QUICK START GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Prime X and is the answer not in the manual?

Questions and answers

Related Manuals for Replay XD Prime X

Summary of Contents for Replay XD Prime X

  • Page 1 QUICK START GUIDE...
  • Page 2 CONGRATULATIONS! You are the owner of the new Prime X. This guide is designed to get you familiar with your new camera. It covers basic features, modes, and mounting options. For more detailed info and video tutorials visit www.ReplayXD.com Love the Prime X?... Share your experiences with us and we’ll show the world: Facebook.com/ReplayXD...
  • Page 3 • The camera has an optimal working temperature range of -20°C to 60°C (-4°F to 140°F). • When you’re using your Prime X or charging the battery, it is normal for Prime X to get warm. The exterior of Prime X functions as a cooling surface that transfers heat from inside the unit to the cooler air outside.
  • Page 4 KEEPING THINGS SIMPLE READY TO GO Prime X is set to record Power [Camera/Wi-Fi] high quality 1080p 60 fps Record [start/stop/shutter] right out of the box. Power status [Blue LED, each 25%] Record status [Red LED] Horizontal level markers Vertical level markers...

  • Page 5: Camera Overview

    CAMERA OVERVIEW Mini USB [charge/sync/480 video out] Charging status, [Green LED=charging] microSD status [Red LED=card full/error] Micro HDMI, Type-D [1080p HD video out] microSDXC compatible slot [up to 64GB] ® Video/Photo, FOV, and FPS status Mode: Video resolution and Photo. MODE -Hold Mode button and Power on camera for mass storage mode.
  • Page 6 1-2A USB charger and into the 3. The card will click into place Prime X USB. [See page 7] when fully inserted. 3. Turn on your Prime X. Press and Hold the Power button for 3 seconds, camera will vibrate 3 times and turn on.
  • Page 7 CHARGE YOUR PRIME X Your Prime X comes with a high capacity Li-ion battery that will last up to 3.5 hours* when properly cared for. To charge your camera, use a high quality USB charger and supplied mini USB cable, we recommend a 1A to 2A USB charger. You can find a USB charger or RePower accessory from our website www.replayxd.com...

  • Page 8: Video Mode

    • 480p 240 [No LED] 120p, 60, 30 fps FPS SETTING FPS LED Other framerates available 120fps Blue • NTSC 60, 30 fps [default] 60fps Green • PAL 50, 25 fps [available from Replay XD App] 30fps • Cine 48, 24 fps [available from Replay XD App]...
  • Page 9 Blue 16MP [Orange LED x2], 14MP [Orange LED x1], 12MP [NO LED] 5 sec Green You can also control your Prime X from the Replay XD App, 3 sec available from the App Store® and Google Play® 30 sec All LED...
  • Page 10 3. From your smartphone or tablet Wi-Fi settings menu, connect to the Prime X. 4. Select the default SSID “Prime X-####” Enter the default password “replayxd” 5. Open the Replay XD App and you will be able to control your Prime X camera, LiveView, Record, Modes and Advanced Settings.
  • Page 11 THE REPLAY XD APP ADVANCED SETTINGS FILE – PRIME-X.TXT The Prime X advanced settings are Adjust from either the text file or the Wi-Fi App. configurable via the Wi-Fi App, available • Enable Pro features to fine tune the image: from the App Store®...
  • Page 12 LIVEVIEW FOR STREAMING Use our popular LiveView via HDMI right from your Prime X. Connect to your TV, ReView Field Monitor, or even broadcast grade equipment and get a full 1080p60 connection. 1. Make sure your microSD card is fully inserted and is ready to record to.
  • Page 13 VIDEO PLAYBACK TO TV After you’re done recording your awesome adventure or scenes for your next movie, you can playback your videos and photos from your Prime X by easily connecting it to an HDMI compatible TV or monitor. 1. Make sure your microSD card is fully inserted and has been recorded to.
  • Page 14 3. Press and Hold the Mode button while you turn on your Prime X. 4. On a PC/Mac the Prime X will mount to your computer as a mass storage device. Download your video files from the DCIM folder created on the microSD card.
  • Page 15 TIP: If your microSD card is new or was previously formatted by another camera or computer, format the card with the Prime X camera. Formatting will erase everything stored on the microSD card, even protected images will be erased. Download any files you would like to keep to your computer or external hard drive before formatting.
  • Page 16 USER INTERFACE - TOP LEDS Solid: Camera is turned on with battery status The Prime X is very simple to use. We made it 100% even easier by giving you, the user, LED and vibration feedback so you know exactly what 1 light rapid flash: 10% or less, time to charge is happening.
  • Page 17 USER INTERFACE - REAR LED / VIBRATION MAP LED INDICATORS - REAR OF CAMERA VIBRATION STATUS No Light: Camera is fully charged or no USB power Press & Hold Power button: Camera is turning on Solid: Camera is charging Vibrate 3 times Solid: SD card is full Flash: No SD card present or SD card read error Press &...
  • Page 18 UNIVERSAL SNAPTRAYS Our SnapTrays use an industrial strength adhesive to secure the camera to the mounting surface. Our mounts snap in and out of the tray via the push tabs. This allows for quick removal and repositioning of the camera in one of many accessory SnapTrays.
  • Page 19 No other camera maker on the market except Replay XD gives you over 1 Million mounting positions right out of the box. Prime X can be mounted nearly anywhere due to its small form-factor and all-round shape. There are two mounts included with each system to get you recording in no-time. The locking tabs on the new mounts have been extended allowing you to get more leverage on the camera while removing it from the mount.

