Summary of Contents for Swann MWABCAM150514T
- Page 1 Super Wide-Angle Security Camera INSTRUCTION MANUAL MWABCAM150514T...
-
Page 2: About The Camera
About the Camera Congratulations on your purchase of this PRO-CAM camera from Swann! You’ve chosen well: we think this is one of the finest CCTV video cameras available. The PRO-CAM is great for monitoring a wide open space whilst maintaining a high level of detail, even at night - it can see up to 30m/100ft in the dark. -
Page 3: Mounting And Installing
Mounting and Installing The camera mounts onto a flat, vertical surface using screws. The surface must have sufficient strength to hold the camera. Materials such as hardwood, brick or masonry are good options, and we’ve included all the gear you’ll need to mount it there (except the tools - sorry, you’ll still need your own drill). -
Page 4: Connection Guide
Connection Guide Connect the camera’s DC and BNC cables to the extension cable, twist the BNC connector to lock it together securely. (Optional) If you intend to use the OSD controller, connect the camera’s green RS485 plug to the extension cable. You may first need to attach the RS485 plug to the wires on the cables as shown in the diagram above. -
Page 5: Troubleshooting
The OSD controls are many and varied so if you would like to make some changes or have a particular need for your camera that requires some fine tuning, simply read the OSD guide included in your pack or you can download the guide to the OSD from our website: www.swann.com/osdpro... -
Page 6: Helpdesk / Technical Support Details
Any unit which proves defective during the stated period will be repaired without charge for parts or labour or replaced at the sole discretion of Swann. The end user is responsible for all freight charges incurred to send the product to Swann’s repair centres. - Page 7 Cámara de seguridad con gran angulo MANUAL DE INSTRUCCIONES...
- Page 8 Acerca de la cámara ¡Felicitaciones por su compra de esta PRO-CAM de Swann! Ha elegido bien: creemos que es una de las mejores cámaras de video de CCTV disponibles. La cámara PRO-CAM es ideal para supervisar un amplio espacio abierto y a la vez mantener un alto nivel de detalle, incluso por la noche: se puede ver hasta 30 m / 100 pies en la oscuridad.
-
Page 9: Instalación De La Cámara
Instalación de la cámara La cámara se monta sobre una superficie plana y vertical usando tornillos. La superficie debe ser lo suficientemente fuerte como para sostener la cámara. Materiales tales como madera dura, ladrillos o mampostería son buenas opciones y hemos incluido los elementos que necesitará... -
Page 10: Guía De Conexión
Guía de Conexión Conecte los cables DC y BNC de la cámara al cable de extensión. (Opcional) Si intenta utilizar el controlador OSD, conecte el enchufe verde RS485 al cable de extensión. Podría necesitar acoplar primero el enchufe RS485 a los alambres en los cables como se muestra en el siguiente diagrama. -
Page 11: Solución De Problemas
La cámara trabajará perfectamente bien si nunca acopla el controlador OSD - regulará todas sus funciones automáticamente. Los controles OSD son muchos y variados, y simplemente no hay espacio suficiente en este manual para cubrirlos. Puede descargar una guíadetallada de nuestro sitio web: www.swann.com/osdpro 11 11 11... - Page 12 El usuario final asume los costos de fletes incurrido para enviar el producto a los centros de reparación de Swann. El usuario final se responsabiliza de los costos de envío en que incurran cuando envía desde y hacia cualquier país distinto al país de origen.
- Page 13 Caméra de sécurité à angle super large MANUEL D’UTILISATION...
- Page 14 À propos de la caméra Félicitations pour votre achat de cette caméra PRO-CAM de Swann! Vous avez fait un bon choix : nous croyons que c’est une des meilleures caméras vidéo CCTV sur le marché. La PRO-CAM est parfaite pour surveiller un espace large ouvert, tout en maintenant un niveau élevé...
-
Page 15: Installation De La Caméra
Installation de la caméra La caméra s’ajuste sur une surface plate et verticale en utilisant des vis. La surface doit être suffisamment solide pour tenir la caméra. Des matériaux comme du bois franc, de la brique ou de la maçonnerie sont de bonnes options, et nous avons inclus tout l’équipement que vous aurez besoin pour la monter sur ces matériaux (sauf les outils –... -
Page 16: Guide De Connexion
Guide de Connexion Connectez les câbles CC et BNC de la caméra au câble de prolongement. (Facultatif) Si vous prévoyez utiliser le contrôleur OSD, connectez la prise verte RS485 de la caméra au câble de prolongement, Vous pouvez d'abord attacher la prise RS485 aux fils des câbles tel qu'indiqué... -
Page 17: Dépannage
OSD - il règlera tous les règlages automatiquement. Il y a plusieurs différents contrôles OSD, et il n'y a simplement pas assez d'espace dans ce manuel pour tout couvrir. Vous pouvez télécharger un guide complet pour l'OSD à partir de notre site Web: www.swann.com/osdpro 17 17 17... - Page 18 à la discrétion de Swann. L’utilisateur final est responsable de tous les frais de port qu’implique l’envoi du produit au centre de réparation de Swann. L’utilisateur est responsable de tous les frais de port si l’envoi doit être effectué en provenance ou à destination de tout pays hors du pays d’origine.
