Boss BV9982I User Manual

Full ipod control in-dash dvd/mp3/cd am/fm receiver with motorized flip-out 7" (178mm) widescreen touchscreen digital tft monitor with dual (front and rear) usb, sd memory card port and front panel av input
Hide thumbs
Table of Contents

Advertisement

Quick Links

BV9982I
FULL iPod® CONTROL
IN-DASH DVD/MP3/CD AM/FM RECEIVER
WITH MOTORIZED FLIP-OUT 7" (178mm)
WIDESCREEN TOUCHSCREEN
DIGITAL TFT MONITOR
WITH DUAL (FRONT AND REAR) USB, SD MEMORY CARD PORT
AND FRONT PANEL AV INPUT
User's Manual
BV9982I
FULL iPod® CONTROL
IN-DASH DVD/MP3/CD AM/FM
RECEIVER WITH MOTORIZED
FLIP-OUT 7"
(178mm)
WIDESCREEN TOUCHSCREEN
DIGITAL TFT MONITOR
WITH DUAL (FRONT AND REAR) USB,
SD MEMORY CARD PORT AND
FRONT PANEL AV INPUT

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BV9982I and is the answer not in the manual?

Questions and answers

Related Manuals for Boss BV9982I

Summary of Contents for Boss BV9982I

  • Page 1 User’s Manual BV9982I FULL iPod® CONTROL IN-DASH DVD/MP3/CD AM/FM RECEIVER WITH MOTORIZED FLIP-OUT 7" (178mm) WIDESCREEN TOUCHSCREEN DIGITAL TFT MONITOR WITH DUAL (FRONT AND REAR) USB, SD MEMORY CARD PORT AND FRONT PANEL AV INPUT BV9982I FULL iPod® CONTROL IN-DASH DVD/MP3/CD AM/FM RECEIVER WITH MOTORIZED FLIP-OUT 7"...

  • Page 2: Class 1 Laser Product

    PRECAUTION WARNING: TO REDUCE THE CAUTION RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE RISK OF ELECTRIC SHOCK THIS APPLIANCE TO RAIN OR DO NOT OPEN MOISTURE. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
  • Page 3 1. Before Operation 1.1 Glossary PBC (playback control) This is a signal(menu) recorded on the disc with SVCD or VCD2.0 format used for the playback control. For discs containing PBC, It can playback interactive software with the menu displayed on monitor screen. If the disc contains still images, it can playback high definition still images.
  • Page 4 1.3 Maintenance and Cleaning of Discs Disc Maintenance 1. To keep the disc clean, andle the disc by its edge, do not touch the disc surface of the play side. 2. Do not stick paper or tape on the disc. If there is glue or dirt on the disc surface, you must wipe it off before using.

  • Page 5: Remote Control Description

    1.5 Remote Control Description 1. ANG BUTTON 2. MENU BUTTON 3. POWER BUTTON 4. ^ BUTTON 5. >>| BUTTON 6. > BUTTON 7. |<< BUTTON 8. v BUTTON 9. SEL BUTTON 10. PLAY/PAUSE BUTTON 11. NUMBER(0~10,+10 -10) BUTTONS 12. 10+/PTY BUTTON 13.
  • Page 6 1.6 Locations and Names of Controls on or in the unit B V998 2I Front Panel SD/MMC The Front Facet after removing the front panel 1. OPEN button 13. INT/2 button 2. POWER/MUTE button 14. RPT/3 button 3. Monitor 15. RDM/4 button 4.

  • Page 7: Wires Connection Description

    1.7 Wires Connection Description Description of Wires Connection Wiring Connecting Socket 1 Fixing Screw Bolt GREEN PARKING LINE Wiring Connecting Socket 2 Radio Antenna jack Black Black WHITE REVERSAL LINE Black USB LINE IN 1. Parking wire must be connected. And the parking brake must be engaged in order for the monitor to work. 2.

  • Page 8: Unit Installation

    1.8 UNIT INSTALLATION INSTALLATION INSTRUCTIONS This is an anti-theft installation method. The main unit has a METAL MOUNTING SLEEVE. Please connect the wiring, eg, the Power supply, the Speakers and the Antenna according to the requirements of this Instruction Manual, then install the metal mounting sleeve into the car as per the diagram illustrated below.
  • Page 9 2. Common Operation 1. To turn on/off the unit In power off mode, briefly press the POWER button to turn on the unit. In power on mode,press and hold the POWER button on the front panel, or briefly press the POWER button on the remote control to turn off the unit. 2.

