Summary of Contents for Classic Flame BB-18
- Page 1 BB-KITS 5) Complete the installation.
- Page 2 REGISTER YOUR NEW PURCHASE online! I NSCRIRE VOTRE NOUVEL ACHAT • REGISTRAR SU NUEVA COMPRA Thank you for purchasing our product. Please take a moment to visit tsicustomerservice.com to register your new purchase: Merci d’avoir acheté ce produit. Veuillez prendre un court instant pour vous rendre sur tsicustomerservice.com et enregistrer votre nouvel achat : Gracias por adquirir nuestro producto.
- Page 3 PRODUCT DETAILS AND NOTES DÉTAILS ET NOTES DU PRODUIT/DETALLES DEL PRODUCTO Y NOTAS Place of purchase/Lieu de l’achat/Lugar de compra: Date of purchase/Date de l’achat/Fecha de compra: Model #/No de modèle/Número de modelo: Notes/Remarque/Notas: B050...
-
Page 4: Safety Information
SAFETY INFORMATION INFORMACIÓN DE INFORMATION DE SÉCURITÉ SEGURIDAD Please read and understand this Assurez-vous de lire et de comprendre Lea y comprenda completamente entire manual before attempting l’intégralité du présent manuel avant este manual antes de intentar to assemble, operate or install the de tenter d’assembler, d’utiliser ou ensamblar, usar o instalar el product. - Page 5 HARDWARE/QUINCAILLERIE/FERRETERÍA [x10] [x8] [x4] Secu 4x8mm 4x15mm Bolt Securing Plate Screw [x1] [x2] Mounting Bracket Frame B050...
- Page 6 Pre-Installation (Special Framing Instructions) Model Number Frame Width (A) Frame Height (B) Frame Depth (C) BB Kit - 18 20 3/16” 17 11/16” 9” BB Kit - 23 25 3/16” 20 3/4” 10” BB Kit - 26 28 5/16” 18 3/8” 10”...
- Page 7 NOTE: If wall has a rough surface, such as stone, the flange should rest against stone surface in vertical position as shown. Flange Mount the brackets (DD) centered in the opening vertically. The flange should lie flat against the wall. Use screws (AA) to secure the bracket to the framing. Depending on framing materials used, the installer may choose to use screws other than what is supplied with this kit.
- Page 8 NOTE: If the insert has this plastic support bracket it needs to be removed. Unscrew the 1 screw holding the bracket in place, remove the bracket then reinstall the screw. Repeat this step for the other corner. Plastic support bracket Screw [x2] [x2]...
- Page 9 NOTE: Complete wiring of the Insert at this time. Insert flange Place the insert into the opening, push the insert against the bracket (DD) 2) Place the insert in the opening, push the insert against the bracket from step 1. from step 1.
- Page 10 NOTE: Test the function of the Insert before continuing to ensure wiring is completed properly. Place the securing plates (CC) over the flange on the insert. Secure to mounting bracket (DD) with screws (BB). Once connected the insert should be held in place securely. Screws A: 4*8mm 8pcs.
- Page 11 4) Attach the frame to the insert by hooking the top side of the frame to the insert ange as shown. Magnets along the bottom edge will secure the frame to the insert. Attach the Frame (EE) to the insert by placing the frame hooks over the insert flange as shown.
-
Page 12: Installation Is Now Complete
Installation is now complete. Complete the installation. B050... - Page 13 NOTES REMARQUES NOTAS B050...
- Page 14 NOTES REMARQUES NOTAS B050...
- Page 15 NOTES REMARQUES NOTAS B050...
- Page 16 CUSTOMER SERVICE SERVICIO AL CLIENTE / SERVICE À LA CLIENTÈLE tsicustomerservice.com tsicustomerservice.com tsicustomerservice.com Para el servicio de atención Pour le Service Clientèle Appeler le For Customer Service 1-877-587-1791 1-877-587-1791 1-877-587-1791 al cliente llame Call ¿Tiene preguntas? Questions? Questions? Nuestro Centro de mensajes está Nos centres d’appels sont disponibles Our message centers are available disponible 7 días de la semana,...