- Page 19 On-Screen Display (OSD) Instruction Manual Welcome! Lets get started.
- Page 20 Introduction So - you have bought one (or more!) of Swann’s range of Pro Series cameras, browsed through the On-Screen Display (OSD), noticed lots of confusing settings, and don’t quite understand what they all do. This manual will help you navigate through the OSD and explain the OSD settings in detail.
- Page 21 Getting to know the OSD Controller Arrow Buttons Quick save Use to navigate through the OSD and adjust settings. Display the OSD Main Menu/ Enter function...
- Page 22 Connecting the OSD Controller If this is your first time connecting the OSD Controller, follow the instructions below to connect it to your camera. 1. Insert the RS485 plug coming from the camera into the RS485 Port (1). 2. Connect a free end of the supplied power splitter to the DC IN 12V Port (2).
-
Page 23: Navigating The Osd
Navigating the OSD • Press to display the Main Menu of the MAIN MENU OSD on your screen. IMAGE • Press to choose a selection in DAY&NIGHT AUTO the menu list. ZONE MASKING MOTION DET • Press to toggle between options VIDEO LANGUAGE ENGLISH... - Page 24 The OSD Settings • IMAGE • 3D-NR (3D Noise Reduction): Lets you IMAGE turn the camera’s 3D filtering system on 3D-NR to assist in obtaining low-noise images IR IS for recordings done at night or in dim AE MODE BACK LIGHT conditions.
- Page 25 • AE (Automatic Exposure) Mode: Lets you choose from several AE modes that will allow the camera to evaluate the amount of light coming through IMAGE its image sensor and deliver optimal exposure to the objects in the scene by 3D-NR automatically setting the appropriate I RI S...
- Page 26 • Image Enhance: Lets you manually adjust the IMAGE levels of sharpness, contrast and saturation in 3D-NR the displayed image. IR IS • Sharpness: The clarity of detail and edges AE MODE BACK LIGHT AWB - PRO in the image. Setting the sharpness too high IMAGE ENHANCE will make the image look pixelated.
- Page 27 • Mirror: Lets you horizontally reverse the orientation of the image. • Flip: Lets you turn the image upside down. This is useful if you have your IMAGE camera mounted upside down on a ceiling and do not want to rotate it 3D-NR physically.
- Page 28 • DAY & NIGHT Lets you choose how the camera handles colour and manages the transition from daytime to nighttime and vice-versa • Auto: Lets you set the camera to MAIN MENU switch automatically from day to night mode. IMAGE •...
- Page 29 • ZONE MASKING Lets you create and place a “privacy mask” MAIN MENU to conceal parts of the image on the screen. This restricts what can be seen - useful IMAGE DAY&NIGHT AUTO when you want to protect personal privacy ZONE MASKING or sensitve areas.
-
Page 30: Motion Detection
• MOTION DETECTION Lets you can enable motion detection MAIN MENU on the camera. Note that, if you’re using a Swann DVR with motion detection IMAGE DAY&NIGHT AUTO enabled, then there’s no need to arm it on ZONE MASKING the camera as well. -
Page 31: Video Standard
• VIDEO STANDARD MAIN MENU Lets you set the appropriate video IMAGE DAY&NIGHT AUTO standard for your television. ZONE MASKING MOTION DET VIDEO For example, NTSC (used in USA, LANGUAGE ENGLISH Japan, Canada) or PAL (used in UK and LOAD DEFAULT SOFT VERSION 20140101 Australia). -
Page 32: Load Default
• LOAD DEFAULT MAIN MENU If the changes made to the OSD settings IMAGE have made the image look worse that AUTO DAY&NIGHT it originally was or you have moved the ZONE MASKING MOTION DET camera somewhere else and want to re- VIDEO tune the camera, simply reset all OSD LANGUAGE... - Page 33 LANGUAGE ENGLISH to control certain camera features such LOAD DEFAULT as the OSD and PTZ when the camera’s SOFT VERSION 20140101 RS485 RS485 plug is connected to a Swann DVR. SAVE&EXIT RS485 CAM ID PROTOCOL PELCO - D BAUDRATE 9600...
-
Page 34: Troubleshooting
Problem: I misplaced the OSD Controller. Is there any other way to operate the OSD? Solution: Your Swann DVR has a PTZ port with a green plug attached which can be connected with the Red and Black connectors. For information on how to control the OSD on the DVR,... -
Page 35: Need Help
Need Help? Swann Technical Support All Countries E-mail: tech@swann.com Telephone Helpdesk USA Toll Free 1-800-627-2799 USA Parts & Warranty 1-800-627-2799 (Option 1) (M-F, 9am-5pm US PT) AUSTRALIA 1300 138 324 NEW ZEALAND Toll Free 0800 479 266 0203 027 0979... - Page 36 M800OSD150514E | © Swann Communications 2014...
