Charging Battery

.
Charging PP-55:
The PP-55 uses a Lithium Ion rechargeable battery pack. Before first use, the PP-55 battery
pack should be charged for at least 4 hours.
To prevent electrical damage to the printer and/or battery pack, please use approved AC/DC
adapter only.
AC Adapter
Charging PP-55 & Pocket PC device:
The PP-55 has a built-in charging circuit to enable the charging of (selected models) of Pocket
PC device while in the PP-55's cradle. PDA charging only occurs when the external AC/DC
adaptor is connected to PP-55 adapter inlet.
Solid RED = charging
Solid GREEN = fully charged (~4 hrs.)
Infinite Peripherals, Inc.
www.ipcprint.com
PP-55 User's Manual v4.01 for Pocket PC
Figure 2
Figure 3
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Adapter inlet
