EXP Computer CD Station User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CD STATION
USER'S MANUAL
EXP
www.expnet.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CD Station and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for EXP Computer CD Station

Summary of Contents for EXP Computer CD Station

  • Page 1 CD STATION USER’S MANUAL www.expnet.com...
  • Page 2 Non-transferable Limited Warranty EXP, (EXP Computer Inc. and EXP Memory Products), provides a full one year warranty, from the date of purchase, against any defects in the material and workmanship. This warranty shall not apply if the product is in...
  • Page 3 so the above exclusion or limitation may not apply to you. How to contact us: EXP WEB SITE: www.expnet.com TECHNICAL SUPPORT: 516-496-7629 TECHNICAL SUPPORT E-MAIL: support@expcomputer.com - 4 -...

  • Page 4: Table Of Contents

    CONTENTS INTRODUCTION .............. 7 SYSTEM REQUIREMENTS..............7 Features....................7 Package contents ..................8 Caution ......................8 PART NAMES AND FUNCTIONS........9 FRONT PANEL..................... 9 REAR PANEL ..................... 10 POWER SOURCE ............10 HARDWARE INSTALLATION (PC CARD)....11 SOFTWARE INSTALLATION (PC CARD)....12 SOFTWARE INSTALLATION FOR WINDOWS 95/98......
  • Page 5 SOFTWARE INSTALLATION (OPTIONAL PARALLEL PORT) ................21 Windows 95/98..................21 Windows NT 4.0 ..................23 Linux (Red hat distribution) ..............25 PLAYING AN AUDIO CD ..........26 Using cd player utility in windows 95/98....26 Hot-Insert/Remove feature of the PCMCIA CD-ROM ......26 - 6 -...

  • Page 6: Introduction

    The CD Station is a portable external CD-ROM drive, equipped a high- speed PC Card (PCMCIA). The CD station is connected to a PC through a PC Card Type I slot, Type II slot or a Parallel port (parallel cable sold separately).

  • Page 7: Package Contents

    PACKAGE CONTENTS The items shown below are included in the CD-Station package. 1. CD-ROM drive 2. AC Adapter Input: 120 VAC Output: 12 VDC 1 Amp. 3. Device Driver diskette 4. PC Card CAUTION • Condensation can form on the lens if the CD-ROM drive is moved from a cold temperature to a warmer environment.

  • Page 8: Part Names And Functions

    PART NAMES AND FUNCTIONS FRONT PANEL The front panel of your CD-ROM may look slightly different from the figure shown below. However, the following parts and functions are the same regardless of their location on the drive. Eject button: Press this button to eject the tray. Access LED: This LED will blink when the drive is accessing the disc.

  • Page 9: Rear Panel

    REAR PANEL 1. Power Button: (Optional in some models) Press the button to manually power on/off the drive when it is powered by an AC adapter. 2. DC in Jack: Connect AC adapter into here. 3. Interface Connector: Connect the PCMCIA interface card or Parallel Port cable into here. 4.

  • Page 10: Hardware Installation (Pc Card)

    HARDWARE INSTALLATION (PC CARD) Turn OFF your system before connecting the PCMCIA CD-ROM to your computer. 1. Connect the PCMCIA interface card to the CD-ROM drive. Press firmly until the connector is seated, and tighten the two screws on the cable connector.

  • Page 11: Software Installation (Pc Card)

    SOFTWARE INSTALLATION (PC CARD) SOFTWARE INSTALLATION FOR WINDOWS 95/98 If you are inserting the PCMCIA CD-ROM into your computer for the very first time, depend on version of Windows 95/98. Listed below are the screen displays to use for reference. (Your PC Card name may be different) Windows 98 The Add New Hardware Wizard window will be displayed Click Next twice in order to diplay the screen below.

  • Page 12: Windows 95 (B)

    Windows 95 (B) If the Update Device Driver Wizard dialog box appears, as below, it means your Windows 95 is version 4.00.950B, i.e. OSR 2. In this case, perform the following steps for installing the PCMCIA CD- ROM under Windows 95. Otherwise, ignore this section and skip to the next page for installing the PCMCIA CD-ROM for Windows 95 (Older versions).

