- Page 1 DS-220K ORDERCODE D1131...
- Page 2 Congratulations! You have bought a great, innovative product from DAP Audio. DAP Audio DS-220K brings excitement to any venue. Whether you want simple plug-&-play action or a sophisticated show, this product provides the effect you need. You can rely on DAP Audio, for more excellent audio products.
-
Page 3: Table Of Contents
Dap Audio Dap Audio DS-220K™ Product Guide Warning..................................Unpacking Instructions............................Safety-instructions..............................Return Procedure..............................Claims..................................Operating Determinations............................ Description................................... Overview................................. Frontview................................. Rearview................................. Remote Control..............................Installation..................................Set Up and Operation..............................Installing batteries..............................Operations................................... Preparation................................Normal Playback..............................Pause..................................Stop..................................Previous and Next..............................Fast Forward/Reverse............................ -
Page 4: Dap Audio
Dap Audio Dap Audio DS-220K™ Product Guide Connections................................Connecting a television set..........................Connecting a television set using an A/V cable....................Maintenance................................Troubleshooting................................Product Specifications............................... -
Page 5: Warning
Save the carton and all packing materials. In the event that a fixture must be returned to the factory, it is important that the fixture be returned in the original factory box and packing. Your shipment includes: • DAP DS-220K • Remote control • User manual •... - Page 6 IMPORTANT: The manufacturer will not accept liability for any resulting damages caused by the non- observance of this manual or any unauthorized modification to the system. Never let the power-cord come into contact with other cables! Handle the power-cord and all connections with the mains with particular caution! ...
-
Page 7: Return Procedure
Return Procedure Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued. Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility. Call Highlite 0031-455667723 or mail aftersales@highlite.nl and request an RMA prior to shipping the fixture. -
Page 8: Operating Determinations
OPERATING DETERMINATIONS This system is not designed for permanent operation. Consistent operation breaks will ensure that the system will serve you for a long time without defects. If this system is operated in any other way, than the one described in this manual, the product may suffer damages and the warranty becomes void. -
Page 9: Description
Description of the device Features The DAP-audio DS-220K is a 1U Karaoke DVD player LCD display with blue backlight Preview monitor Full control remote control unit Reverb effect unit 2 Adjustable mic inputs Overview Fig. 1... -
Page 10: Frontview
Frontview Fig. 2 1) Eject 14) Headphone Out 2) Power On/Off 15) Mic 1 Volume 3) Disc Slot 16) Mic 1 Input 4) Remote Sensor 17) Mic 2 Volume 5) LCD Display 18) Mic 2 Input 6) Play/Pause 19) Reverb Level 7) Mute 20) Remote Sensor 8) Repeat... -
Page 11: Remote Control
Remote Control Fig. 4 34) Standby 53) Up (Pitch) 35) Program 54) Open/Close 36) Display 55) Title 37) Repeat 56) Menu 38) A-B 57) Setup 39) 0-9 Keys 58) L/R 40) Audio 59) +10 41) Angle 60) Time 42) Slow 61) Zoom 43) Step 62) Subtitle... -
Page 12: Installation
Do not attempt to operate a 120V specification product on 230V power, or vice versa. Connections 1. Turn off the Power switch. 2. Connect the DS-220K to your amplifier using the proper cables. CAUTION: Be sure that the power is off, when connecting the cables. Installing batteries 1. -
Page 13: Operations
Operations 1. Preparation • When you want to watch a DVD film, switch the TV-set on and select the video input connected to the DVD player. • If you want to listen to audio via your audio installation, switch the audiosystem on and select the DVD player input. -
Page 14: Step
10. Step Press Step (43) to step a single frame/ picture forward during playback. Press Step (43) several times to step several frames/ pictures forward. Press Play/Pause (6, 68) to resume playback. 11. Time (search) Press Time (60) once, to view the search menu, press once more to cancel the function. In the search menu, use the Scroll up (22, 45), Scroll down (23, 67) and the 0-9 (39) buttons to make the desired choice. -
Page 15: Before Switching Off The Power
Before switching off the power When you have finished using the CD player. Press the Eject (1) or Open/Close (54) button. When the disc is completely ejected, take out the disc without using force. Now you can safely switch off the power. CAUTION: •... -
Page 16: System Setup
System Setup DVD Setup Menu When youpress the Setup (57) button, the setup menu will be displayed. You can select four tabs: A. General B. Audio C. Video D. Password E. Exit When you have entered the setup menu you can use the Scroll (21, 22, 23, 24/ 45, 46, 66, 67) buttons te navigate and select the desired item. - Page 17 2. Angle Mark When a DVD enabling multiple camera angles is used, the user can select a certain camera angle using the Angle (41) button on the remote control. However, the function must be activated first. The ANGLE MARK setting must be set to “ON” if you want the device to support multiple camera angles. 3.
-
Page 18: Audio Setup
6. Last Memory If last memory is activated, the DS-220K will remember the last track before switching off. As the unit is switched on again, it will resume playback at the last track played before switching off. B. Audio Setup Includes: 1. -
Page 19: Video Setup
In the Equalizer Setup menu you can select between Preset settings for Rock, Pop, Live, Dance, Techno, Classic, Soft or off. 3. 3d Processing The 3d Processing submenu allows you to select a Reverb effect. You can choose between 5 reverb modes or switch the reverb function off. -
Page 20: Password Setup
2. Panel Quality Allows you to adjust the sharpness, brightness, contrast and hue of the built in preview monitor. D. Password Setup Allows you to protect your system with a password. E. Exit Allows you to exit the setup menu. -
Page 21: Connections
Connections Connecting a television set Television Karaoke player Connecting a television set using an A/V- cable Television Karaoke player... -
Page 22: Maintenance
Maintenance DAP Audio-CD-Player DS-220K requires almost no maintenance. However, you should keep the unit clean. Disconnect the mains power supply, and then wipe the cover with a damp cloth. Do not immerse in liquid. Do not use alcohol or solvents. - Page 23 2010 Dap Audio.
