Summary of Contents for Vantec UGT-CR960
- Page 1 Multi-Memory Internal Card Reader w/USB2.0, eSATA, Audio Ports Model No.: UGT-CR960 Installation Guide v1.02...
-
Page 2: System Requirement
System Requirement • Microsoft Windows XP/Vista/7(32/64 Bit) • Mac OS x 10.4+ Package Content • Vantec Multi-Memory Internal Card Reader w/USB2.0, eSATA, Audio Ports • 3.5” to 5.25” Mounting Bracket • Installation Guide • Installation Screws Bracket Installation instructions Left Right •... - Page 3 •Step 2: Install the screws to card reader, both left and right(refer to above photo) Step 3: Put the card reader inside the bracket, tighten the screws. Step 4: Finish Installation of product If in doubt about how to install the device correctly, please contact an EXPERT or a specialist workshop and let them do the installation! Improper installation can damage the plug-in unit as well as your computer and all connected devices.
- Page 4 Proceed with caution. Danger to life! Switch off the computer in which the product is to be installed and all connected devices. Disconnect all devices from the mains voltage and pull out the main AC power cord! Just turning off at the on/off switch is not enough! •...
- Page 5 -9pin USB plug -USB 9pin pinouts Most motherboard use cable pinout, some motherboard have slot for fixing • Connect the Audio plug connector with a free Audio connection of your motherboard. Please also note the operating instructions of the motherboard.(refer to below photo):...
- Page 6 -Audio Plug -Audio pinout • Connect the SATA plug connector with a free SATA connection of your motherboard. Please also note the operating instructions of the motherboard. (Refer to below photo) -Red SATA cable -SATA connector on motherboard • Install the cables so that they do not protrude into any of the computer’s fan, use cable ties, for example.
- Page 7 • If your computer does not start correctly, switch it off again immediately and check all the settings and cable connections. It must be disconnected from the mains power supply before restarting, see above!
- Page 8 Also, check for any cosmetic flaws. If any parts are missing or if there are cosmetic defects, please contact the retailer from which you purchased the unit immediately and ask for a replacement. Contact: Vantec Thermal Technology www.vantecusa.com...
