Owner’s Manual Outdoor Lighting Fixture Installation Instructions W-042 030404 Please write model number here for future reference: / Veuillez noter le numéro de mod- èle aux fins de référence ultérieure: / Por favor, incluya el número del modelo aquí para...
If this fixture fails for any reason covered by this warranty, simply return the fixture with a copy of the original sales receipt, freight prepaid and Westinghouse Lighting, at its option, shall repair or replace the fixture or refund the purchase price.
Page 3
FIGURE 1. FINIAL (P) RUBBER WASHER (T) BREAK (Q) COVER (R) FIXTURE COVER NIPPLE (U) BRACKET (S) *OUTLET THREADED BOX (E) CAP NUTS (V) GREEN GROUNDING SCREW (N) SIDE HOLE (O) CROSS BAR (C) CAGE (H) MOUNTING SCREWS (D) *OUTLET BOX ROUND NUT (H) SCREWS (F) COUPLING (W)
Page 4
MOUNTING AND WIRING INSTRUCTIONS CAUTION: For fixtures labeled for outdoor and wet location use, provide a water-tight seal between the fixture and the mounting surface by using silicone or similar caulking. NOTE: Underwriters Laboratories (UL) does not require all fixtures to have ground wires. These fixtures meet all UL specifications.
(voir fig. 1). GARANTIE LIMITÉE DE CINQ ANS Cet appareil d'éclairage Westinghouse est assorti d’une garantie de 5 ans contre les défauts de matériaux et de fabrication, qui entre en vigueur à partir de la date d'achat. La présente garantie se substitue à...
Page 6
FIGURE 1. ECROU DECORATIF (P) *BOITE DE SORTIE RONDELLE EN SEPARATEUR DE COURANT (E) CAOTCHOUC (T) SUPERIOR (Q) COUVERCLE (R) SUPPORT DU COUVERCLE DE L’APPAREIL D’ECLAIRAGE (S) MANCHON ECROUS CAPUCHONS FILETE (U) TARAUDES (V) VIS DE MISE A LA TERRE (VERTE) (N) TROU LATERAL (O)
Page 7
INSTRUCTIONS DE MONTAGE ET DE RACCORDEMENT NOTA : Underwriters Laboratories (UL) n’exige pas que tous les appareils d’éclairage comportent des fils de mise à la terre. Ces appareils satisfont cependant à toutes les spécifications UL. 1. Mettez l’interrupteur de la boîte de fusibles à « OFF » afin d’éviter le risque d’électrocution. 2.
Page 8
Esta garantía no cubre la rotura de piezas de vidrio. Si recibe el artefacto con alguna pieza de vidrio rota, sírvase llamar a Westinghouse Lighting para que le envíen una pieza de repuesto gratis.
Page 9
FIGURA 1. FLORON (P) ARANDELA DE CAUCHO (T) CUBIERTA (R) TOPE *CAJA DE SUPERIOR (Q) EMBUTIR (E) SUPORTE DE LA CUBIERTA DEL ARTEFACTO (S) NIPLE (U) TUERCAS TAPA ROSCADAS (V) TORNILLO VERDE DE TIERRA (N) ORIFICIO LATERAL (O) CABLE DE TIERRA BARRA TRANSVERSAL (C)
Page 10
INSTRUCCIONES DE MONTAJE Y CABLEADO NOTA: Underwriters Laboratories (U.L.) no requiere que todos los artefactos tengan cables de tier- ra. Estos artefactos cumplen con todas las especificaciones U.L. 1. Desconecte el suministro eléctrico en la caja de fusibles para evitar la posibilidad de descarga eléctrica.
Page 11
FIGURE 2. WARNING Turn off electricity to the mounting site before beginning installation. Mounting instructions must be followed exactly as shown for the fixture to be safely supported. CONNECT TO BLACK CONNECT TO WHITE GROUP A: GROUP B: HOUSE WIRE HOUSE WIRE BLACK WHITE...
