Whynter Elite Seamless Stainless Steel Door Dual Zone Built-in
Wine Refrigerators
Model # : BWR-171DS & BWR-401DS
INSTRUCTION MANUAL
BWR-171DS
BWR-401DS
Congratulations on your new Whynter product. To ensure proper operation, please read this Instruction Manual carefully before
using this product. Keep this manual in a safe place for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BWR-171DS and is the answer not in the manual?

Questions and answers

Related Manuals for Whynter BWR-171DS

Summary of Contents for Whynter BWR-171DS

  • Page 1 Model # : BWR-171DS & BWR-401DS INSTRUCTION MANUAL BWR-171DS BWR-401DS Congratulations on your new Whynter product. To ensure proper operation, please read this Instruction Manual carefully before using this product. Keep this manual in a safe place for future reference.

  • Page 2: Table Of Contents

    Table of Contents PAGE Safety Precautions 3 - 4 Parts Product Features Installation 7 - 9 Operation and Controls 10 - 12 Storage 13 - 14 Care and Maintenance Troubleshooting 16 - 17 Warranty Information...

  • Page 3: Safety Precautions

    Safety Precautions APPLIANCE SAFETY Your safety and the safety of others are very important to us. To reduce the risk of fire, electrical shock, or injury when using your appliance, follow these basic precautions This is the Safety Alert Symbol. This symbol alerts you to potential hazards that may result in serious injury.

  • Page 4: Safety Precautions

    Safety Precautions  Do not store or use gasoline or other flammable vapors and liquids in the vicinity of the appliance or any other appliance.  Before proceeding with cleaning and maintenance operations, make sure to unplug the appliance.  Do not connect or disconnect the electric plug with wet hands.

  • Page 5: Parts

    Parts BWR-171DS BWR-401DS 1. Door Handle 4. Door 2. Shelves 5. Cabinet 3. Control Panel 6. Leveling Legs 7. Bottom Grille...

  • Page 6: Product Features

    Product Features  Capacity: 17 standard 750ml wine bottle capacity for BWR-171DS Upper Zone Capacity: 6 bottles Lower Zone Capacity: 11 bottles  Capacity: 40 standard 750ml wine bottle capacity for BWR-401DS Left Zone Capacity: 20 bottles Right Zone Capacity: 20 bottles ...

  • Page 7: Installation

    Installation IMPORTANT SAFETY INSTRUCTIONS To reduce the risk of fire, electrical shock, or injury WARNING when using your appliance, follow these basic pre-  Read all instructions before using the appliance.  DANGER or WARNING: An empty wine refrigerator can be a hazardous for children or small pets.
  • Page 8 WARNING: Improper use of the grounded plug can result in the risk of electrical shock. If the power cord is damaged, have it replaced by a qualified electrician or contact Whynter Service Department This appliance requires a standard 115/120 Volt AC ~/60Hz electrical ground outlet with three-prong. Have the wall outlet and circuit checked by a qualified electrician to make sure the outlet is properly grounded.

  • Page 9: Installation

    Installation REVERSING THE DOOR SWING OF YOUR WINE REFRIGERATOR Note: Door reversal is only applicable for model# BWR-171DS. All parts removed must be saved for proper reinstallation of the door. This appliance has the capability of the door opening from either the left or right side. The appliance is deliv- ered to you with the door opening from the left side.

  • Page 10: Operation And Controls

    Rose Wines 49 - 51ºF 10 - 11ºC Sparkling Wines 40 - 47ºF 5 - 8ºC CONTROL PANEL GUIDE BWR-171DS BWR-401DS  POWER To turn the appliance on/off, press and hold the key for 5 seconds. Pressing the key once can switch off the audible alarm when the alarm is on.
  • Page 11 The unit has two separate temperature zones. For model BWR-401DS, the temperature range of BOTH zones can be set between 41ºF and 72ºF (5ºC and 22ºC). For model BWR-171DS, the temperature range of the UP- PER zone is between 41ºF and 50ºF (5ºC and 10ºC) and the LOWER ZONE is between 50ºF and 72ºF (10ºC and 22ºC)
  • Page 12 This appliance is equipped with removable shelves. To prevent damage to the door gasket, make sure the door is opened completely before pulling the shelves out. BWR-171DS - 5 removable shelves BWR-401DS - 11 removable shelves ...

  • Page 13: Storage

    Storage BWR-171DS BWR-401DS...
  • Page 14 Storage STORAGE Wine bottles may differ in size and dimensions so the actual number of bottles can be stored may vary. The 17 or 40 bottle capacities are approximate maximums when storing traditional Bordeaux 750 ML bottles and in- cludes bulk storage. You may load your wine bottles in single row or by stacking while taking note of the following: if you do not have enough bottles to fill your wine refrigerator, it is better to distribute the load throughout the wine refrigerator so as to avoid “all on top”...

  • Page 15: Care And Maintenance

    Care and Maintenance CAUTION: Failure to unplug the appliance during service could result in electrical shock or personal injury. CLEANING YOUR APPLIANCE  Turn off the power, unplug the appliance, and remove all items including shelves.  Wipe the interior with a warm water and baking soda solution. The solution should be about 2 tablespoons of baking soda to one quart of water.

  • Page 16: Troubleshooting

    Troubleshooting Problem Possible Causes Solutions The appliance does not oper-   There is a power failure Ensure the appliance is plugged in and  the power outlet has power The appliance is not plugged in   Replace the broken fuse or reset the A house fuse has blown or the breaker circuit breaker is tripped...

  • Page 17: Troubleshooting

    Troubleshooting Problem Possible Causes Solutions  Display “E0”, “E1”. “E2”,  “E0” indicates the communication Call for service “E3”, “E4”, “E5” or “E7” error for 3 zone models  “E1” or “E2” indicates that the air temperature sensor is failed ...

  • Page 18: Warranty Information

    CHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO ONE YEAR OR THE SHORTEST PERIOD ALLOWED BY LAW, BUT NOT LESS THAN ONE YEAR. WHYNTER SHALL NOT BE LIABLE FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES SUCH AS PROPERTY DAMAGE AND INCIDENTAL EXPENSES RESULTING FROM ANY BREACH OF THIS WRITTEN LIMITED WARRANTY OR ANY IMPLIED WARRANTY.
