- Page 1 Nitrogen53 Hardware User Manual Revision History Date Revision Description 03-08-2011 First Draft 04-04-2011 Updated Pin Outs 05-24-2011 Updated Board Layout 06-27-2011 Updated Pin Outs for Touch screen Revision 1.3...
-
Page 2: Table Of Contents
1 Contents 1 Contents ............................2 2 Overview............................3 3 Electrical Characteristics ......................3 4 Connector Details......................... 4 5 Mounting............................ 11 Revision 1.3... -
Page 3: Overview
1GHz, the IMX53 is a powerful multimedia platform capable of 1080P video playback. The Nitrogen53 was designed to take advantage of the video performance of the IMX53 by offering multiple display interfaces including HDMI, LVDS, and TTL. With OpenGL® ES 2.0 and OpenVG™... -
Page 4: Connector Details
4 Connector Details As shown in Figure 1, the Nitrogen53 board contains a wide variety of I/O options. This section will focus on the details of each connector. Revision 1.3... - Page 5 Slot HDMI (DVI Signals) DC Power Jack Headphone Jack SATA 4.2 Custom Connectors The Nitrogen53 board has a wide variety of peripheral interfaces available via custom connectors. J1: COM1 & COM2 (Molex 53047-0610) Pin# Function UART1 TX UART2 TX...
- Page 6 J8: General Purpose Input/Output (Molex 54167-0308) Pin# Function EIM_DA0 EIM_DA1 SD3_CMD SD3_CLK SD3_DATA0 SD3_DATA1 SD3_DATA2 SD3_DATA3 GPIO2_24 GPIO2_21 GPIO2_20 GPIO2_19 AUD3_TXC AUD3_TXD AUD3_TXFS AUD3_RXD PWM0 GPIO5_2 GPIO_9 GPIO3_23 UART3_CTS UART3_RXD UART3_RTS UART3_TXD 3.3V 3.3V J9: I2C (Molex 53047-0510) Pin# Function GPIO J15: USB3 (Molex 53047-0410) Pin#...
- Page 7 USBDN_DM3 USBDN_DP3 J18: POE Output (Singatron SSW-1-04-01-T-S) POE Output is meant to interface with BD POE module. If you need further details, please contact us. J19: Audio out (Molex 53047-0210) Pin# Function J21: Microphone In (Molex 53047-0210) Pin# Function MIC_IN Common J23: TTL Display Interface (Omron XF2M-4515-1A) Pin#...
- Page 8 3.3V HSYNC VSYNC 3.3V GPIO J24: External Power Connector (Tyco 640457-3) Pin# Function J25: Camera (AVX 6210033340800) Pin# Function Revision 1.3...
- Page 9 2.8V 1.8V 2.8V 2.8V DATA_EN CAM_RESET VSYNC HSYNC PIX_CLK GPIO_2 GPIO_7 J28: Component Video (Molex 53047-0710) Pin# Function VGA_HSYNC VGA_VSYNC J30: 4-wire Resistive Touch (Molex 52271-0479) Pin# Function J31: LED Backlight (Molex 53047-0510) Pin# Function LED String 1 Cathode LED String 2 Cathode LED String 3 Cathode LED Anode LED Anode...
- Page 10 J34: 5-wire Resistive Touch (Molex 52207-0585) Pin# Function Sense J35: Android Buttons (Molex 53047-0710) Pin# Function GPIO ON/OFF MANUAL ON/OFF HOME SEARCH BACK MENU J37: Auxiliary Power (Molex 53047-0410) Pin# Function Tracks DC INPUT voltage PWM0 CON1: LVDS (Hirose DF14-20P-1.25H) Pin# Function 3.3V...
-
Page 11: Mounting
TX3_P 5 Mounting The overall dimensions of the Nitrogen53 board are 116x75mm. Revision 1.3...