  • Page 10: Band Button

    11.To do setup To do setup, tap the icon in the Main Menu to turn to SETUP interface as right. In the interface, select one of GENERAL, TIME, AUDIO, VIDEO ,RADIO , CALIBRATE by tapping them, then set them by tapping some icons on the right side accordingly. GENERAL SETUP 3.
  • Page 11 5. PRESET STATION [ 1-6 ] BUTTONS In RADIO mode: 1) To memorize the current frequency on the current band, press and hold any one of the six preset buttons (1-6) on remote control or rotate number knob and press and hold . 2) To recall the preset memory on the current band, press one of the preset buttons [1-6] on remote control or rotate number knob and press it .
  • Page 12 When the AF switching mode is selected, the radio checks the signal strength of the AF all the time. The interval of checking time of each AFs depends on the signal strength of the current station, from a few minute for the strong station to a few seconds for the weak station.
  • Page 13 3. Display control icons When displaying i Pod playback, tap icon to turn to control icons as right. Tapping the direction icon to select the play function such as : PLAYLISTS, ARTISTS, ALBUMS, GENRES, SONGS, COMPOSERS, REPEAT and so on. Control icons 4.
  • Page 14 : Tap it to pause playback : Tap it to stop playback . :Tapping one of them can switch on between the speed levels of fast backward or forward. (Except image mode.) : Tapping one of them can select next or Root interface for MUSIC previous chapter/track.
  • Page 15 5.2 Pause Playback When playing DVD/VCD/CD/MP3/WMA content , press the PAUSE button on IR remote controller to pause the playback, press the PLAY button to resume normal playback. 5.3 Stop Playback When playing DVD/VCD/MP3/WMA/CD content , press the STOP button once to pause the playback, then press the PLAY button to resume the normal playback;...
  • Page 16 Press the direction buttons to select your desired title, and then press the OK or PLAY button to open the root menu of the selected title. Press the direction buttons to select your desired chapter, finally press the OK or PLAY button to play the selected chapter. During playback, pressing the MENU button can directly display the root menu of the title that is playing.
  • Page 17 During slow forward, press the PLAY button to resume normal playback. The function is only for video. 5.9 Display still frame step by step If the unit is currently playing video, press the TEL button consecutively to display still frame step by step. Press the PLAY button to resume normal playback.
  • Page 18 5.11 Playback in Scan Mode 1. When playing VCD(PBC OFF)/CD discs , press the INT button to play the previous 15 seconds part of each track on the disc. Press the INT button again to resume normal playback. 2. When playing DVD/MP3/WMA sources , the INT button is not available. 5.12 Playback from a specified chapter/track or a specified time 1.
  • Page 19 ZOOMx2,ZOOMx3,ZOOMx4,ZOOMx1/2,ZOOMx1/3,ZOOMx1/4,ZOOM OFF. Press one of the ^/v/>/< buttons to select the area you want to enlarge. 5.16 Change the Caption Language When playing DVD's ,press the SUBTITLE button repeatedly to select the language of the caption or turn off the caption.(depend on the media used.) When playing VCD/MP3/WMA/CD discs,the buttons are not available.
  • Page 20 5.19 Program Playback It allows you to enter the order in which you want some chapters/tracks in DVD/VCD/MP3/WMA/CD to play. 1 During playback, press the PROG button to enter a program interface as follows: 2 Use the direction buttons to move cursor onto the desired place for inputting the sequence number.
  • Page 21 When you select the IMAGE file sort icon, press the ^ or > button to select the first IMAGE file, then press the v button to select the desired IMAGE file, finally press the OK or PLAY/PAUSE button to display the image in full screen from the selected IMAGE file.

  • Page 22: System Setup

    2. There are 6 setup pages in all for the System Menu. Press the > or < button to select an desired setup page. 3. Press the ^ or v button to select an setup item in the selected setup page. 4.

  • Page 23: Language Setup

    5.23.2 LANGUAGE SETUP OSD LANGUAGE This item is for selecting the language of the SYSTEM MENU and all operating prompt interface displayed during playback. AUDIO LANG This item is for selecting a audio language. SUBTITLE LANG This item is for selecting a subtitle language. MENU LANG This item is for selecting a disc menu language.

  • Page 24: Speaker Setup

    5.23.5 SPEAKER SETUP DOWNMIX This is for selecting your desired sound effect when there is no center speaker and subwoofer. There are 3 modes: LT/RT, STEREO, VSS. LT/RT: When playing a disc with PRO LOGIC stereo effect, choose the item, so it will output audio signal with vivid theatre effect.
  • Page 25 * Parental Control Q:Why after inserting DVD disc in the disc slot, a dialogue window appears that asks to input a 4 digits password ? A:This is because the movie you are playing is rated with the Parental Control, and the current rating level of DVD player is lower than the current disc.
  • Page 26 Region Code Q: Why does the unit display REGION ERROR after inserting disc into disc compartment ? A: Because the DVD player and disc has respective region code. If the region codes of them do not match with each other, the DVD player can not play the disc.

  • Page 27: Troubleshooting

    6. Trouble Shooting Please read the user ’s manual carefully before using the DVD player. If you have any troubles in using this player, try to solve the problems by the suggestions mentioned below. If you can not remove the trouble after using all the suggestions, please contact the company or the technical servic e center authorized by us .
  • Page 28 Frequency Response......20Hz ~ 20KHz(at 1KHz 0 dB) ≥ S/N Ratio(Audio)..........90dB (at 1KHz 0 dB) Separation................50dB Radio Specification FM Section Frequency range........87.5MHz - 107.9MHz(US) 87.5MHz - 108.0MHz(EU) Usable sensitivity..............3uV I.F Frequency..............10.7MHz AM Section Frequency............530KHz - 1710KHz(US) 522KHz - 1620KHz(EU) CAR AUDIO SYSTEMS BOSS AUDIO CAR STEREOS...
