12 pg_W-204_EFS
7/25/05
Owner's Manual
Guide d'utilisation
Manual del Usuario
Indoor Lighting Fixture
Installation Instructions
Instructions d'installation
Appareil d'éclairage pour utilisation intérieure
Instrucciones para la insalación
de la lámpara para interiores
Please write model number here for future reference: / Veuillez noter le numéro de mod-
èle aux fins de référence ultérieure: / Por favor, incluya el número del modelo aquí para
futura referencia:
10:13 PM
Page 1
W-204
032312

Advertisement

loading
Need help?

Need help?

Do you have a question about the W-204 and is the answer not in the manual?

Questions and answers

Related Manuals for Westinghouse W-204

Summary of Contents for Westinghouse W-204

  • Page 1 Appareil d'éclairage pour utilisation intérieure Instrucciones para la insalación de la lámpara para interiores W-204 032312 Please write model number here for future reference: / Veuillez noter le numéro de mod- èle aux fins de référence ultérieure: / Por favor, incluya el número del modelo aquí para...

  • Page 2: Warranty Information

    If this fixture fails for any reason covered by this warranty, simply return the fixture with a copy of the original sales receipt, freight prepaid and Westinghouse Lighting, at its option, shall repair or replace the fixture or refund the purchase price.
  • Page 3 12 pg_W-204_EFS 7/25/05 10:13 PM Page 3 GROUND *OUTLET FIGURE 1. WIRE BOX (B) WIRE CONNECTORS (N) SIDE HOLE (P) MOUNTING *OUTLET BOX BAR (A) SCREWS (C) LOCK WASHER (F) GREEN GROUNDING HEX NUT 1 (D1) SCREW (O) MOUNTING NIPPLE (E) SCREW COLLAR (L) CANOPY (M)
  • Page 4 12 pg_W-204_EFS 7/25/05 10:13 PM Page 4 MOUNTING AND WIRING INSTRUCTIONS NOTE: Underwriters Laboratories (UL) does not require all fixtures to have ground wires. These fixtures meet all UL specifications. 1. Turn off power at circuit box to avoid possible electric shock. 2.

  • Page 5: Garantie Limitée De Cinq Ans

    (voir fig. 1). GARANTIE LIMITÉE DE CINQ ANS Cet appareil d'éclairage Westinghouse est assorti d’une garantie de 5 ans contre les défauts de matériaux et de fabrication, qui entre en vigueur à partir de la date d'achat. La présente garantie se substitue à...
  • Page 6 12 pg_W-204_EFS 7/25/05 10:13 PM Page 6 *BOITE DE SORTIE FIL DE MISE FIGURE 1. A LA TERRE DE COURANT (B) CONNECTEURS DE FIL (N) TROU LATERAL (P) BARRE DE *VIS DE LA BOITE DE FIXATION (A) SORTIE DE COURANT (C) RONDELLE DE BLOCAGE (F) VIS DE MISE A LA TERRE...
  • Page 7 12 pg_W-204_EFS 7/25/05 10:13 PM Page 7 INSTRUCTIONS DE MONTAGE ET DE RACCORDEMENT NOTA : Underwriters Laboratories (UL) n’exige pas que tous les appareils d’éclairage comportent des fils de mise à la terre. Ces appareils satisfont cependant à toutes les spécifications UL. 1.
  • Page 8 Si este artefacto sufre un desperfecto causado por cualquiera de las razones cubiertas por esta garantía, simplemente envíe el artefacto con una copia del comprobante original de compra, fran- queo prepago, y Westinghouse Lighting, a su criterio, reparará o reemplazará el artefacto o le rein- tegrará el precio de compra.
  • Page 9 12 pg_W-204_EFS 7/25/05 10:13 PM Page 9 CABLE DE *CAJA DE FIGURA 1. TIERRA EMBUTIR (B) CONECTORES DE ROSCA (N) ORIFICIO LATERAL (P) BARRA DE *TORNILLOS CAJA MONTAJE (A) DE EMBUTIR (C) TORNILLO ARANDELA DE PRESION (F) VERDE DE TUERCA HEXAGONAL 1 (D1) TIERRA (O) NIPLE DE MONTAJE (E) COLLAR...
  • Page 10 12 pg_W-204_EFS 7/25/05 10:13 PM Page 10 INSTRUCCIONES DE MONTAJE Y CABLEADO NOTA: Underwriters Laboratories (U.L.) no requiere que todos los artefactos tengan cables de tierra. Estos artefactos cumplen con todas las especificaciones U.L. 1. Desconecte el suministro eléctrico en la caja de fusibles para evitar la posibilidad de descarga eléctrica.
  • Page 11 12 pg_W-204_EFS 7/25/05 10:13 PM Page 11 FIGURE 2. WARNING CONNECT TO BLACK CONNECT TO WHITE GROUP A: GROUP B: HOUSE WIRE HOUSE WIRE Turn off electricity to the BLACK WHITE mounting site before beginning installation. WHITE OR GREY WITH TRACER WHITE OR GREY WITHOUT TRACER Mounting instructions must be followed exactly...
  • Page 12 Westinghouse Lighting Corporation Philadelphia, Pa. 19154-1029, U.S.A. Westinghouse Lighting Corporation, a Westinghouse Electric Corporation licensee. www.westinghouselighting.com “Westinghouse” and “You can be sure...if it’s Westinghouse” are registered trademarks of Westinghouse Electric Corporation. © 2012 WESTINGHOUSE LIGHTING CORPORATION...
