Page 2 (ANSI/LEEE C95.1-1992) recommends that people should not be exposed to radiation stronger than 1 milliwatt per square centimetre at the frequencies used in the SIMRAD MS50 terminal. Accordingly, the operator of the terminal should ensure that the area RADIO FREQUENCY RADIATION...
Page 3 Call from Display Handset ............. 2.1 Telephone features .............. 2.10 Chapter 3. Telefax Service 1. Introduction Setting up ................3.1 Using telefax with Simrad MS50 ..........3.2 Chapter 4. Data Service Setting up ................4.1 Starting from PC ..............4.3 Sending NIMS message ............4.6 Receiving NIMS message .............
Page 5: Equipment
Contents Chapter 1. Introduction Equipment .................. 1.1 System description ..............1.6 The design and specifications of the equipment may be changed without notice. Simrad MS50 – User’s Manual...
Page 7 Chapter 1. Introduction Equipment General The Simrad MS50 terminal provides access to the international dial- up telephone, facsimile and data networks via the Inmarsat 3 Spot Beam satellite system. The terminal comprises: • Simrad MS50 • Antenna Unit including RF transceiver (option).
Page 8 Fixed antenna: • Portable antenna designed for semi- or fixed mounting on a flat surface, or tripod. • Provident designed to provide telecommunication services for remote villages, farms, businesses, construction sites etc. Simrad MS50 – Chapter 1. Introduction...
Page 9 See separate information. • Aero, intended for use on the small to medium size aircraft. See separate information. Note! It is advisable to turn off the equipment prior to switching antenna. Simrad MS50 – Chapter 1. Introduction...
Page 10 The SIM card (Subscriber Identity Module) carries subscription informa- tion from your Inmarsat Service Provider (ISP) or Net service provider on an integrated circuit. The Simrad MS50 used with the SIM card assumes the identity of the SIM card. The SIM card has its own set of numbers on which the user can be contacted irrespective of the Simrad MS50 used.
Page 11 With PC connected to Simrad MS50, the Internet Messages Service (NIMS) allows a message of maximum 1024 characters to be sent to the Simrad MS50 from a website, or from the Simrad MS50 to an e- mail address or another Simrad MS50.
Page 12 Inmarsat 3 Spot Beam system, see map on next page. NCS: Network Coordinating Station LES: Land Earth Station (w/Net service providers) MES: Mobile Earth Station (WorldPhone terminal) Simrad MS50 terminal TELEPHONE NETWORKS DATA NETWORKS Figure 1.2 Overwiew of the Inmarsat Mini-M system. Simrad MS50 – Chapter 1. Introduction...
Page 13 Satellite positions AOR-E Atlantic Ocean East Region Indian Ocean Region Pacific Ocean Region The coverage area of the satellites for Simrad MS50 (Mini-M) is shown on the map below. Communication is possible in areas marked with grey. Simrad MS50 coverage...
Page 14 For added functionality: • PC for control and settings. • Telefax Only a thin coaxial cable connects Simrad MS50 to the Antenna Unit. Net service provider The Net service provider issues your user licence and IMN (Inmarsat Mobile Number) numbers. It is also responsible for the billing of calls.
Page 15 When the called party responds, the call proceeds. Calls to Mobiles The Simrad MS50 terminal receives incoming calls via the IMN phone numbers. IMN numbers are assigned to the following ports: • Display Handset (HS port) •...
Page 17: Call From Display Handset
Contents Chapter 2. Operation Call from Display Handset ............2.1 Telephone features ..............2.10 The design and specifications of the equipment may be changed without notice. Simrad MS50 – User’s Manual...
Page 19: Call From Display Handset
Display and keys The Display Handset is used for telephone calls and basic functions. Additional control of functions and other facilities must be done from a PC con- nected to Simrad MS50, see chapter 4. Data Service. Handsfree Displayed when applicable: microphone •...
Page 20 HOOK ON/OFF and ESCAPE key: Telenor Beeps in the handset Before contact is established with the selected satellite beeps indicate attempts. Loudspeaker When off-hook the loudspeaker key toggles the Display Handset loudspeaker ON and OFF: Telenor Simrad MS50 – Chapter 2. Operation...
Page 21 PIN code The user is prompted for the 4-8 digit Personal Identification Number each time Simrad MS50 is switched on: • SIM PIN? (with SIM card). • Phone PIN? (without SIM card). Note! The PIN code may also be entered from the PC, if connected, see "Starting from PC"...
Page 22 "ON" should DATA ØÅ. ÄÖÜ appear in the display. Alternatively, press the ON-OFF button on Simrad MS50. The red ON indicator should light up: L1 L2 Search indicator Call indicator Enter the SIM PIN SIM PIN code: If no SIM card is inserted, the "Phone PIN"...
