- Page 1 WHYNTER 20 Bottle Thermoelectric Wine Cooler MODEL # : WC-201TD Thank you for your purchase of this WHYNTER product. Please read this Instruction Manual carefully before using product to ensure proper use. Keep this manual in a safe place for...
-
Page 2: Table Of Contents
Table of Contents Wine Cooler Safety Important Safe Guides Important Safety Instructions Before Using Your Wine Cooler Installation Introduction Parts and Features Installation Instructions Operation Guide Temperature Controls Wine Shelves Electrical Connection Extension Cord Operating your Wine Cooler Recommended Temperature Settings Care and Maintenance Cleaning Your Wine Cooler Premises Power Failure... -
Page 3: Wine Cooler Safety
Wine Cooler Safety Your safety and the safety of others are very important to us. To reduce the risk of fire, electrical shocks, or injury when using your Wine Cooler, follow these basic precautions: This is the Safety Alert Symbol. This symbol alerts you to potential hazards that may result in serious injury. - Page 4 Use two or more people to move and install the Wine Cooler. Failure to do so can result in injury. Choose a well-ventilated area with temperatures above 60°F (16°C) and below 90°F (32°C). This Wine Cooler must be installed in an area protected from the element, such as wind, rain, water spray or drips.
-
Page 5: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS To reduce the risk of fire, electrical shock, or injury when using your Wine Cooler, follow these basic precautions: Read all instructions before using your Wine Cooler An empty cooler can be a hazardous for children or small pets. If disposing of the cooler, remove gasket seals, latches, lids or the entire door from your unused Wine Cooler, or take other action to ensure the cooler is harmless. -
Page 6: Parts And Features
Parts and Features Hinge Cover Light Switch Light Magnetic Door Seal Fan Mask Glass Shelf Door Handle Foot Door Frame Water Box Note: Your specific model of Wine Cooler may differ slightly from the diagram above but its operation is essentially the same. -
Page 7: Operation Guide
Operation Guide Temperature Controls Use the temperature adjustment buttons on the control panel to change the set temperature. Press the “▼” button to lower the temperature or “▲” button to raise the temperature. The temperature inside the Wine Cooler is dependent on the ambient temperature (room temperature). The Wine Cooler temperature range is between 46 -65 degrees F. -
Page 8: Electrical Connection
Technical Data Model number: WC-201TD Maximum Capacity: 20 standard wine bottles Temperature Control: Electric Control Input Power: 120 Volts / 60 Hertz Power Consumption: 75 Watts / 1.0 Amps Net Weight: 33 lbs Dimensions: 22"H x 16"W x 20.5"D Electrical Connection Improper use of the grounded plug can result in the risk of electrical shock. -
Page 9: Operating Your Wine Cooler
Operating your Wine Cooler It is recommended you install the Wine Cooler in a place where the ambient temperature is between 70º- 78ºF. If the ambient temperature is above or below recommended temperatures, the performance may be affected. For example, placing your Wine Cooler in extreme cold or hot conditions may cause interior temperatures to fluctuate. -
Page 10: Care And Maintenance
Care and Maintenance Cleaning your Wine Cooler Turn off the power, unplug the Wine Cooler, and remove all items including shelves. Wipe the interior with a warm water and baking soda solution. The solution should be about 2 tablespoons of baking soda to one quart of water. -
Page 11: Troubleshooting Guide
Troubleshooting Guide Most common problems can be resolved by referring to the troubleshooting suggestions listed below. PROBLEM POSSIBLE CAUSE SOLUTIONS The Wine Cooler does There is a power failure. Ensure the Wine Cooler is plugged not turn on. in and the power outlet has power. -
Page 12: Warranty Information
ONE YEAR LIMITED WARRANTY This WHYNTER Wine Cooler is warranted, to the original owner within the 48 continental states, for one year from the date of purchase against defects in material and workmanship under normal use and service. Should your WHYNTER Wine Cooler prove defective within one year from the date of purchase, return the defective part or unit, freight prepaid (within two months of purchase;...
