BUILT IN ELECTRIC FIREPLACE
INSTALLATION GUIDE
CONSUMER SAFETY INFORMATION
PLEASE READ THIS MANUAL BEFORE INSTALLING THIS APPLIANCE
IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED,
AN ELECTRIC SHOCK OR FIRE MAY RESULT CAUSING
PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.
DO NOT STORE OR USE GASOLINE OR OTHER FLAMMABLE
VAPORS AND LIQUIDS IN THE VICINITY OF THIS
Thank you and congratulations on your purchase of a Classic Flame fireplace.
Please read the installation instructions before installing and operating
this appliance.
IMPORTANT: Read all instructions and warnings carefully before starting installation.
Failure to follow these instructions may result in a possible electric shock, fire
hazard and/or injury and will void the warranty.
For Customer Service:
E-Mail: parts@twinstarhome.com
In English Call: 866-661-1218
En Français Call: 866-374-9203
En Español Call: 866-661-1218
MODEL NUMBERS:
39EB500ARA
39EB500GRA
39EB500GRS
WARNING
OR ANY OTHER APPLIANCE.
E-1
Twin-Star International, Inc.
Delray Beach, FL 33445
Made in China
Printed in China
© 2011, Twin-Star International, Inc.
U.S.A.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Classic Flame 39EB500ARA
Summary of Contents for Classic Flame 39EB500ARA
-
Page 1: Installation Guide
DO NOT STORE OR USE GASOLINE OR OTHER FLAMMABLE VAPORS AND LIQUIDS IN THE VICINITY OF THIS OR ANY OTHER APPLIANCE. Thank you and congratulations on your purchase of a Classic Flame fireplace. Please read the installation instructions before installing and operating this appliance. -
Page 2: Listings And Code Approvals
CSA, No.220391, STANDARDS FOR FIXED AND LOCATION DEDICATED ELECTRIC ROOM HEATERS. MODEL SPECIFICATIONS Remote Model Number Description Voltage Watts Amps Control 39EB500ARA 39”Electric Box without any doors 120/208/240 1440/2100/2800 12/10.1/11.7 39EB500GRA 39”Electric Box with glass front 120/208/240 1440/2100/2800 12/10.1/11.7 39EB500GRS 39”Electric Box with double swing door... -
Page 3: Section 2: Recommended Power Supply Wire Specifications
Section 1: Framing Four mounting flanges on the sides of the unit This fireplace is a zero clearance design. No are provided to facilitate installation. combustibles can be placed on the top Insulation and vapor barrier should be placed surface of the fireplace. Combustibles may a minimum of 2 inches from the unit. -
Page 4: Section 3: Voltage Selector Switch Location
Section 3: Voltage Selector Switch Location Important: Caution: Ensure that the incoming power supply When changing the voltage selector switch voltage matches the setting of the from 240 volts to 120 volts ensure that the voltage selector switch!!!!!! power supply is turned off. 230 volt position. -
Page 5: Section 4: Mounting Flanges
Section 4: Mounting Flanges There are two mounting flanges located on each side of the fireplace insert. In order to facilitate the transportation, we make the mounting flanges into flat status. Please bend the mounting flanges into 90 using suitable hardware before installation. (please see the figure 3) Mounting Flange Location: Figure 3 Wall and Mounting Flange: Figure 4... - Page 6 Section 7: 120 Volt Installation Instructions Important • The unit is factory configured for 120 volt • All wiring must be completed prior to operation. installing the unit. • Use 2 conductor wire with ground (3 wires • Ensure that the voltage selector switch is total) from the power supply (breaker in the proper position for the required panel) to the junction box on the unit.
- Page 7 Figure 7: 120V Wire Connection Diagram N - WHITE WIRE N- WHITE WIRE 120 VOLT L2 - RED WIRE POWER SUPPLY BREAKER L1 - BLACK WIRE PANEL L1- BLACK WIRE G - GREEN WIRE G- GREEN WIRE...
- Page 8 Section 6: 240 Volt Installation Instructions Important • The unit is factory configured for 120 volt • All wiring must be completed prior to operation. You must set the voltage installing the unit. selection switch to 240 volts (230 volt is printed on the switch.
- Page 9 Figure 8: 240V Wire Connection Diagram N - WHITE WIRE N- WHITE WIRE 240 VOLT L2 - RED WIRE L2 - RED WIRE POWER SUPPLY BREAKER PANEL L1- BLACK WIRE L1 - BLACK WIRE G- GREEN WIRE G - GREEN WIRE...
- Page 10 Section 8: Wiring Schematic: Fireplace Wiring Diagram TS-0824LIGHT TS-0824LIGHT TS-0824LIGHT E-10...
