Page 1: Operating Instructions
IN A BOX A PRODUCT OF ANIMATED LIGHTING, L.C. With Pumpkin Faces Assembly and Operating Instructions Animated Lighting, Inc. 13848 Wyandotte Kansas City, MO 64145 (816) 941-0400 www.animatedlighting.com... - Page 2 Overview Congratulations! You have purchased the Haunted House in a Box (HHIAB). It is a plug-and-play light controller from Animated Lighting that enables you to quickly build an exciting Halloween light show with your lights on bushes and trees, black lights, strobes, spot lights or just about anything spooky that lights up or you can shine a light on.
- Page 3 A1 and A0 on them. These dials need to be set at “1” (A1) and “4” (A0). These dials will be changed based on the size of your display (the number of light controllers that are used). Animated Lighting, Inc PAGE 2...
- Page 4 Auxiliary Bank 1, Channel B Auxiliary Bank 1, Channel C Auxiliary Bank 1, Channel D Auxiliary Bank 2, Channel A Auxiliary Bank 2, Channel B Auxiliary Bank 2, Channel C Auxiliary Bank 2, Channel D Animated Lighting, Inc PAGE 3...
- Page 5 Important Consideration for Power Your Haunted House in a Box can power a large number of lights, more than a typical wall outlet can provide. There are between one to four 120 volt cords coming out of each lighting controller you have purchased. Plug each cord into different wall plugs to distribute the power.
- Page 6 Locate the two dials on the same board as the RJ45 (8-pin) jacks. Below these 2) ADDRESSING: dials are designations “A1” and “A0”. We have listed in the diagram above the network addresses that are needed for each light controller above the picture of each light controller. Animated Lighting, Inc PAGE 5...
- Page 7 Circle Mouth, Face 3 Black Light Top Eyes, Face 4 Bottom Eyes, Face 4 Top Lip, Face 4 Mid Lip, Face 4 Bottom Lip, Face 4 Open Mouth, Face 4 Circle Mouth, Face 4 Black Light Animated Lighting, Inc PAGE 6...
- Page 8 Suggested Light Arrangements - Four Pumpkin Face Package The standard lighting channels for the Haunted House in a Box has been pre-programmed based on the following (the network addresses of this controller are “0” (A1) and “0” (A0): Light Description Strobe Light.
- Page 9 Important Consideration for Power Your Haunted House in a Box can power a large number of lights, more than a typical wall outlet can provide. There are between one to four 120 volt cords coming out of each lighting controller you have purchased. Plug each cord into different wall plugs to distribute the power.
- Page 10 Do not plug the Ethernet Power 7-24VDC transformer into the wall outlet yet. Your light controller enclosure can be located outside but make sure the access holes are pointing down so rain water cannot enter the unit. Animated Lighting, Inc PAGE 9...
- Page 11 Plugging the Haunted House in a Box Light Controllers into Power A Haunted House in a Box light controller is rated for loads between 15 and 60 Amperes maximum. Most household wall outlets are rated for loads of 15 Amperes maximum. Therefore, unless you have specifically installed an outlet that can handle 30 Amperes, you should locate two over-under outlets on separate circuits to power the light controller.
-
Page 12: Warranty And Disclaimer
Use for Year-Round The Haunted House in a Box can be used for several events to dazzle your friends and family: Christmas Use your Christmas in a Box “personality cards” to play Christmas lighting shows and songs. Broadcast holiday music that is in perfect rhythm Christmas with your lighting effects.
