- Page 2 Thank You for purchasing this ASAP product! Operation The ASAP DR401 is a 4-port device designed to operate with the phone company's Distinctive Ring service, allowing connection of up to 4 separate telecommunication devices to a single telephone line. The phone company's Distinctive Ring service (DRS) is offered in most areas across the U.S.
- Page 3 The ASAP DR401 can be used in virtually any application. Listed below are a few of the most common applications using the ASAP DR401: Children's Rooms Offices, breakrooms, & lobbies Roommates Credit authorization terminals Phone, fax, computer Departments in a retail Multiple offices environment Security systems...
- Page 4 INSTALLATION (on a single telephone line) Connect the incoming telephone line to the TEL LINE port. Plug the small end of the AC power cord into the power input port labeled "12 VAC" on the back of the DR401. Plug the AC adapter into a standard 120-volt outlet. (Only use a 12VAC, 0.4 - 1.0A, Class 2 power source with the DR401.) Connect telephone devices to the ports labeled P1, P2, P3...
- Page 5 In this installation, phones not connected to the ASAP DR401 will ring on every call regardless of the call destination. For installation/operation without interference, see "Installation at the DEMARC." INSTALLATION (on a typical phone system)
- Page 6 Installation at the DEMARC The following diagram shows an installation at the point of DEMARC on line 1. Once connected in this configuration, the telephones will not ring on an inbound call unless the ASAP DR401 transfers a call to a designated port.
- Page 8 Three year limited warranty/Service information WARRANTOR: Command Communications, Inc. ELEMENTS OF WARRANTY: Command Communications, Inc. warrants, for the duration of this warranty, the ASAP DR 401 (hereafter referred to as the "Product") to be free from defects in materials and craftsmanship with only the limitations or exclusions set out below.
- Page 9 NOTE: Any unit returned without an RMA # clearly marked on the exterior package will be refused and returned at the sender's expense. Command Communications, Inc. cannot be held responsible for any loss or damage in transit. Please retain proof of purchases to establish date of original purchase.
- Page 10 If this product is purchased outside the U.S. from an authorized Command Communications' dealer, it should be returned for repair at the location where it was purchased, as provisions have been established to handle warranty repair outside the U.S.
-
Page 11: Registration Information
Registration information REGISTRATION INFORMATION This equipment complies with Part 68 of the FCC rules and the requirements adopted by the ACTA. On the bottom of this equipment is a label that contains, among other information, a product identifier in the format US:AAAEQ##TXXXX. If requested, this number must be provided to the telephone company. - Page 12 If trouble is experienced with the ASAP DR 401, for repair or warranty information, please contact Command Communications at 888-843-4399. If the equipment is causing harm to the telephone network, the telephone company may request that you disconnect the equipment until the problem is resolved.
- Page 13 If your home has specially wired alarm equipment connected to the telephone line, ensure the installation of the ASAP DR 401 does not disable your alarm equipment. If you have questions about what will disable alarm equipment, consult your telephone company or a qualified installer.
- Page 14 Consult the dealer or an experienced radio/TV technician for help. CAUTION: Changes or modifications not expressly approved by the manufacturer could void the user's authority to operate the ASAP DR 401. Industry Canada Information "Notice: The Industry Canada label identifies certified equipment. This certification means that the equipment meets telecommunication network protective, operation and safety requirements as prescribed in the appropriate Terminal Equipment Technical Requirements...
- Page 15 Users should ensure for their own protection that the electrical ground connections of the power utility, telephone lines and internal metallic water pipe system, if present, are connected together. This precaution may be particularly important in rural areas. Caution: Users should not attempt to make such connections themselves, but should contact the appropriate electric inspection authority, or electrician, as appropriate."...
- Page 16 Customer Service 888-843-4399 (for U.S. and Canada) Monday through Friday 8:00am - 5:00pm Mountain Time. © 2005 Command Communications, Inc. All rights reserved. Printed in U.S. COMMAND COMMUNICATIONS, the Arrow logo, and ASAP are registered trademarks of Command Communications, Inc., Centennial, CO 80112 AC022105kr...
