Summary of Contents for BXB Electronics UFO-2050
- Page 1 BXB ELECTRONICS CO., LTD. Copyright © 2011 BXB ELECTRONICS CO., LTD. All rights reserved.
-
Page 2: Table Of Contents
Appendix. Speed Dome Basic Setting ........................26 Power On & Off ··················································································· 26 Telecom On & Off ················································································ 26 IP Address ························································································· 26 Telecom Protocol ················································································· 27 Definition of Data Transmission Cord ······················································· 28 Copyright © 2011 BXB ELECTRONICS CO., LTD. All rights reserved. -
Page 3: Overview
BXB ELECTRONICS CO., LTD. Overview Thank you for purchasing UFO 2050 conference system from BXB Electronics Co. UFO 2050 is the latest digital conference system with superb performance and elegant design which can be used in various conference rooms. UFO 2050 main control unit has the latest built-in digital module which can control up to 10 chairman units and 999 delegate units. -
Page 4: System Features
5. Chairman ID code: *01-*10, 10 units at most Delegate Unit 1. Types: Tabletop, flush-mounted and hand-held 2. Microphone on/off button 3. ID Setting: 10-Bits DIP Switches 4. Delegate ID code: 001-999, 999 units at most Copyright © 2011 BXB ELECTRONICS CO., LTD. All rights reserved. -
Page 5: Safety Instructions
Warning: Do not disassemble or remodel the product, as these actions may lead to electrical shock or damage. The guarantee on the product will become null if the product is ever disassembled. Copyright © 2011 BXB ELECTRONICS CO., LTD. All rights reserved. -
Page 6: Basic Configuration
1.2 Microphone units are equipped with hidden sockets for connecting Cat.5e cable, featuring simple and beautiful appearance. 1.3 Chairman units are pliable in anywhere within circuit 1.4 Please make sure the power is off before unplugging any unit. Copyright © 2011 BXB ELECTRONICS CO., LTD. All rights reserved. -
Page 7: Connection Between Main Control Unit & Video Tracking System
3.1 The main control unit and software were connected by the D sub 9P type parallel connection. 3.2 Please ensure the connection between Graphic control software sever is adopted as COM 1 port. Copyright © 2011 BXB ELECTRONICS CO., LTD. All rights reserved. -
Page 8: Operation And Features
Reduce parameter setting/ conference volume down STEP Select parameter setting of the IP speed dome from left to right. SAVE Save settings ○ Volume output LED indicator ○ 20×4 bits LCD screen Copyright © 2011 BXB ELECTRONICS CO., LTD. All rights reserved. -
Page 9: Rear Panel Description
5 LINK 1 ~ 4: Microphone output ○ 6 L.Spearer VR: Microphone built-in speaker volume knob ○ 7 AUX output terminal (XLR) AUX output terminal description ※ 1, 3 Ground Sound (Aux) Copyright © 2011 BXB ELECTRONICS CO., LTD. All rights reserved. -
Page 10: Turn On
3. Press the talk button of the chairman unit or any delegate unit, the red LED of microphone can be cleared, or wait for 30 seconds until the test mode of the system is finished, and then the conference begins. Copyright © 2011 BXB ELECTRONICS CO., LTD. All rights reserved. -
Page 11: Lcd Instructions
Button：When pressing the “Talk” button, the auto image tracing and positioning mode is activated. Voice：When using more than two microphones, speed dome will be automatically detected the voice for executing auto image tracing and positioning mode. Copyright © 2011 BXB ELECTRONICS CO., LTD. All rights reserved. - Page 12 System test& scan. Scanning all the units is a must-do when first starts the system. SPEED DONE RETURN (YES) automatically go back to a default point. VIDEO AUTO SWITCH (YES) images automatic override Copyright © 2011 BXB ELECTRONICS CO., LTD. All rights reserved.
-
Page 13: Operations & Settings
All the figures shown on this manual is only an example. Each main control unit has been through a series of quality testing during the process of manufacturing. Due to the default setting is not identical, users can change the settings simply followed by the instruction manual. Copyright © 2011 BXB ELECTRONICS CO., LTD. All rights reserved. -
Page 14: Conference Mode
ID code will be stopped flashing and delegate can talk now. Please （this step can also be executed repeat this steps if more delegates request to talk. Copyright © 2011 BXB ELECTRONICS CO., LTD. All rights reserved. - Page 15 M O D E : F I F O O P E N - M I C : A U T O - O F F : S e c Copyright © 2011 BXB ELECTRONICS CO., LTD. All rights reserved.
