  • Page 1 STEPHEN TECHNOLOGIES CO.,LIMITED SVG500SO 1 FXS + 1 FXO SIP VoIP ATA User Manual SVG500SO 1 FXS + 1 FXO Port SIP VoIP ATA User Manual...

  • Page 2: Table Of Contents

    STEPHEN TECHNOLOGIES CO.,LIMITED SVG500SO 1 FXS + 1 FXO SIP VoIP ATA User Manual Introduction ..........................3 Hardware Overview ......................3 Software Overview ......................3 IVR Interface for The TA ....................... 4 Setup the TA by Web Browser ...................... 4 Login ..........................

  • Page 3: Introduction

    SVG500SO 1 FXS + 1 FXO SIP VoIP ATA User Manual Introduction This user’s manual is for SVG500SO VoIP terminal adapter (TA). This user’s manual will explain the IVR instruction, web configuration and command line configuration for the TA. Before using the TA, some setup processes are required to make the TA work properly.

  • Page 4: Ivr Interface For The Ta

    STEPHEN TECHNOLOGIES CO.,LIMITED SVG500SO 1 FXS + 1 FXO SIP VoIP ATA User Manual IVR Interface for The TA You can use the PSTN phone to configure the TA. Please follow the instruction to configure your terminal adapter. Group IVR Action...

  • Page 5: System Information

    STEPHEN TECHNOLOGIES CO.,LIMITED SVG500SO 1 FXS + 1 FXO SIP VoIP ATA User Manual 2. For normal user, the username is: user; and the password is: test. If you use this account to login, but you can not configure the SIP setting.

  • Page 6: Phone Settings

    STEPHEN TECHNOLOGIES CO.,LIMITED SVG500SO 1 FXS + 1 FXO SIP VoIP ATA User Manual 3.3.1.2 To delete a group of number, first select the number, and then click “Delete Selected” button to delete selected number. 3.3.1.3 To delete all number, click “Delete All” button, a dialogue window will show up. Click OK button to delete all numbers.
  • Page 7 STEPHEN TECHNOLOGIES CO.,LIMITED SVG500SO 1 FXS + 1 FXO SIP VoIP ATA User Manual 3.4.2 SNTP Settings: you can setup the primary and secondary SNTP Server to get the date/time information. Also you can base on your location to set the Time Zone, and how long is needed to synchronize. When you finished the setting, please click the Submit button.
  • Page 8 STEPHEN TECHNOLOGIES CO.,LIMITED SVG500SO 1 FXS + 1 FXO SIP VoIP ATA User Manual 3.4.5 Auto Answer function: You can set the Auto Answer function to answer the incoming call by the phone. If the call is come from the IP, then the TA can let user to redial the call to PSTN phone number. If the call is coming from PSTN, then the TA can let user to redial to IP Phone number.
  • Page 9 STEPHEN TECHNOLOGIES CO.,LIMITED SVG500SO 1 FXS + 1 FXO SIP VoIP ATA User Manual Example 1: Drop prefix: No; Replace rule 1: 002, 8613+8662 When your dialed number beginns with 8613 or 8662, 002 will be added to the beginning of your dialed number.

  • Page 10: Network

    STEPHEN TECHNOLOGIES CO.,LIMITED SVG500SO 1 FXS + 1 FXO SIP VoIP ATA User Manual 3.4.10 T.38(Fax) Setting: Enable/disable the fax function and set fax port. 3.4.11 Hot line setting If enabled, when you lift handset, the hot line number will be dialed out automatically.
  • Page 11 STEPHEN TECHNOLOGIES CO.,LIMITED SVG500SO 1 FXS + 1 FXO SIP VoIP ATA User Manual 3.5.1 Network Status: You can check the current Network setting in this page. 3.5.2 WAN Settings 3.5.2.1 Bridge settings: Enable/disable bridge mode. If you set the Bridge On, then the two Fast Ethernet ports will be transparent 3.5.2.2...
  • Page 12 STEPHEN TECHNOLOGIES CO.,LIMITED SVG500SO 1 FXS + 1 FXO SIP VoIP ATA User Manual 3.5.3 LAN Settings: Set network parameters for LAN.You may refer to your current network environment to configure the TA properly. When you finished the setting, please click the Submit button.
  • Page 13 STEPHEN TECHNOLOGIES CO.,LIMITED SVG500SO 1 FXS + 1 FXO SIP VoIP ATA User Manual 3.5.5 VLAN Settings 3.5.6 DMZ setting 3.5.7 Virtual Server...