Page 23 Clear the call when finished: Phone No.+ Call through selected Net service provider: 002 BT PLAY DATA Enter the reference code, e.g. BT: ØÅ. Continue from step 1. Note! Availability of this function depends on provider. Simrad MS50 – Chapter 2. Operation...
Page 24 LIST search tone, and adjust volume: LIST Pressing stops the search. I I I I Accept the satellite, e.g. AOR-E: Use AOR-E? ENTER Note ! The antenna must be connected when selecting Ocean Region. Simrad MS50 – Chapter 2. Operation...
Page 25 AOR-E Display the current default Net: ENTER Telenor Scroll down through list > CMC to wanted Net service provider: LIST Store the chosen Net service provider as default: Default Net ENTER Revert to idle: Simrad MS50 – Chapter 2. Operation...
Page 26 Call from Display Handset cont’d IMN numbers This function lists the IMN numbers assigned to Simrad MS50. Editing of the numbers on the telephone or SIM card respectively can only be done from the PC (when connected). See chapter 4. Data Service.
Page 27 Call from Display Handset cont’d Information The following information is provided: • Simrad MS50 version number. • Forward ID number which identifies your particular Simrad MS50 and SIM card if installed. • System version numbers of the internal software programs. Dial 00+Intn Readout: Phone No.+...
Page 28 Telephone features General Control of functions and other facilities must be done from a PC connected to Simrad MS50, see chapter 4. Data Service. Call through default Net service provider routes the call via the default Net service provider for the satellite (Ocean Region) you are using.
Page 29 4 – AOR-W (Atlantic Ocean Region West) Note! Some Net service providers support the common Ocean Re- gion access no. 870, which connects the call to the dialed Simrad MS50 regardless of the Ocean Region the user currently communi- cates through.
Page 31 Contents Chapter 3. Telefax Service Setting up ................... 3.1 Using telefax with Simrad MS50 ..........3.2 The design and specifications of the equipment may be changed without notice. Simrad MS50 – User’s Manual...
Page 33 Please check with your Net service provider before purchasing a telefax for use with Simrad MS50. Installation Connect the telefax cable to the FAX port on the Simrad MS50 connector panel. For wiring details, see appendix B – Installation of Simrad MS50.
Page 34 Using telefax with Simrad MS50 Transmission Telefax calls made by Simrad MS50 are telefax only. Any telephone handset connected to the telefax machine is for dialing purposes only. To send a fax, use the same dialing sequence as when making a call, either through the default Net or a selected one.
Page 35: Table Of Contents
Misc. version ID information ..............4.57 Oscillator compensation ................. 4.57 Network status ..................4.57 Installation ....................4.58 Paid functions ..................4.58 Phone name setup ................. 4.58 The design and specifications of the equipment may be changed without notice. Simrad MS50 – User’s Manual...
Page 37: Setting Up
Setting up General When connecting a PC to Simrad MS50, access is obtained to all its functions. With a VT100 compatible terminal emulator, such as Windows 95 – HyperTerminal the menu is displayed on the PC screen. Simrad MS50 also provides access to asynchronous data services through its built-in modem capability.
Page 38 Enter a name for the terminal, f.ex. "modem_test". In the "Phone Number" window, select Direct to COM1 (or the COM port Simrad MS50 is connected to). In the "COM1 Properties" window, set as follows: • Bits per second: 9600 bps.
Page 39: Starting From Pc
Starting from PC Procedure Turn on Simrad MS50, see chapter 2. Operation. Open the terminal emulator on the PC, and connect. Key in the start prompt at+wneradte. at+wneradte Terminal MMI started in mode: MMI (multilingual) CTRL-f to switch font CTRL-x to return to AT command mode.
Page 40 Main window appears: Dial 00 + country code + subscriber no To make a call, see Book Last Menu Seek chapter 2. Operation Ctrl + T for Help <+U> <+I> <+O> <+P> Simrad MS50 – Chapter 4. Data Service...
Page 41 "soft" keys. Printing When printing f.ex. a NIMS message or Traffic log, the screen switches to text mode. Simrad MS50 must be restarted to revert to data mode. Simrad MS50 – Chapter 4. Data Service...
Page 42: Sending Nims Message
Setup for sending mail User name : Kari Nordmann NIMS center : 004767244445 470 IN SIM Edit Ctrl + T for Help <+U> <+I> <+O> <+P> Ok reverts to ª P mail manager Simrad MS50 – Chapter 4. Data Service...
