Nitrogen6_MAX Hardware User Manual
Revision History
Date
07-20-2014
11-04-2015
Revision
1.0
1.1
Added Quad Plus Capability
Revision 1.1
Description
First Draft
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Nitrogen6 MAX and is the answer not in the manual?

Questions and answers

Summary of Contents for Boundary Devices Nitrogen6 MAX

  • Page 1 Nitrogen6_MAX Hardware User Manual Revision History Date Revision Description 07-20-2014 First Draft 11-04-2015 Added Quad Plus Capability Revision 1.1...
  • Page 2 1 Contents 1 Contents ............................2 2 Overview ............................3 3 Electrical Characteristics ......................3 4 Connector Details......................... 4 5 Mounting ............................ 12 Revision 1.1...
  • Page 3 2 Overview The Nitrogen6_MAX is a turbo-charged version of our popular Nitrogen6X platform. The Nitrogen6_MAX features the same Quad-Core i.MX6 processor from Freescale, but has some other notable upgrades to allow for high-end performance. The Nitrogen6_MAX Rev 3 boards, support the i.MX6 Quad PLUS processor. The hardware specifications for the Nitrogen6_MAX board are the following: ...
  • Page 4: Connector Details

    4 Connector Details Micro Host Audio Power Speaker Micro Ethernet Jack HDMI Slot Jack (Right) Boot Connector Switch Speaker (Left) Host Microphone Reset Switch 2x RS-232 (Console/Spare) GPIO/I2C Connector JTAG SATA Connector MIPI GPIO/Android LVDS1 mPCIE RS-485 SATA RS-232/RS-485 Buttons (Secondary) Switch Power...
  • Page 5 4.1 Standard Connectors The list of industry standard connectors with known pin outs is the following: Ref Designator Function USB OTG HDMI Headphone Jack DC Power Jack microSD Slot 1 SATA 2xUSB Host 10/100/1G Ethernet SIM Card Holder 4.2 Custom Connectors The Nitrogen6_MAX board has a wide variety of peripheral interfaces available via custom connectors.
  • Page 6 GPIO_3_CLKO2 2.5V 2.5V 2.5V 2.5V CSI0_DATA_EN CSI0_RST CSI0_VSYNC CSI0_HSYNC CSI0_PIXCLK GPIO_6 GPIO1_16 J6: LVDS (Hirose DF14-20P-1.25H) Pin# Function 3.3V 3.3V LVDS0_TX0_N LVDS0_TX0_P LVDS0_TX1_N LVDS0_TX1_P LVDS0_TX2_N LVDS0_TX2_P LVDS0_CLK_N LVDS0_CLK_P LVDS0_TX3_N LVDS0_TX3_P DISP0_CONTRAST (NANDF_D0) PWM4 J7: I2C/GPIO (Molex 53047-0710) Pin# Function Revision 1.1...
  • Page 7 GPIO9 I2C3_SDA I2C3_SCL J9: MIC In (Molex 53047-0310) Pin# Function GND_Analog MIC In MIC Det J11: LVDS (Hirose DF14-20P-1.25H) Pin# Function 3.3V 3.3V LVDS1_TX0_N LVDS1_TX0_P LVDS1_TX1_N LVDS1_TX1_P LVDS1_TX2_N LVDS1_TX2_P LVDS1_CLK_N LVDS1_CLK_P LVDS1_TX3_N LVDS1_TX3_P LVDS1_GPIO (EIM_CS0) PWM2 J12: CSI1 (Molex 52991-0408) Pin# Function EIM_A23...
  • Page 8 EIM_DA2 EIM_A20 EIM_DA3 EIM_A19 EIM_DA4 EIM_A18 EIM_DA5 EIM_A17 EIM_DA6 EIM_A16 EIM_DA7 EIM_EB3 EIM_DA8 EIM_EB2 EIM_DA9 EIM_RW EIM_DA10 EIM_EB1 EIM_DA11 EIM_EB0 EIM_LBA EIM_DA12 DSI_D1M EIM_WAIT EIM_DA13 EIM_A24 EIM_DA14 +3.3V +3.3V EIM_DA15 J13: JTAG (20021121-00010T4LF FCI) Pin# Function +3.3V JTAG_TMS JTAG_TCK JTAG_TDO JTAG_MOD Revision 1.1...
  • Page 9 JTAG_TDI JTAG_nTRST BRESET_N J14: Android Buttons (Molex 53047-0810) Pin# Function IMX6 Pad Name ON/OFF KEY_VOL_UP GPIO_18 HOME NANDF_D4 SEARCH NANDF_D3 BACK NANDF_D2 MENU NANDF_D1 KEY_VOL_DN GPIO_19 J15: Parallel RGB (Omron XF2M-4015-1A) Pin# Function DISP0_CNTRST Revision 1.1...
  • Page 10 DISP0_CLK DISP0_HSYNC DISP0_VSYNC DISP0_DRDY I2C3_SCL I2C3_SDA PWM1 J16: MIPI (Molex 52991-0308) Pin# Function CSI_D0M CSI_D0P I2C2_SDA CSI_D1M I2C2_SCL CSI_D1P PWM3 MIPI_BAKLGT_ON CSI_D2M NANDF_D5 CSI_D2P DSI_D0P DSI_D0M CSI_D3M CSI_D3P DSI_CLK0P DSI_CLK0M CSI_CLK0M CSI_CLK0P DSI_D1P DSI_D1M Revision 1.1...
  • Page 11 J17: COM1 & COM2 (Molex 53047-0610) UART2 is used as the U-Boot and O/S console, so UART1 or UART5 on J54 should normally be used for external connections. UART1/2 are mapped to /dev/ttymxc0 and /dev/ttymxc1 under Linux and COM1/2 under Windows Embedded.
  • Page 12 +1.5V I2C3_SCL PCIE_TXM I2C3_SDA PCIE_TXP USBDN_DM3 USBDN_DP3 +1.5V +3.3V J22: CAN Interface (Molex 53047-0310) Pin# Function CANH CANL J27: 2W Amplified Audio – Right Channel (Molex 53047-0210) Pin# Function OUTRP OUTRM J28: 2W Amplified Audio – Left Channel (Molex 53047-0210) Pin# Function OUTLP...
  • Page 13 5 Mounting The overall dimensions of the Nitrogen6_MAX board are 5.4” x 3.43” Revision 1.1...