  • Page 14: Sip Settings

    STEPHEN TECHNOLOGIES CO.,LIMITED SVG500SO 1 FXS + 1 FXO SIP VoIP ATA User Manual SIP Settings In SIP Settings you can setup the Service Domain, Port Settings, Codec Settings, Codec ID Setting, DTMF Setting, RPort Setting and Other Settings. If the VoIP service is provided by ISP, you have to setup the related informations correctly so that you can register to the SIP Proxy Server successfully.
  • Page 15 STEPHEN TECHNOLOGIES CO.,LIMITED SVG500SO 1 FXS + 1 FXO SIP VoIP ATA User Manual 3.6.2 Port Settings: you can setup the SIP and RTP port number in this page. Each ISP provider will have different SIP/RTPport setting, please refer to the ISP to setup the port number correctly. When you finished the setting, please click the Submit button.
  • Page 16 STEPHEN TECHNOLOGIES CO.,LIMITED SVG500SO 1 FXS + 1 FXO SIP VoIP ATA User Manual 3.6.4 Codec ID Setting: Sometimes 2 VoIP devices with different Codec ID will cause some problems. If there are some problems when you are talking with others, you may ask the other one what Codec ID he is useing, and change your Codec ID to the same as his.

  • Page 17: Nat Trans

    STEPHEN TECHNOLOGIES CO.,LIMITED SVG500SO 1 FXS + 1 FXO SIP VoIP ATA User Manual 3.6.7 Other Settings: you can setup the Hold by RFC, Voice/SIP QoS and SIP expire time in this page. To change these settings please following your ISP’s information. The QoS setting is to set the voice packets’...

  • Page 18: Others

    STEPHEN TECHNOLOGIES CO.,LIMITED SVG500SO 1 FXS + 1 FXO SIP VoIP ATA User Manual Others 3.8.1 Auto Config: Please set these according to your need. 3.8.2 FXO & FXS Port: Please set this according to your country’s standard. 3.8.3 MAC Clone Setting: Enable/disable MAC Clone.

  • Page 19: System Auth

    STEPHEN TECHNOLOGIES CO.,LIMITED SVG500SO 1 FXS + 1 FXO SIP VoIP ATA User Manual 3.8.4 Tones Settings 3.8.5 Advanced Settings System Auth. In System Authority you can change your login name and password. When you finished the setting, please click the Submit button.

  • Page 20: Save Change

    STEPHEN TECHNOLOGIES CO.,LIMITED SVG500SO 1 FXS + 1 FXO SIP VoIP ATA User Manual 3.10 Save Change In Save Change you can save the changes you have made. If you want to make new setting into effect, You have to click the Save button. After you click the Save button, the TA will automatically restart and the new setting will take effect.

  • Page 21: Reboot

    STEPHEN TECHNOLOGIES CO.,LIMITED SVG500SO 1 FXS + 1 FXO SIP VoIP ATA User Manual 3.11.2 Auto Update 3.11.3 In Default Setting you can restore the TA to factory settings in this page. You can just click the Restore button, then the TA will restore to default and automatically restart.

  • Page 22: Configuration

    STEPHEN TECHNOLOGIES CO.,LIMITED SVG500SO 1 FXS + 1 FXO SIP VoIP ATA User Manual Configuration Open the hyper terminal window, input a connection name and click “OK” button. Select TCP/IP(WinSock) in “Connect using” field, input TA’s IP in “Host address” field, “Port number” use the default value 23.
  • Page 23 STEPHEN TECHNOLOGIES CO.,LIMITED SVG500SO 1 FXS + 1 FXO SIP VoIP ATA User Manual update Update Flash Code/RAM auth Change User Name and Password NAT Configuration DNS Configuration ping ping [-lN] [IP-addr|host-name] SIP Configuration ddns DDNS Configuration sntp SNTP Configuration...
  • Page 24 STEPHEN TECHNOLOGIES CO.,LIMITED SVG500SO 1 FXS + 1 FXO SIP VoIP ATA User Manual -dhcps DHCP Server Setting -ddns Set DDNS -bridge Set Bridge -dev0 Set Device 0 Setting -dev1 Set Device 1 Setting -dev2 Set Device 2 Setting (null) Show Interface Setting 4.2.1.4...
  • Page 25 STEPHEN TECHNOLOGIES CO.,LIMITED SVG500SO 1 FXS + 1 FXO SIP VoIP ATA User Manual -norm3 Change Normal user3 user name/password -norm4 Change Normal user4 user name/password -ppp Change PPP user name/password (null) Show auth Setting If you want to change the password, you need to type the password twice in the CLI.
  • Page 26 STEPHEN TECHNOLOGIES CO.,LIMITED SVG500SO 1 FXS + 1 FXO SIP VoIP ATA User Manual (null) Show SIP Setting 4.2.1.14 ddns function Itno Command Description Show ' ddns' Option -type Set DDNS Type -host Set Host Name -wild Set Wild Card Mode...

  • Page 27: How To Make A Phone Call

    STEPHEN TECHNOLOGIES CO.,LIMITED SVG500SO 1 FXS + 1 FXO SIP VoIP ATA User Manual 4.2.1.21 reload function is to Reload Factory Setting, please make sure you want to do the factory reset. 4.2.1.22 watchdog function Itno Command Description Show ' WatchDog' Option...

  • Page 28: Dial A Pstn Phone Call

    Stephen Technologies Co.,Limited. Disclaimer Notice: No license is granted, implied or otherwise, under any patent or patent rights of Stephen Technologies Co.,LTD. Stephen Technologies Co.,LTD, makes no warranties, implied or otherwise, in regard to this document and to the products described in this document.
