ID Tech VERSAKEY Manual

Pos keyboard
Hide thumbs Also See for VERSAKEY:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
QUESTIONS?
Ask the experts at POSMicro.com.
1.800.241.6264
Live Chat Now
support@POSMicro.com
Monday - Friday 6 AM to 5 PM Pacific Time
1.800.241.6264
ID Tech Manual
More information available at
BULk DISCOUNTS
FREE SHIPPING*
*Free ground shipping to the continental USa on orders over $100.
For Help Call
POSMicro.com
SE HaBLa
ESpañOL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VERSAKEY and is the answer not in the manual?

Questions and answers

Related Manuals for ID Tech VERSAKEY

Summary of Contents for ID Tech VERSAKEY

  • Page 1 For Help Call 1.800.241.6264 ID Tech Manual More information available at POSMicro.com QUESTIONS? BULk DISCOUNTS SE HaBLa Ask the experts at POSMicro.com. ESpañOL FREE SHIPPING* 1.800.241.6264 Live Chat Now support@POSMicro.com Monday - Friday 6 AM to 5 PM Pacific Time...
  • Page 2 VERSAKEY POS Keyboard Quickstart Manual...

  • Page 3: Fcc Warning Statement

    FCC WARNING STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 4: Limited Warranty

    LIMITED WARRANTY ID TECH warrants to the original purchaser for a period of 36 months from the date of invoice that this product is in good working order and free from defects in mate- rial and workmanship under normal use and service. ID TECH’s obligation under...

  • Page 5: Table Of Contents

    Table of Contents Section 1. Introduction Section 2. Installation & Operation Section 3. Reader Confi guration Section 4. Specifi cation Keyboard Section 5. Specifi cation Reader Section 6. Trouble Shooting Appendix A. Magnetic Stripe Default Settings Appendix B. Connector Pin Assignments Appendix C.

  • Page 6: Section 1. Introduction

    Both the keyboard and the reader are industry proven. The keyboard pro- vides more than 20,000,000 key operations; the reader has an operational life greater than 1,000,000 swipes. The VersaKey meets FCC Class B & CE regulatory requirements. ESD immunity is greater than 15KV with no dam-...

  • Page 7: Section 2. Installation & Operation

    VersaKey. The computer may have several USB connection ports; any of these ports can be used to connect the USB keyboard. To install the VersaKey, close any open applications and Shut Down the com- puter. Determine the VersaKey connection type and locate the appropriate connection receptacle on the computer.

  • Page 8: Reader Configuration

    The VersaKey Reader is an intelligent magnetic stripe reader, which provides extensive formatting capability. In addition, characters can be added to the formatted data. The added characters form either a prefi x or a suffi x to the magnetic stripe data.
  • Page 9 Section 4 SPECIFICATION KEYBOARD MECHANCIAL Keyswitch Total Travel 4.0 + 0.5 mm Operating Force 50 + 7g Keyboard Housing Color Black or Cream White Size 469.9 mm (L) x 203.9 mm (W) x 42.8 mm (H) Material Cable Information Jacket Material PVC jacket with Aluminum Shielding Length 1.5 M (5ft.) Overall...
  • Page 10 Section 5 SPECIFICATION READER Number of tracks Track 1 & 2 or Track 1, 2 & 3 Compatibility ISO 7810 and 7811-1 through -6 cards. Reads AAMVA driver license cards. Communications Decoded track data sent through Keyboard communications cable. Output data formatting Default card data output format or customized data output format is programmable through PC confi...

  • Page 11: Section 6. Trouble Shooting

    Check the connections. Check that the computer power is on. If the power indicator LED is on and the VersaKey is a USB type, the driver may not be loaded properly on the computer. Check the Device Manager in Hardware Properties of the computer.

  • Page 12: Appendix A. Magnetic Stripe Default Settings

    Function Default Value Beep Volume High Inter-Character Delay 2 ms Track Selection Any Track Data Output Format ID TECH Format (See Appendix C) Track Separator See Appendix C MSR Reading Enable Decoding Method Decoding in Both Directions Terminator ID ENTER...

  • Page 13: Appendix B. Connector Pin Assignments

    Appendix B CONNECTOR PIN ASSIGNMENTS PS/2 Connector, 6 pin DIN Connector Pin Signal Not Used +5 V Not Used Data Ground Clock Viewed from cable end USB, 4 pin USB plug Connector Pin Signal +5 V - Data + Data Ground...

  • Page 14: Appendix C. Magnetic Stripe Data Output Format

    Appendix C MAGNETIC STRIPE DATA OUTPUT FORMAT The Reader is shipped from the factory with the following magnetic stripe default settings already programmed: Magnetic Track Basic Data Output Format Track 1: <SS1><T1 Data><ES><TS> Track 2: <SS2><T2 Data><ES><TS> Track 3: <SS3><T3 Data><ES><Terminator> where: SS1(start sentinel track 1) = % SS2(start sentinel track 2) = ;...

  • Page 15: Appendix D. Keyboard Layout

    Appendix D KEYBOARD LAYOUT North American Typical Format...
  • Page 16 ID TECH 10721 Walker Street Cypress, California 90630 (714) 761-6368 www.idtechproducts.com 80074502-001 Rev. A R01/06 #442...