Page 43 Information available. Calling NIMS center at 004767244445 Status information, Submitting message changes during call 470 IN SIM Abort Ctrl + T for Help <+U> <+I> <+O> <+P> ªP Abort stops NIMS call after confirmation Simrad MS50 – Chapter 4. Data Service...
Page 44: Receiving Nims Message
26 June 1998 15:57 Arrived: 26 June 1998 15:58 Status : Unread 470 IN SIM Read Ctrl + T for Help <+U> <+I> <+O> <+P> Ok reverts ªU ªP to In box See next page Simrad MS50 – Chapter 4. Data Service...
Page 45 Call dials the mailbox 470 IN SIM <Del Remov Call to read out the voice Ctrl + T for Help <+U> <+I> <+O> <+P> message ªU I O Ok reverts to In Box Simrad MS50 – Chapter 4. Data Service...
Page 46: Functions
See "Phone setup". 006 Traffic log Logs calls and provides detailed printout. See "Traffic log". 008 Precharge Allows preprogramming of total call duration. See "Precharge". 009 Advanced functions See overview on next page. 4.10 Simrad MS50 – Chapter 4. Data Service...
Page 47 002 Misc. version Id information (non-SIM operation). 009 Network status information SIM Only accessible with SIM card. SIM+ May be restricted 99 – Installation menu to higher SIM levels. 001 Paid functions 002 Phone name setup Simrad MS50 – Chapter 4. Data Service 4.11...
Page 48: Last Number List
L a s t General The last 10 numbers called are stored in the Simrad MS50 memory or on the SIM card. Each number may comprise up to 22 digits. If the number is already stored in the phone book, the subscriber’s name appears in the list.
Page 49: Phone Book
The following may be stored for abbreviated dialing from the Display Handset or telephone: • 99 entries with names of up to 29 characters in Simrad MS50. • Up to 100 entries (no.100 and up) with names of up to 10 charac- ters on the SIM card (varies with type).
Page 50 Number : 004766724700 number on the SIM Net provider: Default Net card. Terrestrial net: 00 no. (SIM): 102 <Del Remov New Save Ctrl + T for Help <+U> <+I> <+O> <+P> 4.14 Simrad MS50 – Chapter 4. Data Service...
Page 51: Key Lock
(If Phone PIN / SIM PIN is disabled, turning power off and then on will not unlock the phone.) The facility is only accessible when Simrad MS50 is restricted for use with a specific SIM, or with no SIM.
Page 52: Default Net Service Provider & Terrestrial Network
Return to step 3, Ctrl + T for Help <+U> <+I> <+O> <+P> scroll down and key in ªO Terrestrial network code. Save stores the selected Net service provider and Terrestrial network as default. 4.16 Simrad MS50 – Chapter 4. Data Service...
Page 53: User Access
M e n u General The Simrad MS50 user program is accessible from two levels: • USER LEVEL – accessed by Phone PIN or SIM PIN. Note! If the Phone PIN is accidentally lost, it is possible to reset the user’s password to default by logging in as owner:...
Page 54 > Retype new password: _ <Del To revert to User level, Ctrl + T for Help <+U> <+I> <+O> <+P> reselect the "Set access ª P level" function and select User 4.18 Simrad MS50 – Chapter 4. Data Service...
Page 55 > Retype new password: _ Select Ok following each entry: <Del Ctrl + T for Help <+U> <+I> <+O> <+P> To revert to User level, reselect the "Set access ª P level" function and select User Simrad MS50 – Chapter 4. Data Service 4.19...
Page 56: Data/Printer Port Setup
Setup for data communication • Speed as selected on next page, normally 9600 bps. Note! The bit rate set between the PC and the Simrad MS50 must be higher than the nominal 2400 bps Simrad MS50-to-satellite bit rate to ensure maximum speed transfer.
Page 57: Data/Printer Port Setup
Enable/Disable the DATA port for AT modem as required. Recommended port setup Mode Output to printer Data com. (AT) Data com. (DTR dialing) Printer: Enabled Disabled Disabled AT modem: Disabled Enabled Disabled Hot dial: Disabled Disabled Enabled Simrad MS50 – Chapter 4. Data Service 4.21...
Page 58 Initial mode: The mode is set to AT modem as default. When selecting any of the MMI (Man Machine Interface) settings, the PC screen automatically displays the Simrad MS50 menu. Choose Initial mode (step 9), and scroll down Initial mode 3 –...
Page 59: Phone Setup
13:02:00 29 June 1998 confirm with Yes if settings are correct. Proceed to system reset? Note! The Simrad MS50 Ctrl + T for Help <+U> <+I> <+O> <+P> is now restarted. ªU Simrad MS50 – Chapter 4. Data Service 4.23...
Page 60: Setting Key Lock
M e n u M e n u M e n u Setting key lock Simrad MS50 must be set for use with a specific SIM, or with no SIM. See Advanced functions: Access control. Procedure Select the function Menu ªO...
Page 61: Language Setup
Selct Ctrl + T for Help <+U> <+I> <+O> <+P> Save changes the display ª O text to the selected language. To easy restore English, see next page. Simrad MS50 – Chapter 4. Data Service 4.25...
