HDB42-4AVF
HD SDI 1080P ICR OSD 42 IR
FEATURES
•
SDI 1080p - 1920 x 1080, 30 fps, 2.0 Megapixel
•
1/2.8" 2.0 Megapixel Progressive Scan CMOS
•
3.3mm~12mm Auto Iris Vari-focal Lens
•
1.0 Lux @ F1.2
•
42 IR LED
•
IR distance up to 100ft / 30m
•
600mA max
•
12V DC
•
IP66 Rating
Please read the M anual before attem pting to use this product.
Specifications and appearance are subject to change without notice.
Copyright © 2013. All Rights Reserved.
Bullet Camera
USER MANUAL
HDC-33
R201312-V04
Advertisement
Table of Contents
Related Manuals for Sentry US HDB42-4AVF
Summary of Contents for Sentry US HDB42-4AVF
-
Page 1: Bullet Camera
HDB42-4AVF HD SDI 1080P ICR OSD 42 IR Bullet Camera USER MANUAL FEATURES • SDI 1080p - 1920 x 1080, 30 fps, 2.0 Megapixel • 1/2.8” 2.0 Megapixel Progressive Scan CMOS • 3.3mm~12mm Auto Iris Vari-focal Lens • 1.0 Lux @ F1.2 •... -
Page 2: Limited Warranty
When the video product exhibits a distinct change in performance. LIMITED WARRANTY Sentry US products are covered under warranty for one (1) years from the date of purchase. The warranty will automatically be voided if any of the following occurs: 1. -
Page 3: Package Contents
PACKAGE CONTENTS One (1) HDB42-4AVF Camera One (1) Mounting Screw One (1) Wall Anchor One (1) User Manual * For any returns, please include all components listed above with original packaging in Resalable Condition. Absolutely No Returns will be accepted if any component is missing/damaged. - Page 4 EXPOSURE Electronic Shutter Auto Auto, 1/25 ~ 1/50,000 AGC Middle Low / Middle / High Auto Slow Shutter Auto x2-x30 Image Brightness 44 0 ~ 100 Digital Wide Range Off / Low / Middle / High Transparent Off / Low / Middle / High Gain at backlight area/ Area / Preset / Return Area for choose Area for display...
- Page 5 IR LED On/Off IR PWM 0 0~100 Return Outer Switch 2D Noise Reduction On/Off 3D Noise Reduction On: S-Level 0 0~100 On: E-Level 0 0~100 Level 80 0~100 Smart Noise Reduction On/Off Return FUNCTIONS Camera Headline On/Off Digital Effect Image Freeze On/Off Mirror Off / Horizonal Mirror / Vertical Mirror / Rotation...
- Page 6 On/Off Level 30 0~60 Static Dead Pixels Repair On/Off Start Level 25 0~60 Auto Slow Shutter x4 X2~x30 Return RS485 Camera ID 0~255 ID Display On/Off Baud Rate 2400, 4800, 9600, 19200, 38400 Return Version 120320 Return IMAGE ADJUSTMENT Sharpness Sharpness On/Off Level 60...
-
Page 7: Troubleshooting
CONDITIONS & TESTING Working Condition Temperature: -10°C~50°C (Recommendation: - 5°C ~ 40°C) Humidity: 10 %∼85 % Storage Condition Temperature: -20°C~60°C Humidity: 0 %∼ 90 % High Temperature storage Test Leaving the packed product at Temperature of 60°C for 72 Hours, then leaving it at Normal Temperature for 8 Hours, after doing that, there should be no Problem in Performance. -
Page 8: Specification
SPECIFICATION Model HDB42-4AVF Image Sensor HD Sony MX-122 1/2.8" progressive scan CMOS Total Pixel 2010(H) x 1108(V) = 2,227,080 Effective Pixel 1944(H) x 1092(V) = 2,122,848 Digital: 1080 (30 frame), 720 (60 frame) Resolution Max: 1100TVL (1080 frame) Color:1.0 Lux @ F1.2, B&W: 0.5 Lux Min.
