEEL MUST BE DISENGAGED BEFORE TURNING ENGINE ON/OFF AND BEFORE SERVICING A MACHINE.
  • Page 71 SP7015 TRX SERVICING HYDRAULICS • Replace hydraulic filter every three to four months of normal use. More often if used under severe conditions. Use a 10-micron filter, available at most locations. • Unscrew old filter and discard properly. Clean filter housing and install new...
  • Page 72 SP7015 TRX SERVICING HYDRAULICS REPLACING HYDRAULIC PUMP • Engine must be shut off. • Remove key & disconnect battery cable. • Make sure that hydraulic oil is cool and that pressure is relieved from the lines. • Disconnect hydraulic lines from pump and cap them, mark which line goes where to reconnect correctly.
  • Page 73: Servicing Stub Shaft

    SP7015 TRX SERVICING STUB SHAFT SAFETY • NEVER SERVICE A MACHINE WITH THE ENGINE RUNNING, SEVERE PERSONAL INJURY COULD OCCUR. TURN ENGINE OFF THEN REMOVE IGNITION KEY AND DISCONNECT POSITIVE BATTERY CABLE TO AVOID STARTING MACHINE ACCIDENTALLY. • CUTTER WHEEL MUST BE DISENGAGED BEFORE TURNING ENGINE ON/OFF AND BEFORE SERVICING A MACHINE.
  • Page 74: Servicing Stub Shaft

    SP7015 TRX SERVICING STUB SHAFT • Next you will need to remove the REMOVE jackshaft sheave. Remove the bolts in BOLTS AND SCREW INTO the jackshaft sheave and screw them EXTRA HOLES back into the empty threaded holes to push the sheave off the bushing and remove the bushing and sheave.
  • Page 75 SP7015 TRX SERVICING STUB SHAFT • You can now remove the bearing supported stub shaft plate. Remove the bolts holding the shaft plate to the engine. There are eleven 10MM bolts to remove. Pull the plate straight off. • There are two threaded holes that can be used to push the shaft plate off the engine mount.
  • Page 76 SP7015 TRX SERVICING STUB SHAFT • Replace any parts found defective or worn. Put stub shaft coupling plate onto the flywheel. The plate is attached using eight 10MM-1.5 x 20MM bolts with a lock washer. Put LocTite 242 (blue) ®...
  • Page 77 SP7015 TRX SERVICING STUB SHAFT • Bolt grease fitting to the air filter bracket. • Before starting the engine, apply grease to the grease fitting until the pin on the opposite side of the stub shaft pops out. This must be done daily to protect the bearing in the stub shaft assembly.
  • Page 78: Machine Wiring

    SP7015 TRX MACHINE WIRING RADIO CONTROL MACHINE DIAGRAM SEE RADIO CONTROL MANUAL, INCLUDED IN THIS MANUAL, FOR MORE INFORMATION.
  • Page 79: Turntable Assembly

    SP7015 TRX TURNTABLE ASSEMBLY ITEM NO PART NO DESCRIPTION 0500125 Turntable Bearing 5/8”-18 x 2 1/2” SHCS 5/8”-18 x 2 1/8” SHCS 0150156 5/8”-11 x 2 1/2” SHCS 0300105C Hydraulic Cylinder - 3x4 0300105Q Cylinder Pin - Captured 0150801 Hardened Bushing - 1”...
  • Page 80: Engine Slide Assembly

    SP7015 TRX ENGINE SLIDE ASSEMBLY ITEM NO PART NO DESCRIPTION 02001051 Engine - 60 HP Deutz Turbo Diesel 5/8”-11 x 4” HHCS 0150407 5/8” Lock Washer 4404113 Engine Slide Frame 4404110 Engine Slide Rod 0150104 3/8”-16 x 2 1/2” HH Bolt 0150207 3/8”-16 Lock Nut...
  • Page 81 SP7015 TRX ENGINE SLIDE ASSEMBLY...
  • Page 82: Engine Belt Assembly