Page 62: Language Reset
M e n u M e n u M e n u Language reset When starting Simrad MS50 with the display language set to f.ex. Portugese, the Eng function key provides an easy way to restore the default English display language: Nera WorldPhone >...
Page 63: Mailbox Access Numbers
> Voice: Fax: Data: Default numbers for mailbox access <Del Ctrl + T for Help <+U> <+I> <+O> <+P> OK stores the new ª O mailbox number(s). Simrad MS50 – Chapter 4. Data Service 4.27...
Page 64: Call Charge Setup
> Charge time unit (s): modify entries: Price per charge unit: 3.00 Minimum charge time (s): <Del Save Ctrl + T for Help <+U> <+I> <+O> <+P> ª U ª P Save stores the new values: 4.28 Simrad MS50 – Chapter 4. Data Service...
Page 65: Traffic Log
(voice, fax, data, NIMS) • Net provider and satellite • user name (if access code is enabled) / SIM card FWD The Simrad MS50 owner may set the log output mode as follows (see Traffic log settings) • off (stops logging) •...
Page 66 1/100 be replaced by a call charge field and seconds of a minute showing the cost of each call. Example of traffic log printout. 4.30 Simrad MS50 – Chapter 4. Data Service...
Page 67 Ctrl + T for Help <+U> <+I> <+O> <+P> Hours:minutes:seconds Quit reverts to main Appears when "Access code" is enabled. window. (For SIM card call – SIM Id: ABCDF) See Advanced functions: Access control. Simrad MS50 – Chapter 4. Data Service 4.31...
Page 68: Precharge
M e n u General For use with SIM, see "Precharge on SIM card". Simrad MS50 can be preprogrammed with a total call duration limit of up to 44640 minutes (744 hours). The owner stores a special telephone number under short number 00.
Page 69 • Fax or mail the Forward ID and Index to the owner who generates the buy code and returns this by fax, mail, etc. See following pages. • The owner loads the new Precharge limit into Simrad MS50. See following pages. Simrad MS50 – Chapter 4. Data Service...
Page 70 2:33:45 remaining time limit: Time remaining: 3:56:15 Select Ok again and Code Ctrl + T for Help <+U> <+I> <+O> <+P> then press Esc to return to ª P the conversation window: 4.34 Simrad MS50 – Chapter 4. Data Service...
Page 71 Key in the code faxed Ctrl + T for Help <+U> <+I> <+O> <+P> or mailed back to you. The code contains the time information. Ok loads the new remaining time limit. Simrad MS50 – Chapter 4. Data Service 4.35...
Page 72 M e n u M e n u Precharge cont’d M e n u Owner loads Precharge time Simrad MS50 must be set in owner level. Menu ª O Select the function Menu Function menu and scroll down Traffic log to Precharge: 008>...
Page 73 Simrad MS50 must be set in owner level. Using the Precharge Administrator program (QPRG 9110039) to generate a buyer’s Precharge code requires both the owners pass- word and a "key" generated by Simrad MS50, as follows: Menu ªO Select the function...
Page 74: Precharge On Sim Card
M e n u Precharge on SIM card When using SIM card, any Precharge set on the telephone itself is overridden. If no Precharge is set on the SIM card, Simrad MS50 may be used freely. Readout on SIM The procedure is the same as described previously for the telephone (except for the Code function which now is not required), see "Precharge readout"...
Page 75: Advanced Functions
(owner level, or in user level Network status information when diagnostics is ON, see Configuration: Set diagnostics) • Install: Installation and debug menu: Paid functions (owner level) Phone name setup (owner level) Simrad MS50 – Chapter 4. Data Service 4.39...
Page 76: Advanced Functions: Access Control
Simrad MS50 for dialing from Phone Book only. See next page. • Access code which opens Simrad MS50 for up to 25 authorized users. See following pages. • Restrict SIM usage which permits controlling the use of SIM card with Simrad MS50.
Page 77: Restricted Dialing
• Dial from Book only, which restricts calls to the numbers in the Phone Book (in Simrad MS50). It is still possible to append, i.e. a short number entry with number field "0047" means that it is possi- ble to dial all Norwegian numbers.
Page 78 Ctrl + T for Help <+U> <+I> <+O> <+P> Alternative Current mode : Dial from Book only Book Ctrl + T for Help <+U> <+I> <+O> <+P> ª O Similar to Phone book, see this chapter. 4.42 Simrad MS50 – Chapter 4. Data Service...
Page 79: Restricted Dialing Setup
Book allows short numbers Edit Book Ctrl + T for Help <+U> <+I> <+O> <+P> to be entered: ªO NB! Remember to revert to user level Similar to Phone book,see this chapter Simrad MS50 – Chapter 4. Data Service 4.43...
Page 80: Access Code
When the access code function has been enabled, the user is prompted for a 1 - 8 digit personal code when making a call. The code opens Simrad MS50 for one call. Up to 25 authorized users can be allocated access codes.
