Owner's Manual
Outdoor Lighting Fixture
Installation Instructions
W-015
01/14/04

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the W-105 and is the answer not in the manual?

Questions and answers

Related Manuals for Westinghouse W-105

Summary of Contents for Westinghouse W-105

  • Page 1 Owner’s Manual Outdoor Lighting Fixture Installation Instructions W-015 01/14/04 Please write model number here for future reference: / Veuillez noter le numéro de mod- èle aux fins de référence ultérieure: / Por favor, incluya el número del modelo aquí para futura referencia:...

  • Page 2: Warranty Information

    If this fixture fails for any reason covered by this warranty, simply return the fixture with a copy of the original sales receipt, freight prepaid and Westinghouse Lighting, at its option, shall repair or replace the fixture or refund the purchase price.
  • Page 3 FIGURE 1. *OUTLET CROSS BOX (C) BAR (B) *OUTLET BOX SCREWS (D) MOUNTING SCREWS (A) SIDE HOLE (G) GREEN GROUNDING SCREW (F) BACK PLATE (H) CAP NUTS (I) GROUND WIRE THUMB SCREWS (K) WIRE CONNECTORS (E) GLASS SHADE (J) Line art shown may not exactly match the fixture enclosed. *NOT SUPPLIED However, the installation instructions do apply to this fixture.
  • Page 4 MOUNTING AND WIRING INSTRUCTIONS CAUTION: For fixtures labeled for outdoor and wet location use, provide a water-tight seal between the fixture and the mounting surface by using silicone or similar caulking. NOTE: Underwriters Laboratories (UL) does not require all fixtures to have ground wires. These fixtures meet all UL specifications.

  • Page 5: Garantie Limitée De Cinq Ans

    (voir fig. 1). GARANTIE LIMITÉE DE CINQ ANS Cet appareil d'éclairage Westinghouse est assorti d’une garantie de 5 ans contre les défauts de matériaux et de fabrication, qui entre en vigueur à partir de la date d'achat. La présente garantie se substitue à...
  • Page 6 FIGURE 1. BARRE TRANSVERSALE (B) *BOITE DE SORTIE DE COURANT (C) *VIS DE LA BOITE DE SORTIE DE TROU COURANT (D) LATERAL (G) VIS DE FIXATION (A) PLAQUE VIS DE MISE ARRIERE (H) A LA TERRE (VERTE) (F) ECROUS CAPUCHONS (I) FIL DE MISE A LA TERRE VIS A CLE (K)
  • Page 7 INSTRUCTIONS DE MONTAGE ET DE RACCORDEMENT NOTA : Underwriters Laboratories (UL) n’exige pas que tous les appareils d’éclairage comportent des fils de mise à la terre. Ces appareils satisfont cependant à toutes les spécifications UL. 1. Mettez l’interrupteur de la boîte à fusibles à « OFF » afin d’éviter le risque d’électrocution. 2.
  • Page 8 Esta garantía no cubre la rotura de piezas de vidrio. Si recibe el artefacto con alguna pieza de vidrio rota, sírvase llamar a Westinghouse Lighting para que le envíen una pieza de repuesto gratis.
  • Page 9 FIGURA 1. BARRA TRANSVERSAL (B) *CAJA DE EMBUTIR (C) ORIFICIO LATERAL (G) TORNILLOS *TORNILLOS CAJA DE MONTAJE (A) DE EMBUTIR (D) TORNILLO PLACA VERDE DE POSTERIOR (H) TIERRA (F) TUERCAS TAPA (I) CABLE DE TIERRA TORNILLOS DE MARIPOSA (K) CONECTORES DE ROSCA (E) PANTALLA DE VIDRIO (J)
  • Page 10 INSTRUCCIONES DE MONTAJE Y CABLEADO NOTA: Underwriters Laboratories (U.L.) no requiere que todos los artefactos tengan cables de tierra. Estos artefactos cumplen con todas las especificaciones U.L. 1. Desconecte el suministro eléctrico en la caja de fusibles para evitar la posibilidad de descarga eléctrica.
  • Page 11 FIGURE 2. WARNING CONNECT TO BLACK CONNECT TO WHITE GROUP A: GROUP B: HOUSE WIRE HOUSE WIRE Turn off electricity to the BLACK WHITE mounting site before beginning installation. WHITE OR GREY WITH TRACER WHITE OR GREY WITHOUT TRACER Mounting instructions must be followed exactly BROWN, GOLD OR BLACK BROWN, GOLD OR BLACK WITH TRACER...

  • Page 12: Cleaning And Care

    Westinghouse Lighting Corporation Philadelphia, PA 19154-1099, U.S.A. Westinghouse Lighting Corporation, a Westinghouse Electric Corporation licensee www.westinghouselighting.com “Westinghouse” and “You can be sure...if it’s Westinghouse” are registered trademarks of Westinghouse Electric Corporation © 2004 WESTINGHOUSE LIGHTING CORPORATION...