  • Page 13: Windows 95 (Older Versions)

    Windows 95 (Older Versions) The following dialog will appear. If you are using the PCMCIA CD-ROM under Windows 95 for the very first time and your Windows 95 is version 4.00.950 or 4.00.950a. (If this dialog box does not appear and the CD-ROM folder cannot be found in My Computer, please refer to the section titled “Installing 32-bit Card Support”.) Select Driver from disk provided by hardware manufacturer and then...
  • Page 14 Installing 32-bit Card Support Note: The following procedures apply to the notebook that has install or re- install the original release of the Windows 95 version 4.00.950 or 4.00.950a. Your system should be ready for the PCMCIA socket support prior to operating the PCMCIA CD-ROM.
  • Page 15 After the PCMCIA 32-bit Card Support is installed, Windows will ask you to reboot your computer. You should now refer to the previous section for installing the PCMCIA CD-ROM device driver. If the PCMCIA Socket is not found, then you must add a PCMCIA socket to your system.

  • Page 16: Software Installation For Windows Nt

    SOFTWARE INSTALLATION FOR WINDOWS NT Make sure of the following before you begin: ♦ Windows NT must be version 3.51 or higher. ♦ Since Windows NT does not support the “Hot Insert/Remove” feature, the PCMCIA CD-ROM should be connected with your computer prior to starting Windows NT.
  • Page 17 Click the Add button, and then click the Have Disk... button. Windows NT will then prompt you to insert the manufacturer installation disk. Insert the device driver disk into your floppy drive. Specify the directory as A:\WINNT (or B:\WINNT whichever contains the diskette) and select OK. When the below dialog box appears, select PCMCIA CD-ROM/CD- R/CD-RW/DVD-ROM and click the OK button.

  • Page 18: Software Installation For Linux (Red Hat Distribution)

    SOFTWARE INSTALLATION FOR LINUX (RED HAT DISTRIBUTION) In order to install the PCMCIA CD-ROM, the computer or notebook must have a PCMCIA package install first. The PCMCIA package consists of base kernel modules and card specific modules. The PCMCIA CD-ROM card requires an ATA/IDE card module.

  • Page 19: Hardware Installation (Optional Parallel Port)

    HARDWARE INSTALLATION (OPTIONAL PARALLEL PORT) Before you begin, make sure you turn OFF all power to your system before connecting the CD Drive to your computer. CAUTION The CD and electronic components installed on the CD drive are very sensitive to damage from static electricity.

  • Page 20: Software Installation (Optional Parallel Port)

    SOFTWARE INSTALLATION (OPTIONAL PARALLEL PORT) For Windows 95/98 Check all the connection as states in the “Hardware Installation” section. From the Desktop click the My Computer icon. Next click the Control Panel icon, and then click the Add New Hardware icon. You should now see the window Add New Hardware Wizard.
  • Page 21 4. Insert Installation Diskette into the drive selected, Then click OK. If you're installing from a directory containing downloaded installation files, specify the full path of the directory and click OK. 5. Select PHT Parallel-Port PHT-Series Win95/98 Driver, And click Next>. 6.

  • Page 22: Windows Nt 4.0

    Windows NT 4.0 1. Click on My Computer > Control Panel > SCSI Adapters. 2. Choose Drivers tab and the click on Add. From the Install Driver click the Have Disk button. 3. The Install From Disk dialog box will prompt for device driver diskette. Click the Browse button or type in the path A:\winnt.
  • Page 23 5. Select PHT Parallel-Port PHT-Series NT Driver. Click OK 6. Restart the computer when prompted to do so. VERIFY YOUR INSTALLATION Once your computer has booted up, and your Desk Top appears, click on the My Computer icon. You should now see an additional CD- ROM icon in My Computer.

  • Page 24: Linux (Red Hat Distribution)

    Linux (Red hat distribution) The parallel port CD-ROM IDE modules consist of three parts: There is a base paride module required to access the parallel ports. (Support EPP and Bi-Direct, NOT ECP mode) The second module (to load) is the manufacturer specific protocol driver.

  • Page 25: Playing An Audio Cd

    PLAYING AN AUDIO CD USING THE CD PLAYER UTILITY IN WINDOWS 95/98. Connect the 3.5 mm stereo audio cable from the Line-Out Jack of your CD-ROM to your notebook’s Line-In Jack, or to a self-amplified speaker. Make sure the CD Player utility has been installed in your Windows 95/98.
  • Page 26 To display the PC card indicator on the task bar, perform the following steps: 1. Double-click the PC Card (PCMCIA) icon on the Control Panel. 2. Make sure the box showing the control on the task bar is checked. If the PC Card (PCMCIA) wizard appears when you click the button in step one, restart you computer and repeat the above steps.
  • Page 27 HELPFUL HINTS The following are solutions to some problems that you may encounter while using the PCMCIA CD-ROM. IF YOU CANNOT ACCESS A CD-ROM Solutions: # Make sure there is power to your drive. If you are using power directly from the PCMCIA socket, be sure that your system has enough power.