-
Page 16: Open Delegate Microphone Number
99 sec later if not speaking, the delegate unit will be automatically AUTO–OFF：99 Sec switched off. ii. AUTO–OFF：Invalid the delegate unit should be manually switched off by pressing the “TALK”. Copyright © 2011 BXB ELECTRONICS CO., LTD. All rights reserved. -
Page 17: Save Setting
( 0 1 ) 0 0 1 5.4 One main control unit can control 16 speed domes cameras. No. 01 ~ 16 is the” ID code” of these 16 speed dome cameras. Copyright © 2011 BXB ELECTRONICS CO., LTD. All rights reserved. - Page 18 5.9 4.6.10 The Programmable Preset Position is the 128th of ID address and the 1st ID code of the IP speed dome. It is mainly used to turn the IP speed dome automatically to the 128th conference preset position when there is no using microphone. Copyright © 2011 BXB ELECTRONICS CO., LTD. All rights reserved.
-
Page 19: Speed Dome Camera Mode
BXB ELECTRONICS CO., LTD 6. SPEED DOME CAMERA MODE 6.1 Auto-Image Tracing & Positioning Control Mode 6.1.1 ” None” mode: Auto-Image Tracing & positioning is disabled. 6.1.2 ” Button” mode: The speed dome will be tracing & positioning the image while the “TALK”... - Page 20 BXB ELECTRONICS CO., LTD Press “STEP” button move ( ) to “Scan” press “Save” button. ◘ M I C C H E C K I N G M O D E T e s t ( S c a n ) ...
-
Page 21: Speed Dome Return
BXB ELECTRONICS CO., LTD CHECKING MIC(Checking correct microphone ID)： Under “Test” status, it will test only those microphones connected MIC COUNTER（All microphone connected） : Under “Test” status, it will be displayed the number of microphones connected correctly. ERROR (Error MIC ID Code) : Under “Test”... -
Page 22: Video Auto Switch
BXB ELECTRONICS CO., LTD 9. VIDEO AUTO SWITCH 9.1 With BXB multiplexer, it can run image override function. 9.2 See following for operation Move “ ◘” to VIDEO AUTO SWITCH You can see () besides Yes Press Press “MODE”... -
Page 23: Volume Mode Settings
BXB ELECTRONICS CO., LTD Volume Mode Settings To set up the volume of PA system, please press the “UP” button ▲ or ”Down” button▼ on the left side of the five functional buttons, the LCD will be showed will show as following.After 3 seconds of pressing the button, the LCD will be automatically returned to the “MENU”... -
Page 24: Tabletop Chairman Microphone Unit
BXB ELECTRONICS CO., LTD Tabletop Chairman Microphone Unit Model:UFO-2011 ○ 1 Talk button ○ 2 Conference Mode Indicator ○ 3 Chairman Control button ○ 4 Talk Indicator ○ 5 MIC Input Functions： 1. Press Talk button, when the indicator lamp of Talk and microphone is on, talking can begin. -
Page 25: Tabletop Delegate Microphone Unit
BXB ELECTRONICS CO., LTD Tabletop Delegate Microphone Unit Model:UFO-2012 ○ 1 Talk button ○ 2 Conference Mode Indicator. ○ 3 Talk Indicator ○ 4 MIC Input Functions： 1. Press Talk button, when the indicator lamp of Talk and microphone is on, talking can begin. -
Page 26: Appendix. Speed Dome Basic Setting
BXB ELECTRONICS CO., LTD Appendix. Speed Dome Basic Setting Power On & Off Before the speed dome connects with other equipments, user has to complete the related settings of IP address and protocols. Please see the following pictures: Reserved port... -
Page 27: Telecom Protocol
BXB ELECTRONICS CO., LTD Percentile Decile Unit a. Please do not set up the identical IP address of two Speed Domes to avoid Communication collisions. b. While adjusting the IP address, please make sure “0(Zero)” is in the north. Telecom Protocol Switch No. -
Page 28: Definition Of Data Transmission Cord
BXB ELECTRONICS CO., LTD Definition of Data Transmission Cord For user’s convenient fast installation and test, this IP Speed Dome contains a 50 centimeters data transmission cord; Data transmission cord varies depend on the product models(DC 12V or AC 24V ). - Page 29 RS-485 is the communication interface between IP Speed Dome and control keyboard; If 24-gauge cord is adopted to use, the maximum length of cable is 4000 feet (1219 meters). Twisted Pair Cable is recommended. BXB Electronics Co., LTD. TAIWAN | Website: www.bxb.tw PA System / Conference System / Language Laboratory System TEL：+886(7)970-3838...
