Summary of Contents for DAPAudio DVMP-250
- Page 1 MANUAL ENGLISH DVMP-250 Ordercode: D1133 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
-
Page 2: Table Of Contents
DVMP-250 Table of contents Warning ....................................2 Unpacking Instructions ............................. 2 Safety Instructions ..............................2 Operating Determinations ............................3 Connection with the mains ............................. 4 Return Procedure ..............................4 Claims ..................................4 Description of the device ..............................5 Overview ..................................5 Frontside .................................. -
Page 3: Warning
Save the carton and all packing materials. In the event that a fixture must be returned to the factory, it is important that the fixture be returned in the original factory box and packing. Your shipment includes: • DAP DVMP-250 • User manual •... -
Page 4: Operating Determinations
DVMP-250 IMPORTANT: The manufacturer will not accept liability for any resulting damages caused by the non-observance of this manual or any unauthorized modification to the system. Never let the power cord come into contact with other cables! Handle the power-cord and all connections with the mains with particular caution! ... -
Page 5: Connection With The Mains
DVMP-250 Connection with the mains Connect the device to the mains with the power-plug. Always pay attention, that the right color cable is connected to the right place. International EU Cable UK Cable US Cable BROWN YELLOW/COPPER FASE BLUE BLACK... -
Page 6: Description Of The Device
DVMP-250 Description of the device Features The DAP-audio DVMP-250 is a 2U Karaoke DVD player • Supports all common audio/video formats • Contains S-Video, TV, Component Video, VGA, HDMI and BNC video outputs • Balanced XLR audio outputs • 19” Rack mounts included •... -
Page 7: Frontside
DVMP-250 Frontside Fig. 02 Power switch R/L button Display IR Remote sensor Disc holder Source button LCD Display Play/pause button Direct access buttons Eject button Fast reverse button Return button Fast forward button Flat button Previous button Time button Phone input... -
Page 8: Remote Control
DVMP-250 Remote control Fig. 04 Source button Step button A-B button Sharp button (key control) Nor button (key control) Menu button N/P button OK button Eject button Cursor right button Flat button (key control) R/L button Cursor up button Return button... -
Page 9: Names And Functions
It is a 6,3 mm (1/4”) TRS socket, wired as Tip=left, Ring=right and sleeve = ground. Caution: Depending on the type of headphones connected to the Headphones jack, the DVMP-250 is capable of producing high output levels via the phones output. Therefore, make sure to turn the control all the way to the left (minimum setting) before connecting the headphones. - Page 10 DVMP-250 23/64) Video button Pushing this button allows you to switch between YUV, VGA and S-Video modes. 24/62) Next button Use this button to skip to a following track. 25) HDMI out Connect the input of a HDMI monitor to this output.
-
Page 11: Installation
Do not attempt to operate a 120V specification product on 230V power, or vice versa. Connections 01) Turn off the Power (01) switch. 02) Connect the DVMP-250 to your amplifier using the proper cables. CAUTION: Be sure that the power is off, when connecting the cables. Installing batteries 01) Remove the cover (73). -
Page 12: Operations
DVMP-250 Operations 01) Preparation • When you want to watch a DVD film, turn the TV-set on and select the video input connected to the DVD player. • If you want to listen to audio via your audio installation, turn the audio system on and select the DVD player input. -
Page 13: Program
DVMP-250 12) Program Push prog (65) to open the on screen program menu. • The DVMP-250 allows you to program up to 16 tracks/chapters. • Use the cursor (42/44/46/59) buttons to navigate through the menu. • Use the direct access (05/53) buttons to insert a desired track/chapter in the selected program number. -
Page 14: Before Switching Off The Power
DVMP-250 Before switching off the power When you have finished using the DVD player, before switching off the power, be sure that the disc holder (03) has been closed with the eject (17/40) button. CAUTION: • Do not forcibly close the disc holder when the power is off. -
Page 15: System Setup
DVMP-250 System Setup When you push the setup (43) button, the setup menu will be displayed. You can select five tabs: General Audio Dolby Video Preference When you have entered the setup menu you can use the cursor (42/44/46/59) buttons to navigate and select desired items. - Page 16 DVMP-250 Note: Available aspect ratios will be printed on the back of a DVD packaging. Some DVDs are recorded in cinema widescreen format (16:9) and others in standard format (4:3). Some DVDs are recorded in both formats and may thus feature the Pan Scan function. If available, the Pan Scan function will allow the 4:3 format to fill out the entire screen.
