B20F/B20F-PG/B30F/B30F-PG Mixer Parts List
Figure 10 STANDARD ACCESSORIES
1
2
3
Item
Descviption
Mixing device I
1
Mixing device II
2
Mixing device III
3
bowl
4
NOTES
4
Any agitator is easily installed by simp-
ly raising it onto the mixing axle, and
then rotating it clockwise on the shaft
until into place. To remove, raise the a-
gitator on the shaft until it clears the loc-
k and then rotate counter-clockwise and
lower.
All of tools are precisely fitted to the bo-
wl, rounded corners and easily remov-
eable for cleaning.
11
B20F/B20F-PG/B30F/B30F-PG Mixer Parts List
Qty
1
1
1
1
gear axle (2)
fork

Figure 3 GEAR AXLE

5
Item
1
2
3
4
1
6
5
6
7
7
8
9
2
8
3
9 4
NOTES
At the center in the shaft unit. To the
above is the gear shaft and gear sh-
I
aft (see figure 3-1 ).
C-type stop ring(6/8) has to be fixed
gear axle I
when reassembling.
spiral
Be sure that the keys are inserted
for each gear.
axle
FIGURE 3-1
4
Qty
Descviption
1
bearing 6201
gear axle 1
key 5*11 1
1
key 5*11
1
gear
1
stop ring
1
gear
1
stop ring
bearing 6201 1
