Summary of Contents for migear Xtracamwifird
- Page 1 ...
-
Page 2: Table Of Contents
CON TEN TS PAGE Contents Page 2 Introduction 3 Safety Instructions 3 Important Safety Precautions 4 Product Specification 5 Contents 6 Getting to know your Camera 7 Using the Action Camera 9 Action Camera Operation 13 WIFI Mode 20 Connecting to PC 26 Using the Remote Control 27 Using the Mounting Accessories 28 Troubleshooting 31 ... -
Page 3: Introduction
IN TRODUCTION Congratulations on the purchase of your new Action Camera. This manual contains important safety and operating information. Please read all the information carefully before you use the device to avoid accidents and keep it for future reference. Follow these important safety and operation instructions. SAFETY IN STRUCTIONS •... - Page 4 • Press the buttons gently. Pressing too hard can damage the product. • Do not use the camera in an extremely dry environment. • Do not put the camera in high temperature places (over 40ºC), especially not in a car with the windows closed in summer. • Do not subject the camera to harsh impacts. Do not drop the unit to avoid damage. • Do not attempt to dismantle or repair this camera yourself. Qualified personnel should perform repairs. • Disconnect the camera from the power source before cleaning. • Use a dry soft cloth to clean this camera. ...
-
Page 5: Important Safety Precautions
electric shock, do not remove the cover. No user‐serviceable parts inside. Refer servicing to qualified personnel. • The USB cord for the device should be unplugged from the computer when the unit is left unused for a long period of time. • Do not subject the product to harsh impacts. Do not drop ... -
Page 6: Product Specification
Attention: We have done our best to produce a complete and accurate manual. However, we cannot ensure that there are no errors or omissions during the printing process. PRODUCT SPECIFICA TION • 5MP CMOS sensor • WIFI Module for wireless streaming to Smartphone • Free App available from Google Play or iTunes • Video Resolution: 1080P (1920x1080,30 fps), 720P (1280x720,30 fps), 720P (1280x720,60 fps) • Still Image Resolution: 12MP, 5MP • Wide angle lens • File Format JPEG, H.264 • LCD Status Display screen • Expandable Micro SD Slot up to 32GB • High‐speed USB 2.0 interface • Built‐in 3.7V rechargeable lithium battery ... -
Page 7: Contents
• Operation Temperature: ‐10°C to 40°C • Storage Temperature: 15°C to 30°C • Works with Windows 8, 7, Vista and XP, Mac 10.2 and above NOTE: As a result of continual improvements, the design and specifications of the product within may differ slightly from the unit illustrated on the packaging. CON TEN TS Please make sure that the items shown below are included in the package. Should an item be missing, please contact the local retailer from which you purchased this product Action Camera 1 piece Waterproof Case 1 piece Rechargeable Battery ... -
Page 8: Getting To Know Your Camera
Remote Control 1 piece Mounting Adaptor for GoPro Accessories 1 piece USB Cable 1 piece 10. User Manual 1 piece GETTIN G TO KN OW YOUR CAMERA DEVI CE OVERVIEW ... -
Page 9: Ir Sensor
1 Shutter button 2 Microphone 3 LCD Display 4 Lens 5 Wifi Button 6 Power/Mode Button 7 IR Sensor 8 Micro USB Port 9 HDMI Port 10 Micro SD Slot ... -
Page 10: Using The Action Camera
External Microphone Battery Cover release 11 12 Jack switch 13 LED Indicator light USIN G THE ACTION CA MERA BATTERY INSTALLATI ON Please install the lithium battery correctly as shown in the following graphic. ... - Page 11 1. Push the battery cover switch to the open position ), and remove the cover as shown in figure 1. 2. Put the lithium battery into the battery slot. Make sure the contacts of the battery are corresponding to the symbols of the camera ( ). As shown in figure 2 and figure 3. 3. Install the battery cover back in place, and lock the switch to the lock position( )to ...