Page 81: Access Code Setup
<Del Ok stores modified user name. Ctrl + T for Help <+U> <+I> <+O> <+P> NB! Remember to revert to user level ª U I O Simrad MS50 – Chapter 4. Data Service 4.45...
Page 82: Restricted Sim Usage
See also Restricted dialing and Access code. When restricted to SIM provider The service provider can lock Simrad MS50 to a specific type of card, e.g. a "MOBIQ" SIM card. The restrictions will then be: • any "MOBIQ" SIM card.
Page 83: Checking Sim Restrictions
• No restrictions, Access code and Restricted dial only apply for non-SIM operation. • Locked to one, Access code and Restricted dial apply for non- SIM operation and operation with the specified SIM card. Simrad MS50 – Chapter 4. Data Service 4.47...
Page 84: Setting Sim Restrictions
Ctrl + T for Help <+U> <+I> <+O> <+P> * Allowed SIM: Appears if card is locked by SIM provider Follow the same procedure as for Restricted SIM with the marker remaining at Allowed SIM. 4.48 Simrad MS50 – Chapter 4. Data Service...
Page 85: Satellite Setup
Save stores the selected Net service Selct ªO provider and Terrestrial network as the default for that particular satellite. S/A operator and terrestrial network Repeat steps 4 - 6 for selection of S/A operator and terrestrial network. Simrad MS50 – Chapter 4. Data Service 4.49...
Page 86: Port Configuration
<+U> <+I> <+O> <+P> call response. ª P Secure voice appears when bought. For enabling/disabling of secure voice, see appendix D. For port details, see appendix B – Connecting up optional equipment. 4.50 Simrad MS50 – Chapter 4. Data Service...
Page 87: Net Service Providers
972 – Net service providers 004> Telenor Scroll up/down to Indosat wanted service provider: France Telecom Station 12 Teleglobe IDB Ctrl + T for Help <+U> <+I> <+O> <+P> ª P Ok stores the chosen provider: Simrad MS50 – Chapter 4. Data Service 4.51...
Page 88: Power Conservation
974 – Set diagnostics Additional system information is displayed >Set diagnostics: when diagnostics is turned On. Note! Not necessary for Ctrl + T for Help <+U> <+I> <+O> <+P> normal telephone usage. ª I O 4.52 Simrad MS50 – Chapter 4. Data Service...
Page 89: Storing Of Preferred/Allowed Net Service Provider And Stand Alone Operator On The Sim Card
TNID: Network Identification Digits) Telenor TNID: Remove deletes the the Net entry. Remov Edit Ctrl + T for Help <+U> <+I> <+O> <+P> ªU I See next page Removes entry from list Simrad MS50 – Chapter 4. Data Service 4.53...
Page 90 Set S/A preferred Net (Stand Alone operator) Repeat steps 3 through 6. Set allowed Nets / Set S/A allowed Nets Restricted to "CHV2" or higher, depending on Net service provider. Repeat steps 3 through 6. 4.54 Simrad MS50 – Chapter 4. Data Service...
Page 91: Charge Tone
Ctrl + T for Help <+U> <+I> <+O> <+P> ª I DTMF key: 0 - 15 Key no. when selecting DTMF. Available tone types > Single tone DTMF Selct Selct enters the chosen settings: ª O Simrad MS50 – Chapter 4. Data Service 4.55...
Page 92: Information Available
Access level must be set to "owner" or "CHV2" for editing of the numbers on the telephone or SIM card respectively. • Forward ID number which identifies your particular Simrad MS50 and SIM card if installed. • System version numbers of the internal software programs. See next page.
Page 93: Misc. Version Id Information
Region registration: Successful Current ocean: AOR-E of network data. Active NCSC: Active spot beam Id: Oreg Cap ChAdv P.Adv Ctrl + T for Help <+U> <+I> <+O> <+P> Simrad MS50 – Chapter 4. Data Service 4.57...
Page 94: Installation
M e n u M e n u M e n u Paid functions Only appears in owner level (non-SIM operation). An enhanced Simrad MS50 function is activated by entering the "Opening key" provided when purchased: Menu ª O Select the function...
Page 95: Appendix A Telephone Country Codes
Appendix A Telephone country codes .......... A-1 Service address codes..........A-5 Appendix B Installation of Simrad MS50 ........B-1 Installation of Marine Antenna ........B-4 Installation of Voyager Antenna ......B-10 Mounting of Portable Antenna ........ B-15 Installation of Provident Antenna ......B-18 Optional antenna cable ...........
Page 97: Telephone Country Codes
To send number Note! Some Net service providers support the common Ocean Region access no. 870, which connects the call to the dialed Simrad MS50 regardless of the Ocean Region the user currently communicates through. Simrad MS50 – Chapter 5. Appendices...
Page 98 Indian Ocean Region (IOR)(Inmarsat) ..873 Cook Islands ..........682 Indonesia (Republic of) ........62 Costa Rica ............ 506 Iran (Islamic Republic of) ....... 98 Croatia (Republic of) ........385 Iraq (Republic of) ......... 964 Simrad MS50 – Chapter 5. Appendices...