    SP7015 TRX ENGINE BELT ASSEMBLY ITEM NO PART NO DESCRIPTION 0400131 Engine Belt - 4B105 0250105 Sheave - 4B5.4 0250179 Bushing - SD 1 1/2” 0250104 Sheave - 4B12.4 0250122 Bushing - SK 1 11/16” A160T013 Key - 3/8” Sq. x 1 7/8”...
  • Page 83 SP7015 TRX ENGINE BELT ASSEMBLY NOTE: Make sure the grease fitting is on top of the stub shaft assembly before bolting the stub shaft plate into place, as illustrated in the Servicing Stub Shaft Section of the manual. Remove the grease...
  • Page 84: Jack Shaft Assembly

    SP7015 TRX JACKSHAFT ASSEMBLY ITEM NO PART NO DESCRIPTION 4404185A Jackshaft – 1 11/16” 0500144 Outer Bearing – 1 11/16” 0500145 Inner Bearing – 2 15/16” 5/8”-11 x 3 1/2” SHCS 0150216 5/8”-11 Lock Nut ⎯ Key – 3/8” Square x 3 5/8”...
  • Page 85 SP7015 TRX POLY CHAIN ® ASSEMBLY ITEM NO PART NO DESCRIPTION 3504196 Poly Chain Guard ® 3/8”-16 X 1 1/2" Carriage Bolt 0150303 3/8” Flat Washer 0150207 3/8”-16 Lock Nut 0250115G 2517 Taper Lock bushing – 1 11/16” 0250115B Sprocket – 14M-29S-68T – Jackshaft 0250115M 3020 Taper Lock Bushing –...
  • Page 86: Cutter Wheel Assembly

    SP7015 TRX CUTTER WHEEL ASSEMBLY ITEM NO PART NO DESCRIPTION 0450101 Tooth - Straight 0450102 Tooth - Right 45° 0450103 Tooth - Left 45° 0450109 5/8”-18 x 2 1/8” Tooth Bolt 0450104 Smart Pocket - C/S 0450105 Smart Pocket - Threaded...
  • Page 87 SP7015 TRX CUTTER WHEEL ASSEMBLY...
  • Page 88: Chip Guard Assembly

    SP7015 TRX CHIP GUARD ASSEMBLY ITEM NO PART NO DESCRIPTION 44TR151 Chip Deck – Right Hand 44TR152 Chip Deck – Left Hand 4404172 Boom Chip Guard Bracket 0150117 3/8”-16 x 1” Carriage Bolt 0150303 3/8” Flat Washer 0150207 3/8”-16 Lock Nut 3/8”-16 x 1 1/4”...
  • Page 89: Track Assembly

    SP7015 TRX TRACK ASSEMBLY TRACK ASSEMBLY WITH EXPANSION ITEM NO PART NO DESCRIPTION 0400244B1 PIN,CLEVIS-PINS 0400244B2 PIN,CYLINDER-CYL.ENDS 0400244B3 PIN,CYLINDER-ROD ENDS 0400244B CYLINDER,HYDRAULIC BOLT,M16_50 PLATE,COVER (fnl dr.) 0400244A TRACK GROUP 42 LINKS W 230 WIDTH WASHER (16) (c.roller) 0400244C ROLLER, CARRIER (BO1) VALVE,PROPORTIONING SCREW BUTTON HD(1/4"-20 UNC)(SHEILDS) 52...
  • Page 90 SP7015 TRX TRACK ASSEMBLY TRACK ASSEMBLY WITH EXPANSION...
  • Page 91 SP7015 TRX TRACK ASSEMBLY LARGE IDLER ASSEMBLY – 0400244F ITEM NO PART NO DESCRIPTION BOLT, M12X60 0400244F2 BRACKET, LARGE IDLER WASHER, M12 0400244F1 IDLER, LARGE 0400244F3 BRACKET, CENTER, LARGE IDLER...
  • Page 92 SP7015 TRX TRACK ASSEMBLY SPRING ADJUST ASSEMBLY- 0400244E ITEM NO PART NO DESCRIPTION 0400244E1 BRACKET,SPRING 0400244E2 SPRING 0400244E3 WELDMENT,SPRING BRACKET 0400244E4 ROD,SPRING...
  • Page 93 Behind Tow- 7500 Deutz Turbo Diesel 24" 46" 92" arc 31" 1.5" 60" 4,400 Behind Call and ask about Carlton’s line of Chippers or visit our website: www.stumpcutters.com CARLTON—QUALITY PRODUCTS AND EXCEPTIONAL SERVICE Carlton Owner’s Manual SP7015 TRX Revised: 11/2007...
