Animated Lighting MBx32 User Manual

Light show computer
Hide thumbs
1
2
3
4
5
6
7
8
9

Advertisement

Quick Links

Download this manual
MBx32
Light Show
Computer
MBX32
Port 1
PWR
Audio
Updated: Feb 8, 2014
A User's Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the MBx32 and is the answer not in the manual?

Questions and answers

Related Manuals for Animated Lighting MBx32

Summary of Contents for Animated Lighting MBx32

  • Page 1 MBx32 Light Show Computer MBX32 Port 1 Audio Updated: Feb 8, 2014 A User’s Manual...
  • Page 2 SUMMARY Animated Lighting’s MBx32 is a powerful light show computer. It is the newest version of and the predecessor to our MonsterBrain product. The MBx32 stores and plays Animated Lighting’s light shows consisting of lights and audio fully synchronized and preprogrammed for a truly impressive plug and play show right out of the package.

  • Page 3: General Information

    GENERAL INFORMATION Identify Peripherals FRONT MBX32 Port 1 Audio Power Indicator Port 2 Indicator LEDs Audio Port 1 Terminator LEFT SIDE Ethernet Power 7-24VDC Ethernet Power Connector Input RIGHT SIDE SD/SDHC Micro USB SD Card SD Card Port Slot Indicator...

  • Page 4: Peripheral Descriptions

    H. Power Input - Connects to the provided 7 to 24Vdc power adapter. Connecting power to the MBx32 is the very last step in setting up your system. I. Micro USB Connector - Reserved USB connectivity J.
  • Page 5 PORT 1 Typical Port 1 Con guration For use with LC-16 Light Controllers MBx32 To Power MBX32 Port 1 Audio LC-16 To other LC-16 Light Controllers...
  • Page 6 PORT 2 Typical Port 2 Con guration For use with Pixel Driver RGB Controllers MBx32 MBX32 Port 1 Audio To Power DC Power Supply OUT IN NET HB 3.3V 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 9 10...
  • Page 7 DUAL PORT Both Ports can be used Simultaneously Operate LC-16 Light Controllers and Pixel Drivers at the same time. MBX32 Port 1 Audio Out to LC-16 Controllers Out to Pixel Drivers...
  • Page 8 AUDIO Connect Speakers or FM Transmitter Using a 3.5mm male stereo phono jack MBX32 Port 1 Audio Note: Do not connect the MBx32 directly to a power ampli er or other low-Z input device.

  • Page 9: Troubleshooting

    - No Show is playing - Check to make sure that the HB indicator light on the MBx32 is blinking. If HB is not blinking, please contact Animated Lighting. Check to make sure that the PLAY indicator light is on.
