Wyse X90 Installation Manual

Mobile thin clients flash and memory upgrade kit
Hide thumbs Also See for X90:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual

Installation Guide

®
Wyse
X90 and X90e Mobile Thin Clients
Flash and Memory Upgrade Kit
Issue: 042810
PN: 883884-21L Rev. A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X90 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Wyse X90

Summary of Contents for Wyse X90

  • Page 1: Installation Guide

    Installation Guide ® Wyse X90 and X90e Mobile Thin Clients Flash and Memory Upgrade Kit Issue: 042810 PN: 883884-21L Rev. A...

  • Page 2: Copyright Notice

    End User License Agreement (“License”) A copy of the Wyse Technology End User License Agreement is included in the software and provided for your reference only. The License at http://www.wyse.com/license as of the purchase date is the controlling licensing agreement.
  • Page 3 The model H12V mobile thin client, products X90 and X90e, contains a user-replaceable battery pack. The battery is designed to work with your Wyse mobile thin client. Do not use a battery from other mobile thin clients or laptop computers with your mobile thin client. Replace the battery only with a compatible battery purchased from a Wyse Authorized Service Center.
  • Page 4 This page intentionally blank.

  • Page 5: Table Of Contents

    About this Guide 1 Finding the Information You Need in this Guide 1 Wyse Technical Support 1 Wyse Online Community 1 Related Online Resources Available at Wyse 1 Getting Started 2 Kit Warranty 2 Kit Contents 2 Required Tools and Materials 3 Installing the Upgrade Kit 4 Verifying the Mobile Thin Client’s Operation 7...
  • Page 6 Contents This page intentionally blank.

  • Page 7: About This Guide

    Wyse mobile thin client features can be found in the datasheet for your specific model. Datasheets are available on the Wyse Web site. Go to http://www.wyse.com/products, click the Wyse Thin Clients link, click the link for your mobile thin client, and then click the Download Datasheet link.

  • Page 8: Getting Started

    If you need to upgrade your operating system, contact Wyse Customer Support at: http://www.wyse.com/support. Wyse Thin Computing Software is available on the Wyse Web site at: http://www.wyse.com/products/software. Getting Started This section provides information about your flash and RAM kit warranty, kit contents, and required tools.

  • Page 9: Required Tools And Materials

    Figure 3 Upgrade Serial Label Required Tools and Materials You will need the following recommended tools to install the kit: • Small Phillips screwdriver • Plastic alignment tools or equivalent Figure 4 Recommended tools Warning Flash and RAM modules may be susceptible to damage by Electro-Static Discharge (ESD).

  • Page 10: Installing The Upgrade Kit

    Installing the Upgrade Kit To install the 1-GB or 2-GB flash and 1-GB RAM Upgrade Kit in an X90 or X90e mobile thin client: Caution Follow all precautions listed in the Quick-Start Guide that came with your mobile thin client for disconnecting and reconnecting the mobile thin client.

  • Page 11: Removing An Older-Type Flash Module

    5. To remove the existing flash module, depending on the type of module you have, you must either pull up the module in the direction as shown in Figure 7, or remove the two screws as shown in Figure 8. Rock the module carefully until free of the connector. Warning Flash and RAM modules may be susceptible to damage by Electro-Static Discharge (ESD).

  • Page 12: Removing The Ram Module

    7. To remove the existing RAM module, use your fingers to unlock the two locking clamps at either side of the module by pushing the clamps in the direction of the arrows shown, see Figure 9. The module should pop up from its socket. Lift out the RAM module. Figure 9 Removing the RAM module 8.

  • Page 13: Verifying The Mobile Thin Client's Operation

    Verifying the Mobile Thin Client’s Operation To verify that the mobile thin client works properly: 1. Reconnect the power cord and power adapter, and then press the power button on the mobile thin client to apply power. 2. After the mobile thin client restarts, close three windows that have opened on the screen by following these instructions: a.

  • Page 14: Shutting Down From The Xpe Test Window

    c. Click Shutdown in the XPE TEST window to shutdown the mobile thin client, see Figure 12. Figure 12 Shutting down from the XPE TEST window 3. Press the power button on the mobile thin client for it to restart. 4.

  • Page 15: Client Information

    Figure 13 Client Information 5. Verify that the MAC address and Serial Number matches the serial number and MAC address on the thin client. 6. Verify that the RAM Configuration is approximately 1984 MB. 7. Verify that the Flash Configuration is less than 1024 MB for a 1-GB flash upgrade and less than 2048 MB for a 2-GB flash upgrade.

  • Page 16: Attaching The Upgrade Serial Label

    Attaching the Upgrade Serial Label The Wyse conversion kit is supplied with a serial label that must be attached to each mobile thin client. Attach the label as shown in Figure 14. Sufficient labels must be purchased for mobile thin clients to be upgraded.

  • Page 17: Figures

    Figures Flash module types 2 RAM module types 2 Upgrade Serial Label 3 Recommended tools 3 Removing bottom screws from access cover 4 Lifting off the access cover 4 Removing an older-type flash module 5 Removing screws from newer-type flash module 5 Removing the RAM module 6 Closing the WinPing window 7 Closing the DOS window 7...
  • Page 18 Installation Guide Wyse® X90 and X90e Mobile Thin Clients Flash and Memory Upgrade Kit Issue: 042810 Written and published by: Wyse Technology Inc., April, 2010 ® ® Created using FrameMaker and Acrobat...

This manual is also suitable for:

X90e