Page 99 Nepal ............977 Swaziland (Kingdom of) ....... 268 Netherlands Antilles ........599 Sweden ............46 Netherlands (Kingdom of the) ......31 Switzerland (Confederation of) ...... 41 New Caledonia ..........687 Syrian Arab Republic ........963 Simrad MS50 – Chapter 5. Appendices...
Page 100 Will form part of numbering zone 7. Code 866 has been allocated to the province of Taiwan. United Arab Emirates (U.A.E.) incl: Abu Dhabi, AJmna, Dubai, Fujeirah, Ras Al, Khaimah, Sharjah, Umm al Oaiwain. Simrad MS50 – Chapter 5. Appendices...
Page 101: Service Address Codes
Ship position reports ........43 Faxmail ............26 Technical assistance (on network) ....33 International outgoing operator ...... 11 Telephone call booking ........17 International information service ....12 Time and duration .......... 37 Time announcement ........50 Simrad MS50 – Chapter 5. Appendices...
Page 103: Installation Of Simrad Ms50
Appendix B – Installation of Simrad MS50 General Simrad MS50 is provided with holes for mounting on desktop or bulkhead. The same mounting arrangement and dimensions apply to Antenna Power Supply delivered with the Marine Antenna and Voyager Antenna. Source of energy The equipment operates from 10 to 32 Volts DC from any 12V or 24V battery.
Page 104 Appendix B – Installation of Simrad MS50 cont’d Bracket for optional Display Handset QSXA 911394 Weight: 0.06 kg Optional 230 VAC Power Supply QBMJ 911004 Mains cable: QRPM 911017/1500 Weight: 0.65 kg Simrad MS50 – Chapter 5. Appendices...
Page 105 Appendix B – Installation of Simrad MS50 cont’d Connecting up optional equipment SIMRAD MS50 5 4 3 2 1 6 7 8 9 RF OUT ON-OFF RS-232 DC IN L1 L2 DATA CD (109) RXD (104) TXD (103) DTR (108)
Page 106: Installation Of Marine Antenna
The equipment is supplied with gasket and a flange for mounting of the Antenna Unit on top of a 42.4 mm outer diameter pipe. Other installation bracket is optional. Simrad MS50 – Chapter 5. Appendices...
Page 107 The latest version (type 3) is mounted as illustrated on page B-6. The earlier versions (type 1 and 2) are mounted as shown on page B-8. Be aware of the condensation drainage through the area around the coax connector for these versions, see illustration. Simrad MS50 – Chapter 5. Appendices...
Page 108 Condensation drainage. Do not cover! Gasket Hexagon screws/ washers (6) Mounting flange Lock screw (2) Use 6 mm unbrako key Mounting flange dimensions: Dia 7 85.5 Tube (option) Outer dia 42.4 DIMENSIONS IN MILLIMETRES Simrad MS50 – Chapter 5. Appendices...
Page 109 Radome top area on the base. Turn radome top approx 30° clockwise until the snap function locks. Alignment mark Locking screw Gasket Snap lock function Radome base Radome base Alignment area Simrad MS50 – Chapter 5. Appendices...
Page 110 Do not cover this area! Gasket Hexagon screws/ washers (6) Mounting flange Lock screw (2) Use 6 mm unbrako key Mounting flange dimensions: Dia 7 85.5 Tube (option) Outer dia 42.4 DIMENSIONS IN MILLIMETRES Simrad MS50 – Chapter 5. Appendices...
Page 111 QRPM 911080-2000 QRPM 911101 10 - 32V DC NB! Polarity dependent: The positive lead is tagged. (The NEGATIVE pole is connected to the CENTRE PIN of the 3-pin plug.) Fuse: 15 A slow blow Simrad MS50 – Chapter 5. Appendices...
Page 112: Installation Of Voyager Antenna
The equipment operates from 10 to 32 Volts DC from any 12V or 24V battery. Outline dimensions and weight Antenna Unit QUFF 911905 Weight: 3.0 kg Load carrier mount (option) QSXA 811990 Antenna Power Supply: See page B-1 B-10 Simrad MS50 – Chapter 5. Appendices...
Page 113 See "Assembling the Antenna Unit for load carrier mount". Antenna Unit mounted on load carrier Antenna Unit attached with magnetic plate Power cable with 15A fuse Antenna Power Supply Simrad MS50 Antenna coax cable Simrad MS50 – Chapter 5. Appendices B-11...
Page 114 Lower the base plate down onto the antenna with the mounting holes positioned across for the screw holes. Place the antenna upside down on a stable surface. B-12 Simrad MS50 – Chapter 5. Appendices...
Page 115 Lower the base plate down onto the antenna with the mounting holes positioned across for the screw holes. Place the antenna upside down on a stable surface. Simrad MS50 – Chapter 5. Appendices B-13...
Page 116 QRPM 911080-2000 QRPM 911101 10 - 32V DC NB! Polarity dependent: The positive lead is tagged. (The NEGATIVE pole is connected to the CENTRE PIN of the 3-pin plug.) Fuse: 15 A slow blow B-14 Simrad MS50 – Chapter 5. Appendices...
Page 117: Mounting Of Portable Antenna
If it is an Inmarsat satellite, a continuous tone will sound with varying frequency. When closing in on a satellite, turning the antenna/lid horizontally and adjusting its vertical angle, the tone should increase in frequency. Simrad MS50 – Chapter 5. Appendices B-15...