-
Page 12: Battery Operation
BATTERY OPERATI ON 1. Make sure the action camera is turned off. 2. To charge the internal battery, connect the action camera with the USB cable provided to a computer. 3. The charging indicator will light up blue when charging. 4. The battery will become fully charged after 3‐4 hours. 5. Once fully charged the charging indictor will disappear. 6. Approximate battery life depending on the situation is: 1080P 30fps with WIFI 50 minutes 1080P 30fps 110 minutes 720P 60fps with WIFI 55 minutes 720P 60fps 120 minutes ... - Page 13 INSERTING MICRO SD CARD This action camera does not have internal memory. A Micro SD (TF) card (Class 10) and above must be inserted for this action camera to operate and record. 1. Turn off the action camera 2. Find the Micro SD card slot, and then insert the Micro SD card. As per below image ...
-
Page 14: Action Camera Operation
ACTION CA MERA OPERA TION START‐UP/SHUTDOWN Press and hold the power button for 5 seconds, the screen will display “ON” and beep. To Turn the action camera off Press and hold the power button for 5 seconds, the screen will display “OFF” and beep. ... - Page 15 NOTE: The action camera has a power saving setting and will automatically turn itself off after 5mins of inactivity to save power. DISPLAY SCREEN The action camera will be set to video mode in its default settings. When the camera is turned on it would display the below Video mode The DV is in video recording icon mode. Video Full HD: 1080p@30fps resolution ...
- Page 16 Recording Stands for 0 hour and 00 time minute. Micro SD Display when a micro SD card is card icon inserted, otherwise no display. Battery level Battery is full The camera is in Mute mode, no Beep will be heard when pressing the buttons. It displays only when Mute mode is Mute icon activated. To turn on/off the mute function press and hold the Shutter button until the icon appears. ...
- Page 17 Wi‐Fi icon Displays when activated. MODES The action camera provides different shooting modes. Press the power button repeatedly; the following modes will be displayed on the screen: ...
- Page 18 HI stands for Full HD (1920x1080,30 fps) video Lo stands for 720P Video (1280x720,30 fps) video HILO stands for 720P (1280x720,60 fps) video HI stands for 12MP resolution Photo Lo stands for 5MP resolution Continuous Supports taking 3/5/10 photos shot continuously (only via App) In self‐timer mode , you can set Self‐timer 0s, 2s or 10s (only via App) ...
- Page 19 VI DEO RECORDING MODE To record a video, please check whether the action camera is in video mode. If the icon is not displayed on the screen, press the power button repeatedly until it appears and select your desired resolution. 1. To start recording press and release the shutter button, the icon and [:] displayed in LCD will flash. At the same time the red indicator will flash too. Note: the LCD only displays minutes and hours. 2. To stop recording press and release the shutter button, the icon and [:] displayed in LCD will stop flashing. At ...
-
Page 20: Photo Mode
the same time the red indicator will stop flashing. Note: When the Micro SD card is full, or the battery runs out, the recording will stop automatically, and the recorded video will be saved before the action camera turns itself off. PHOTO MODE To take a photo, please check whether the action camera is in photo mode. If the icon is not displayed on the screen, press the power button repeatedly until it appears and select either Hi or Lo resolutions. Press and release the shutter button, a beep will be heard and the red indicator will flash, meaning a photo has been taken. Note: If you take photos more than 999 photos, the LCD screen ... -
Page 21: Wifi Mode
will only keep displaying 999. WIFI MODE The action camera comes with wifi function so you can wirelessly stream your video to your Smartphone or control your action camera by your phone. Firstly download the The free APP “SYMAGIX” can be downloaded from the iTunes store or Google Play store. 1. After the App has been downloaded and installed. Insert Micro SD card into the action camera. ... - Page 22 2. To turn the WiFi on and press the Wi‐Fi button to active WiFi. 3. Search for EXTREME_WIFI in your WiFi list on your mobile and connect using password: 1234567890, the indicator will flash and when the WiFi network is connected, the indicator will remain on. The WiFi icon will be displayed on the LCD screen. (In order to save power, the WiFi will be automatically turn off if it cannot be connected after 60 seconds) 5. Once connected successfully , open the SYMAGIX App. ...
- Page 23 6. You can control the action camera with the App to take photos, videos change different settings and even steam files from files on your MicroSD card onto your phone. ...
