- Page 1 Instruction Manual Models: LPE3510 (13”) LPE6510 (25”) For safe operation be sure to read through this instruction manual before operating your Laminator. ID Card System, Laminating Machines & Film FUJIPLA, Inc. TOKYO, JAPAN...
-
Page 2: Table Of Contents
CONTENTS PAGE Warning before using your Lamipacker Safety Precautions Names Functions Film Setting Warming Up Operation Finish Lamination Cleaning Rollers Laminating Film Specifications Warranty... -
Page 3: Warning Before Using Your Lamipacker
Thank you for your purchase of the Fujipla LPE3510 or LPE6510 laminator. This laminating machine is designed to laminate most common paper stocks, inks and toners with transparent lamination film. Laminated objects are waterproof and durable as well as having a lustrous appearance. Please note that, once laminated, it is difficult to peel off the film from the laminated object without damage to it. -
Page 4: Safety Precautions
Laminating film: • While genuine FUJIPLA "CP Roll" is recommended any quality 1.5 or 3 mil laminating film may be used. Contact your dealer. Laminating objects: Lamination is made by heat and pressure. Inappropriate operation may cause failure in quality of lamination or in jamming of film. -
Page 5: Film Setting
2. FILM SETTING: Insert Mandrel into the film roll (Upper & lower). Be sure the direction of hooks is in the reverse direction of the film rotation (fig. A). Set the film roll and Mandrel on the machine (Upper & lower). *Be sure the adhesive side of the film is facing you, not the Heat Chamber (fig. -
Page 6: Warming Up
3. WARMING UP: Set Operation Lever to LAMINATE position. Turn on Power Switch. POWER lamp (red) will glow. • LAMINATE: Rollers will be closed. • OPEN: Rollers will be opened. Set temperature according to the object to be laminated: Machine LPE 3510 (13”) LPE 6510 (25”) Item to be laminated... -
Page 7: Operation
4. OPERATION: Level the rear tray to the operation position. Overlap upper and lower film in the front of Heat Shoe. Set the Operation Lever up to “OPEN”. Position a Film Setting Board between the Heat Rollers together with films. Set Operation Lever down to “LAMINATE”. -
Page 8: Finish Of Lamination
4. OPERATION (cont’d): Creases or wrinkles may appear in the film as it exits the rear of the machine. Observe the film at the face of the Heat Chambers. There may be the occurrence of creases or “waterfall” of the film along the chambers. They should disappear shortly. -
Page 9: Cleaning Of Rollers
Chambers. The lubricate will also increase the effective life of the chambers. See your dealer or contact Dry-Lam for this part. 7. LAMINATING FILM It is recommended to use Fujipla, Dry-Lam, or other quality films. See your dealer. -
Page 10: Specifications
8. SPECIFICATIONS: MODEL LPE3510 LPE6510 Maximum Laminating Width 13" 25" Laminating Film Thickness 1.5mil or 3.0mil Laminating Speed 4ft./min 3ft./min Temperature 194°F-305°F (adjustable) Power Source AC120 V 60Hz Current 6.7A 11.7A Current Power 800W 1400W Carton Dimension (W x L x 21.7"x15.4"x15. -
Page 11: Warranty
Any visual changes in cosmetic parts caused by normal use. • Any charges for shipping and shipping damage. • This warranty does not cover articles that cannot be laminated satisfactorily. *To inquire about maintenance or to order laminating film, please contact your FUJIPLA dealer or Dry-Lam. (end)