Page 118 Appendix B – Mounting of Portable Antenna cont’d Installation The Portable Antenna Unit can be mounted in several ways. See examples below. Screw mount Standard tripod mount Antenna tightening Handle used screws as support B-16 Simrad MS50 – Chapter 5. Appendices...
Page 119 Power cable type QRPM 911080-2000 10 - 32V DC NB! Polarity dependent: The positive lead is tagged. (The NEGATIVE pole is connected to the CENTRE PIN of the 3-pin plug.) Fuse: 8 A slow blow Simrad MS50 – Chapter 5. Appendices B-17...
Page 120 The equipment operates from 10 to 32 Volts DC from any 12V or 24V battery, using the 2 m DC power cable, QRPM 911080-2000. The positive lead of the power cable is tagged. B-18 Simrad MS50 – Chapter 5. Appendices...
Page 121 Appendix B – Mounting of Provident Antenna cont’d Outline dimensions Antenna Unit QUFC 911906 Weight: 3.0 kg (antenna only) Mounting the Antenna Unit Adjustment screws (90 degree range) U-bolt Mast bracket Coax connector RF transceiver Max dia 120 mm Simrad MS50 – Chapter 5. Appendices B-19...
Page 122 Appendix B – Mounting of Provident Antenna cont’d Optional bracket Fastened using existing hexagon screws Rear side of antenna Coax connector N-connector (female) N-connector (male) N-connectors Optional antenna cable B-20 Simrad MS50 – Chapter 5. Appendices...
Page 123 Power cable type QRPM 911080-2000 10 - 32V DC NB! Polarity dependent: The positive lead is tagged. (The NEGATIVE pole is connected to the CENTRE PIN of the 3-pin plug.) Fuse: 8 A slow blow Simrad MS50 – Chapter 5. Appendices B-21...
Page 124: Optional Antenna Cable
General Double screen 50 Ω coaxial cable must be used for connection be- tween Simrad MS50 and the various Antenna Units. The coax cable should be secured by laying the cable in a tube and/ or by fastening the cable to avoid damage.
Page 125: Appendix Cat Commands
Hanging up – escape sequence Once the the Simrad MS50 ASD is online to another system, the only command it recognises is an escape code that contains three typed pluses, (+) which forces the Simrad MS50 ASD back to command mode.
Page 126 • Online command mode A data call is taking place and an escape sequence has been initiated, after which the Simrad MS50 ASD will respond to AT commands during the call. • Online data mode Once the Simrad MS50 ASD is connected up, anything arriving from the PC is interpreted as data and sent to the remote end and vice versa.
Page 127 Note! AT commands may be entered in either upper or lower case (not mixed). AT A ç instructs the Simrad MS50 ASD to connect the line and start the answer sequence of the incoming call. Used when not configured for auto answer.
Page 128 AT S sets and displays S register values. See "S-Register Commands". AT V ç sets the Simrad MS50 ASD response format to words or numbers: AT V0 ç selects numeric response. AT V1 ç Default selects verbal response.
Page 129 Appendix C – AT commands cont’d AT Z ç resets the Simrad MS50 ASD configuration to last saved command. Also clears the call if used when in Online Command Mode. repeats last command. Re-executes the last AT command string issued to the Simrad MS50 ASD, including redialing a telephone number.
Page 130 Simrad MS50 ASD clears call when DTR goes inactive. AT & F ç resets the Simrad MS50 ASD to factory default. The factory default is not saved as with the AT&W command, so ATZ revokes to last saved values.
Page 131 AT +ICF = ç [n<format>] [,m<parity>] specifies the local serial port start-stop (asynchronous) character framing between the PC and the Simrad MS50. AT +ICF ? ç displays current settings. AT +ICF =? ç displays available settings. Format reference number n :...
Page 132 1 = XON/XOFF (software flow control) Default 2 = CTS (hardware flow control) AT +IPR = ç [r(PC WP rate)] -to- specifies the data rate at which PC - Simrad MS50 inter- face accepts commands. Simrad MS50 – Chapter 5. Appendices...
Page 133 AT +IPR =9600 ç specifies a data rate of 9600 bps between the PC and the Simrad MS50 telephone unit. AT +W ç Indicates which PCCA standard the Simrad MS50 ASD complies with. AT +WKSIZE = ç sets the maximum ARQ window size for subsequent data calls using ARQ mode.
Page 134 Net service provider for the next outgoing call. The parameter nnn specifies the Net service provider Access Code. Three digits must be keyed in. If omitted, the default Net service provider set from the Simrad MS50 is selected. Range = 0 - 255 nnn = 000, default Net service provider.
Page 135 AT WRTL =? ç displays available threshold levels. The low parameter specifies the lower threshold at which point the Simrad MS50 ASD should issue an RR (Re- ceiver Ready) packet signalling that it is ready to receive data from Net service provider:...