- Page 17 DVMP-250 04) Captions Use the cursor (42/44/46/59) buttons to switch the Captions function On or Off. 05) HDCD Use the cursor (42/44/46/59) buttons to set up the HDCD. Only works with HDCD media. Depending on the CD sound quality, there are three options which you can choose from: •...
-
Page 18: Audio Setup
Stereo: It is used when the unit is connected to a TV through a scart cable or when the unit is connected to a Dolby Pro Logic II receiver through stereo RCA cables. V(irtual) Surr(ound) With this option, the DVMP-250 widens the sound with a conventional two speaker setup. 5.1 CH Dolby 5.1 sound. - Page 19 Use the cursor (42/44/46/59) buttons and the OK (58) button to select between Spdif/Raw, Spdif/PCM or switch Spdif off. 03) Karaoke Setup The Karaoke setup is not functional on the DVMP-250, as the DVMP-250 has no microphone input. Ordercode: D1133...
- Page 20 DVMP-250 04) CH EQ Setup Use the cursor (42/44/46/59) buttons to select CH EQ Setup and push the OK (58) button to open the CH EQ Setup menu. This menu allows you to setup: • Preset EQ Type You can choose between Rock, Pop, Live, Dance, Techno, Classic, Soft or switch the EQ off.
-
Page 21: Dolby Setup
DVMP-250 This menu allows you to setup a preset reverb algorithm. Concert, Living Room, Hall, Bathroom, Cave, Arena, Church or switch the reverb effect off. Use the cursor (42/44/46/59) buttons to select and change parameters and push the OK (58) button to confirm. -
Page 22: Video Setup
DVMP-250 02) Dynamic Range To avoid disturbing the neighbours at night, you can use this function to reduce the sound effects volume without changing the original tone. Use the cursor (42/44/46/59) buttons to adjust the dynamic range between off and full. - Page 23 DVMP-250 02) TV Mode Use the cursor (42/44/46/59) buttons to select: • P-Scan • Interlace 03) Quality Use the cursor (42/44/46/59) buttons to select Quality and push the OK (58) button to open the Quality Setup menu. This menu allows you to setup: •...
- Page 24 DVMP-250 • Use the cursor (42/44/46/59) buttons to adjust hue between -9 and +9. Push the OK (58) button to store. • Saturation Use the cursor (42/44/46/59) buttons to adjust saturation between -9 and +9. Push the OK (58) button to store.
-
Page 25: Preference
DVMP-250 E. Preference This menu allows you to set up: 01) TV Type 02) Audio This menu item is not functional in this software version. Use a DVD disc’s menu to setup the language. 03) Subtitle This menu item is not functional in this software version. Use the title (52) button. - Page 26 Password Setup menu. This menu allows you to set up a password. 07) Default Use the cursor (42/44/46/59) buttons to select reset. Confirm your selection by pushing the OK (58) button. Now the DVMP-250’s default settings will be restored. Ordercode: D1133...
-
Page 27: Setup Examples
DVMP-250 Setup examples Connection of a television set Connection of a television set using an A/V-cable If your TV-set has an S-video input, the DVD-player can be connected with an S-video cable. If the TV set has no S-video input use an A/V cable. -
Page 28: Connection Of An Amplifier With Digital Audio Input And Tv-Set
Do not use a coaxial cable and an optical cable at the same time! Maintenance DAP Audio-CD-Player DVMP-250 requires almost no maintenance. However, you should keep the unit clean. Disconnect the mains power supply, and then wipe the cover with a damp cloth. Do not immerse in liquid. -
Page 29: Product Specifications
DVMP-250 Product Specifications Power supply: AC 100V-240V, 50/60 Hz Power consumption: 30 Watt S/N ratio: >85dB Frequency response: 20Hz – 20kHz THD: <0,01% Audio output: XLR 6dBv RCA 0dB Analog audio outputs: Unbalanced RCA Balanced XLR Digital audio outputs: Optical... -
Page 30: Notes
DVMP-250 Notes Ordercode: D1133... - Page 31 DVMP-250 Ordercode: D1133...
- Page 32 ©2014 DAP Audio...