  • Page 20: Optional Accessories

    HYBRID MOUNTS OPTIONAL ACCESSORIES HeimLock Mount LowBoy Mount Tilt Mount Kit Suction Cup Mount Curved SnapTray Tripod SnapTray Goggle SnapTray Flat SnapTray DeepDive 197 Surf SnapTray 3M VHB for SnapTray 3M VHB for Surf SnapTray...
  • Page 21 PRO MOUNTS OPTIONAL ACCESSORIES Pro SuctionCup Mount Pro Chassis Mount Pro Picatinny Rail Mount Pro Tripod Mount Pro Baby Pin 5/8 in Clamp Pro Curved Mount Pro Flat Mount Pro SuctionCup Mini Clamp Pro Skateboard Mount Pro Camera Clamp Replacement 3M VHB for Hardware Pro Flat Mount - 5 pack...
  • Page 22 6+ Hours The Replay XD RePower Battery Adapter is perfect for supplying external battery power to your camera for endurance events and activities. With a large capacity microSD card and the RePower Battery Adapter you can...
  • Page 23 Lens Bezel Kit ProLens 37mm Adapter DeepDive 197 ProCap keep your lens protected add an ND window External Audio Adapter Replay XD WindBreakers Microphone Kit 3.5mm Line-In for the Pro Cut the Windnoise Replay XD App ReView HDMI Field Monitor...
  • Page 24 Your Replay XD Prime X records and saves to a file called a MP4. Your video file is compatible with most current media players on a PC or Mac. Many video editing software titles are compatible out of the box such as: Adobe Premier, Apple Final Cut, iMovie, &...
  • Page 25 REPLAY XD, STABLE IMAGING SOLUTIONS, LLC. (SIS) LIMITED WARRANTY WHAT THE WARRANTY COVERS Replay XD, Stable Imaging Solutions, LLC. (SIS) warrants for 1 year from the date of purchase of product it will be free from defects in material and workmanship.
  • Page 26 REPLAY XD, STABLE IMAGING SOLUTIONS, LLC. DISCLAIMER All purchasers, users, and any or all parties involved or engaging in the use of Replay XD, Stable Imaging Solutions, LLC. (“SIS”) products agree to the following: • SIS does not promote or endorse careless and or dangerous actions/activities when using its products.
  • Page 27 FCC Compliance Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Radio and TV Interference This equipment has been tested and found to comply with the limits for a Class B digital device in accordance with the specifications in Part 15 of FCC rules.
  • Page 28 Replay XD a fine brand of Stable Imaging Solutions, LLC. Sales & Technical Support: Phone: 1-805-480-9800 Sales: sales@replayxd.com Support: support@replayxd.com Corporate Address: Stable Imaging Solutions, LLC. 3709 Old Conejo Road Newbury Park, CA 91320 REV. 2014.7.3.0...
