- Page 1 R2SUB R2SUBZ, R2SUBDF Premium All-Weather R-Series Subwoofer System Installation Guide...
-
Page 2: Ec Statement Of Conformity
EC STATEMENT OF CONFORMITY This document confirms that the range of products of Community Professional Loudspeakers bearing the CE label meet all of the requirements in the EMC directive 89/336/EEC laid down by the Member States Council for adjustment of legal requirements. - Page 3 First - HF compression driver diaphragm without an outer suspension – the VHF100. Community’s philosophy is to build products that are uncompromised in sound quality, reliability, durability and flexibility, all at a fair price. We provide comprehensive technical support and we stand behind every product we manufacture. We...
-
Page 4: Table Of Contents
R2SUB with R2 Yoke Mounting Instructions ............12 Maintaining Weather-Resistance ..............13 Technical Specifications ................. 13 R2SUB Dimensions ..................14 Warranty Information And Service ..............15 R2SUBZ and R2SUBDF - Installation Guide - Page 4... -
Page 5: Introduction
Introduction The Community R2SUB is a powerful dual 12-inch subwoofer system, offering all the weather-resistant features and benefits of the acclaimed R-Series. The 400-watt R2SUB subwoofer includes two 12-inch drivers and can be flown or down-fired for flexible system configuration. Featuring Community’s bulletproof DYNA-TECH protection circuitry, the R2SUB is engineered to provide quality low frequency reproduction in a wide variety of outdoor and indoor environments. -
Page 6: Polarity
(such as pink noise) and to view the resultant response on an audio spectrum analyzer. If such equipment is not available, it is also possible to determine the best phase relationship by careful listening. R2SUBZ and R2SUBDF - Installation Guide - Page 6... -
Page 7: Absolute Phase
The three corrective methods referred to in the text (equalizing, high-passing, and increasing the slope of the crossover) are all various implementations of equalization. R2SUBZ and R2SUBDF - Installation Guide - Page 7... -
Page 8: R2Subdf Assembly
Once you have determined the subwoofer location(s), lay out a square pattern of four holes on 22 1/32” centers (55.9 cm). See the diagram below. To simplify this operation, a full-size layout template has been provided in the kit. R2SUBZ and R2SUBDF - Installation Guide - Page 8... - Page 9 Bracket, then the Clamp Bracket to the Surface Bracket, before inserting the carriage bolts. Route the speaker cable through the bracket as shown in the illustration below. The Cable Cover is designed to protect the cable from abrasion, as well as to provide a neat looking installation. R2SUBZ and R2SUBDF - Installation Guide - Page 9...
- Page 10 (2) SUPPORT STRUTS BRACKET ONE ON OPPOSITE SIDE SURFACE BRACKET NOT SHOWN GASKET 3/8" FLAT WASHER 3/8" LOCK WASHER 3/8-16x1" CARRIAGE BOLT 3/8" HEX NUT 3/8" FLAT 3/8" LOCK WASHER SURFACE BRACKET WASHER R2SUBZ and R2SUBDF - Installation Guide - Page 10...
-
Page 11: R2Subz Assembly
R2SUBZ Assembly The R2SUBZ includes a weather-resistant U-shaped mounting yoke for mounting R2 systems. When properly utilized, the mounting yoke allows your R2SUB loudspeaker to be properly aimed in virtually any direction. CAUTION: The R2 Mounting Yoke is specifically designed to provide a high degree of safety in R2 installations. -
Page 12: R2Sub With R2 Yoke Mounting Instructions
Caution: Any of the mounting bolts supplied with the R2SUB that are not used for mounting must be left in place with their rubber washers and firmly tightened to maintain the integrity of the weatherproofing. R2SUBZ and R2SUBDF - Installation Guide - Page 12... -
Page 13: Maintaining Weather-Resistance
TRC400 400-watt transformer Digital signal processor Dimensions (H x W x D): 24.75" x 24.75" x 30.75" (629 x 629 x 781 mm) Weight (without yoke or DFKIT): 69 lbs (31.3 kg) R2SUBZ and R2SUBDF - Installation Guide - Page 13... -
Page 14: R2Sub Dimensions
.472" [12] .532" [ 13.5] 16.693±.079" (TYP 7 PLACES) [424±2] 1.220" [31] (TYP) 1.260" [32] 21.000" [533.4] R2 YOKE R2SUBDF Dimensions 32.750" [831.86] 25.000" [635] 25.000" [635] SIDE VIEW FRONT VIEW R2SUBZ and R2SUBDF - Installation Guide - Page 14... -
Page 15: Warranty Information And Service
This Community warranty is not extended by the length of time which an owner is deprived of the use of the product. Repairs and replacement parts provided under the terms of this warranty shall carry only the remaining portion of the warranty. - Page 16 Community Professional Loudspeakers 333 East Fifth Street, Chester, PA 19013-4511 USA Tel: (610) 876-3400 | Fax: (610) 874-0190 www.communitypro.com © 2009 All Rights Reserved 02DEC2009...
