Vinotemp VT-ICEMAKER15 Owner's Manual

Vinotemp VT-ICEMAKER15 Owner's Manual

Automatic ice maker
Hide thumbs
Table of Contents

Advertisement

Quick Links

A P R O U D H E R I T A G E O F E X P E R I E N C E & Q U A L I T Y
A U T O M A T I C I C E M A K E R
V T - I C E M A K E R 1 5
O W N E R ' S
M A N U A L
W W W . V I N O T E M P . C O M
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VT-ICEMAKER15 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vinotemp VT-ICEMAKER15

Summary of Contents for Vinotemp VT-ICEMAKER15

  • Page 1 A P R O U D H E R I T A G E O F E X P E R I E N C E & Q U A L I T Y A U T O M A T I C I C E M A K E R V T - I C E M A K E R 1 5 O W N E R ’...
  • Page 2 Upon receipt and inspection of unit, the supply cord must be replaced if it is damaged. Contact our customer service at 1-800-777-8466 or info@vinotemp.com. READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS ..........4 PARTS AND SPECIFICATIONS ............5 TECHNICAL DATA ................ 6 ELECTRICAL CONNECTION ............6 CORD INSTRUCTIONS ..............6 INSTALLATION INSTRUCTIONS ............7 OPERATING YOUR ICE MAKER ............9 CARE AND MAINTENANCE ............12 PROBLEMS WITH YOUR ICE MAKER ..........

  • Page 4: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS To reduce the risk of fire, electrical shock or injury when using your appliance, follow these basic precautions: Do not operate this or any other appliance with a damaged cord. Always unplug the appliance or disconnect power and shut off the water line before cleaning or performing maintenance.

  • Page 5: Parts And Specifications

    PARTS AND SPECIFICATIONS 1 7 6 2 1 S o u t h S u s a n a R o a d , R a n c h o D o m i n g u e z , C a l i f o r n i a 9 0 2 2 1 i n f o @ v i n o t e m p .

  • Page 6: Technical Data

    TECHNICAL DATA Model No. VT-ICEMAKER15 Voltage AC 115V Frequency 60 Hz Rated Current (Ice Making/Harvest) 3.7A/4.8A Power Input 260W Power Consumption (kWh/100lbs ice) 13.2 Refrigerant R134a, 7.06oz Ambient Temperature Range 45°- 110° F Operating Water Temperature Range 41°- 90° F...

  • Page 7: Installation Instructions

    INSTALLATION INSTRUCTIONS Before Using Your Ice Maker Remove all exterior and interior packing material. Check to be sure that the appliance is in good condition and that the following parts are included: 1 Ice scoop 1 Ice storage bin 5 ft. Drain hose 9 ft.

  • Page 8: Connecting The Water Supply

    Connecting the water supply IMPORTANT: Improper water line connection may result in flooding. Professional installation is recommended. Review state and local plumbing codes before installation. The ice maker requires a continuous water supply with a minimum pressure of 15 psig and a static pressure not to exceed 80 psig.

  • Page 9: Operating Your Ice Maker

    OPERATING YOUR ICE MAKER IMPORTANT: Although the unit has been tested and cleaned at the factory, due to long-term transit and storage, the first batch of cubes must be discarded. Control Panel Buttons and LEDS ON/OFF button Pressing the ON/OFF button alternates between turning the ice maker on and off. MODE button Pressing the MODE button alternates modes between Freeze and Harvest, reflected by the status of the Green and Yellow LEDs.

  • Page 10: Making Ice

    Smaller: By pressing the “Clean” button you can decrease the size of the ice cubes made. The green LED will blink as the size is lowered. When the lowest possible size is reached, the green LED will remain lit. Bigger: By pressing the “Mode” button you can increase the size of the ice cubes made. The red LED will blink as the size is increased.
  • Page 11 Harvest: During the harvest cycle, the compressor is still operating, but the water pump has stopped. The ice cubes will slide off the evaporator into the storage bin, and the freeze cycle will restart when all the cubes have been harvested. When the ice bin is full, the ice maker will go into cold preservation mode and runs while maintaining a low temperature.

  • Page 12: Care And Maintenance

    CARE AND MAINTENANCE Periodic cleaning and proper maintenance will ensure efficiency, top performance, and a long life for your ice maker. The maintenance intervals listed are based on normal conditions. NOTE: Never keep anything in the ice storage bin that is not ice: objects like wine and beer bottles are unsanitary and labels may slip off and plug up the drain.
  • Page 13 Ice-making system Minerals removed from water during the freezing cycle will eventually form a hard, scaly deposit in the water system. Cleaning the system regularly helps remove the mineral scale build up. Hard water and a less effective filter may require the cleaning system to be cleaned more regularly, up to once every 6 months.

  • Page 14: Problems With Your Ice Maker

    PROBLEMS WITH YOUR ICE MAKER Most common problems can be solved easily, saving you the cost of a possible service call. Try the following suggestions to see if you can solve the problem before contacting Vinotemp at info@vinotemp.com. TROUBLESHOOTING GUIDE...

  • Page 15: Terms And Conditions

    Any claim for damages incurred during shipment by the carrier of the goods are insured and handled directly with the carrier and must be noted at time of delivery. Any damages due to manufacture defects will be handled directly with Vinotemp International, subject to the limited warranty.

  • Page 16: Service & Important Notice

    Rancho Dominguez, CA 90221 www.vinotemp.com Vinotemp is a registered trademark of Vinotemp International. All products, features, and services are subject to change without notice. We cannot guarantee the accuracy of the contents of this document. We disclaim liability for errors, omissions, or future changes.