-
Page 24: Connecting To Hdtv
CONNECTI NG TO HDTV The action camera can be connected to a HDTV via a Mini HDMI cable (not supplied). Note: Before connecting or removing the HDMI cable, please stop video recording, playback and disconnect Wi‐Fi. 1. Connect the action camera to a TV via a Mini HDMI cable (not supplied). ... - Page 25 2. Turn on the TV and the action camera, and then set the TV to HDMI mode. 3. When HDTV is connected, the action camera will enter Playback mode, the LCD will look like the below: Icon Description S/N 1 Playback mode Under Playback mode currently There are 31 files and you are 2 File number viewing the 19 3 Video icon The file is a video ...
- Page 26 4. Press the Power button to switch between photos and videos. 5. To select a photo or video press the Wi‐Fi button 6. When a video file is selected, press the Shutter button to play it, and press the Shutter button again to stop playing. 7. To delete or format a file press and hold the Shutter button, the below will appear on your HDTV. ...
-
Page 27: Connecting To Pc
8. Press the Wi‐Fi button to switch between deleting or formatting modes. 9. Then Press the Power button to select Yes or No, and press the Shutter button to confirm and exit. CONN ECTING TO PC Turn on the action camera and connect it to the USB port of the PC via the supplied USB cable. The action camera will enter U‐disk mode and the LCD will display as below after connection: Now you can view the photos or videos taken by action camera on the PC/Mac. ... -
Page 28: Using The Remote Control
Note: when watching the videos on your computer please ensure you are using the latest version of your media player. USIN G THE REMOTE CON TROL You can use the remote control to record videos, take photos and turn off the action camera. When using the remote control aim the signal to the IR Sensor of the front of the action camera, and press the video button, photo button or power off button. ... -
Page 29: Using The Mounting Accessories
USIN G THE MOUNTING A CCESSORIES The bike and helmet mounts can be attached to either the action camera directly or waterproof case (with the camera inside) To use the bike mount first loosen the screws and place the mount on the bike. After tightening the mount screw, secure the camera on the mount with camera or the waterproof case attached to it. To use the helmet mount first install the helmet strap onto the mount and bond it on the helmet tightly. Then secure the camera on top of the mount. ... - Page 30 Supplied with the action camera is a Mounting Adaptor for GoPro Accessories, to use this adaptor connect to the action camera or the underwater case via the tripod Socket. Then the Mount can be used with any GoPro Accessory which can be bought from the local retailer. The GoPro Accessory will attach to the bottom of the mount and held in place by a screw. WATERPROOF CASE CARI NG INSTRUCTI ONS Before sealing the waterproof case, keep the camera housing’s rubber seal clean, a single hair or grain of sand can cause a leak. ...
- Page 31 You can test by closing the case without inserting the camera. Submerse the case completely in water for about a minute. Remove the case from the water, dry off its exterior with a towel, then open the case. If the entire interior is dry, the case is safe for use under water After every use in salt water you will need to rinse the outside of the housing with non‐salt water and dry. Not doing this can eventually cause corrosion of the hinge pin and salt buildup in the seal, which can cause failure. To clean the seal, rinse in fresh water and shake dry (drying with a cloth may cause lint to compromise the seal). Re‐install the seal into the grooves in the backdoor of the housing. ...
-
Page 32: Troubleshooting
TROUBLESHOOTING Problem Solution I cannot upload Check all cable connections are images to the PC secured. Set the camera to MSDC mode. I press the shutter Wait for data process to button but no complete and then take your response. next image. Or Delete some images in SD/MMC card, if the memory is full. The product does Press the reset button with a pin, not respond and then turn on the product again. The video files are Please ensure you have ... - Page 33 very slow and bad downloaded the latest version of resolutions when your media player, or try such playing on my programs as VLC media player, computer Windows media, Quicktime. Cannot connect to Check to make sure you have mobile App connected to the Action Camera’s wifi. Or reset the camera and connect the wifi again following the steps. If you have any questions regarding this product please contact us on the below Phone or Email: • 1800 224 814 • support@migear.biz ...