Page 136 AT +WTNID =? ç displays available TNIDs. The parameter nnn specifies the terrestrial network ID. If omitted, it is set to 000. Range = 0 - 255 nnn = 000, terrestrial network unspecified. C-12 Simrad MS50 – Chapter 5. Appendices...
Page 137 AT WTTL =? ç displays available threshold levels. The low parameter specifies the lower threshold at which point the Simrad MS50 ASD should issue an XON, or raise the CTS line signalling that it is ready to receive data from the PC:...
Page 138 +WXTR:<terrestrial rate>,<ARQ I NARQ> +WXKR:<ARQ window size> CONNECT <PC-WP rate> Default 2 = CONNECT <see below >,<ARQ I NARQ> 3 = CONNECT <ARQ I NARQ> The lowest value of PC-WP rate, satellite rate and terrestrial rate. C-14 Simrad MS50 – Chapter 5. Appendices...
Page 139 Appendix C – AT commands cont’d S-Register commands S-registers are special memory locations in the Simrad MS50 for storing specific configuration and operating parameters. AT S0 = ç specifies automatic answer at the n ring. 0=OFF, 1-255=ON. AT S0 = ç...
Page 140 BACK SPACE code to 8. AT S25 = ç sets delay before examining DTR (108/2) after dialing and when online with a Simrad MS50-to-Net call. Range: 0-255 hundredths of a second. AT S25 = ç <n> sets delay value.
Page 141: Dte Interface
Data set ready Request To Send Clear To Send Ring indicator Signal source DTE means the signal goes from the PC to the Simrad MS50. Signal source DCE means the signal goes from the Simrad MS50 to the PC. WorldPhone WorldPhone...
Page 142 ON indicates that DCE (Simrad MS50) is prepared to accept data from DTE (PC). 107 Data Set Ready Signal from Simrad MS50 that when ON indicates that a data call setup is in progress. 108 Data Terminal Ready Signal from PC. This signal is used in the Hotline mode and indicate when going from OFF to ON that the PC wants to make a data call.
Page 143: Appendix D Secure Voice (Option
Appendix D – Secure voice (option) General Simrad MS50 can be programmed to allow operation of encrypted speech through the TEL port and the FAX port when this is configured for voice service. The STU IIB/III is enabled as default on ports configured for voice service.
Page 144: Aero Functions (Option
Prev/Next lists the position Prev Next Save Ctrl + T for Help <+U> <+I> <+O> <+P> of available satellite regions. ª U I O (For possible new satellites, key in position and scroll down to select location) Simrad MS50 – Chapter 5. Appendices...
Page 145: Appendix E List Of Terms
AT command used to control modem functions from the PC keyboard (ATtention). AT modem the built-in modem of the Simrad MS50 that performs the modulation and demodulation required for data communication. Azimuth horizontal direction angle between north and, e.g. the direction to the satellite.
Page 146 Inmarsat system; one in each Ocean Region. NIMS Nera Internet Messages Service, allows a message of maximum 1024 characters to be sent to the Simrad MS50 from a website, or to an e-mail address from the Simrad MS50.
Page 147: Appendix F Troubleshooting
• The called party is busy ("Subscriber busy" appears on the display). • Call the Net service provider. If unsuccessful, wait for some time and try again. • The Simrad MS50 is not properly commissioned. Check with the Net service provider. Simrad MS50 – Chapter 5. Appendices...
Page 148 4. Data Service: Data/printer port setup. • Try to connect to the server through a terminal emulator. • Check the PC program settings, and if necessary extend the timeout intervals. • Contact the PC applications vendor for help. Simrad MS50 – Chapter 5. Appendices...
Page 149 CHV2 4.17, E-1 Display and keys 2.1 owner 4.19 Display Handset user 4.10, 4.17 light on/off 2.3 Light intensity 2.3 DTE interface C-17, C-18 Lock 4.24 Loudspeaker 2.2 Lowercase 4.45, 4.58 Editing entry in phone book 4.14 Simrad MS50 – User’s Manual...
Page 150 Precharge 4.32 User on SIM card 4.38 access 4.10 Printer 4.20 level 4.17 Provident Antenna B-18 Version 4.57 Radiation precautions B-4 Voyager Antenna B-10 Receiving NIMS message 4.8 Reply 4.9 Restricted dialing 4.40 SIM 4.46 Simrad MS50 – User’s Manual...
Page 152 SUPPLIER: Simrad AS P.O. Box 55 N-4371 Egersund Norway Telephone: +47 51 46 20 00 Telefax: +47 51 46 20 01 www.simrad.com WORLDWIDE MANUFACTURER OF MARINE ELECTRONICS...

Simrad MS50 Manual Manual

Table of Contents

Chapter 1 . Introduction

Chapter 2 . Operation

Appendix A Telephone Country Codes

Appendix Cat Commands

Appendix D Secure Voice (Option

Appendix E List of Terms

Appendix F Troubleshooting

Quick Links

Chapters

Need help?

Questions and answers

Related Manuals for Simrad MS50

Summary of Contents for Simrad MS50

Table of Contents
