INSTALLATION GUIDE
LAN Cordless DUALphone
ENGLISH..................................................................
DEUTSCH ................................................................
NEDERLANDS.........................................................
FRANÇAIS ...............................................................
DANSK.....................................................................
SVENSKA.................................................................
■
3
4
27
51
75
99
123
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for DUALphone 3081
Summary of Contents for DUALphone 3081
-
Page 1: Installation Guide
INSTALLATION GUIDE LAN Cordless DUALphone ENGLISH..............DEUTSCH ..............NEDERLANDS............FRANÇAIS ............... DANSK..............SVENSKA..............■... -
Page 2: Welcome
For the EU: The telephone’s conformity with EU directives is confirmed by the CE symbol. We hereby declare that the LAN Cordless DUALphone and/or LAN Cordless DUALhandset are in compliance with the essential requirements and other relevant provisions of Direc- tive 1999/5/EC. -
Page 3: Table Of Contents
■ Prerequisites ................... 12 ■ How to Install the Gateway..............13 ■ How to Install and Register the Handset ..........14 ■ How to Configure the DUALphone ............16 ■ Recommended Basic Settings ..............18 QUICK GUIDE ....................20 TROUBLESHOOTING ..................22 ■... -
Page 4: Box Contents
One DUALphone handset One DUALphone handset charging cradle One DUALphone gateway with LAN and telephone line interface Two mains power adapters for gateway and handset charger (note that the connectors at the end of each adapter cord are different: there is one type for the... -
Page 5: At A Glance
AT A G L A N CE H A N D SE T – F RO NT VI E W MESSAGE INDICATOR message indicator light in antenna – used for voice mail, missed calls, etc. EARPIECE OK KEY used to enter the main COLOR DISPLAY menu and select and confirm options... -
Page 6: Handset - Side View
H AND S ET – S IDE V IE W HEADSET JACK CONNECTOR (2.5MM) LOUDSPEAKER VOLUME UP KEY for speakerphone VOLUME DOWN KEY SPEAKERPHONE activation and deactivation key ■ ■ AT A GLANCE AT A GLANCE... -
Page 7: Handset Charger - Front View
H A N D S ET CH AR G E R – F RO NT V IE W HANDSET CHARGER H A N D SE T C HA RG E R – RE A R V IE W POWER SUPPLY CONNECTOR ON HANDSET CHARGER ■... -
Page 8: Idle Mode
ID L E M OD E HANDSET NAME CONNECTION STATUS INDICATORS BATTERY STATUS and charging indicator OPTIONS TIME AND DATE for redial and active calls (activated with soft key) CALL LOG for incoming, outgoing and missed calls OK KEY INDICATOR (activated with soft key) signifies that the OK key is active Black/black - out of range of the gateway... -
Page 9: Gateway - Rear View
G ATE WAY – REAR V IE W LANDLINE CONNECTION PORT POWER CONNECTION (POTS/PSTN) WAN CONNECTION PORT RESET BUTTON for Ethernet cable for activating configuration changes and enabling handset registration G ATE WAY – F R O N T V IE W POWER INDICATOR I-NET INDICATOR indicates power on... -
Page 10: Getting Started
G ET T I N G STA RT E D PR ER E Q UIS ITE S In order to take full advantage of the features of the DUALphone, you need to have the following in place: ■ Broadband Internet connection – cable, DSL or equivalent ■... -
Page 11: How To Install The Gateway
HO W TO INS TAL L T HE GAT EWAY Gateway / WAN To prepare the gateway for Internet telephony, connect the Ethernet cable to the WAN port on the gateway and then to a LAN port on your broadband modem or router. -
Page 12: How To Install And Register The Handset
H O W TO I N S TAL L AN D RE GIS TE R T HE HA N DS E T Push in and down on the two holes in the back of the handset to release the battery cover. - Page 13 Place the handset in the charger, and charge the batteries. We recommend that you charge the batteries fully before first use. This takes approximately 10 hours. When you place the handset in the charger, the handset automatically registers with the gateway. NOTE: After registration of the first handset, there is a 5-minute period during which you can register any additional handsets.
-
Page 14: How To Configure The Dualphone
Your DUALphone may have been pre-configured by the Internet Telephony Service Provider you have purchased it from. If so, the DUALphone is ready for use once you have plugged in all cables and connected the power. Otherwise, please refer to the instructions in the following section on configuring your DUALphone online or using the handset. - Page 15 HOW TO CONFIGURE THE DUALPHONE USING THE HANDSET If you are unable to complete the online configuration, you can configure your DUALphone using the handset. 1) In Idle mode, press the OK key, choose Settings, and then press the OK key.
-
Page 16: Recommended Basic Settings
Setting the country selection properly ensures, among other things, that you can make and receive landline calls and receive Caller ID information on your DUALphone. It is therefore important that you specify in which country you are using the DUALphone. - Page 17 You can change the handset language whenever you want, but we recommend that you change the country settings only if you bring your DUALphone to another country and want to make landline calls. Also note that you cannot change the country selection in the US version of the DUALphone.
-
Page 18: Quick Guide
Q U I C K G U ID E TO... DO THE FOLLOWING Turn the telephone on To turn the handset on, long press and off To turn the handset off, long press Make an Internet call In Idle mode, enter a phone number and press Answer a call Press... - Page 19 TO... DO THE FOLLOWING Change the ringer melody Press to enter the main menu, choose Settings and then Audio settings. Choose Ringer melody, and then choose the type of call. Browse the list of melodies and press to choose a melody. Use voice mail Sign up for a voice mail account with your Internet Telephony Service Provider.
-
Page 20: Troubleshooting
TR OU B L E SH O O T I N G The following is a list of solutions to the most common issues that may occur during installation and use of the DUALphone. Some problems you can easily solve yourself, and some require that you call your service provider. - Page 21 POSSIBLE SOLUTION 1) Press any key. 2) Charge the batteries. 3) Check that the power cord is connected properly, and that power is turned on. 1) Check that the power cord is connected properly, and that power is turned on. 2) Check that the batteries are inserted with the plus and minus ends facing the correct way.
- Page 22 I cannot make landline calls. 1) The landline cable is not connected. 2) The landline connection is out of order. 1) The configuration of the DUALphone I cannot make Internet calls, the VoIP indicator on the gateway is not lit, and is not complete.
- Page 23 1) Check that you have configured your DUALphone properly. Go to www.dualphone.net and then go to the Configuration page. For more information, see, How to Configure the DUALphone in this guide or in the user manual or contact your Internet Telephony Service Provider.
- Page 24 ■...
