- Page 1 SVG200SP+ 1 FXS+1 PSTN SIP/IAX ATA User Manual SVG200SP+ 1 FXS + 1 PSTN SIP/IAX ATA User Manual STEPHEN TECHNOLOGIES CO.,LIMITED ALL RIGHTS RESERVED 陈 泽 科 技 有 限 公 司 1 / 36 www.stephen-tele.com...
-
Page 2: Table Of Contents
Network Diagnosis ....................29 Restore to factory default ..................29 POST Mode(safe mode) ..................30 FAQ ........................30 How many SIP servers may SVG200SP+ register simultaneously? ........30 陈 泽 科 技 有 限 公 司 2 / 36 www.stephen-tele.com... - Page 3 How to use speed dial function? ..................32 How to configure digital map? ..................32 How to use Call Forward, Call Transfer and 3-way Conference calls? ......32 VLAN implement ......................33 陈 泽 科 技 有 限 公 司 3 / 36 www.stephen-tele.com...
-
Page 4: Svg200Sp+ Features
Speciality of electric: output the 12V 500mA DC The network connects:2 RJ45 connect, a WAN, a LAN FXS: 2 port Software Support two sip servers running at the same time. Back-up sip server support. 陈 泽 科 技 有 限 公 司 4 / 36 www.stephen-tele.com... -
Page 5: Standard And Protocols
HTTP: Hyper Text Transfer protocol FTP: File Transfer protocol RFC 3362 ： T .38 protocol Compliant Standards E N55024,EN55022 ： FCC part15 comply with ROHS in EU comply with ROHS in China 陈 泽 科 技 有 限 公 司 5 / 36 www.stephen-tele.com... -
Page 6: Operating Requirement
Storage temperature: -30° to 65° C (-22° to 149° F) Humidity: 10 to 90% no dew Package Size 128 x 85 x 30 mm Packing List SVG200SP+ ATA Power adaptor (12v, 500mA) Manual CD 陈 泽 科 技 有 限 公 司 6 / 36 www.stephen-tele.com... -
Page 7: Installation
Enter SVG200SP+ IP address in the web browser and press ENTER to go to the log on page, and key in the username and password to access SVG200SP+ setting page. Default username and password is: Administrator: Username: admin password: admin User: Username: guest Username: guest 陈 泽 科 技 有 限 公 司 7 / 36 www.stephen-tele.com... -
Page 8: Current State
SIP and IAX2, you can see whether SVG200SP+ has registered the public sip server and IAX2 server. Phone Number shows the public sip server, the private sip server and the IAX2 server phone numbers. 陈 泽 科 技 有 限 公 司 8 / 36 www.stephen-tele.com... -
Page 9: Network
Notice: If user accesses the gateway through WAN port. He should use the new IP address to access the gateway when the WAN port address was changed. 陈 泽 科 技 有 限 公 司 9 / 36 www.stephen-tele.com... -
Page 10: Lan Config
) Proxy Server Port: Signal port of SIP proxy Proxy Username: proxy server username Proxy Password: proxy server password 陈 泽 科 技 有 限 公 司 10 / 36 www.stephen-tele.com... -
Page 11: Iax2 Config
ATA , then you use the number to stand for your username Voice mail text: if IAX support voice mail, config the domain name of your mail box here. 陈 泽 科 技 有 限 公 司 11 / 36 www.stephen-tele.com... - Page 12 Enable Register: enable or disable register IAX(Default Protocol): Set IAX 2 as the default protocol , if not the system will choose SIP as default Enable G.729: Using G.729 speech coding mandatory consultations 陈 泽 科 技 有 限 公 司 12 / 36 www.stephen-tele.com...
-
Page 13: Advance
Gateway: Default gateway of lease table DNS: default DNS server of lease table. Notice: This setting won’t take effect unless you save the config and reboot the device 陈 泽 科 技 有 限 公 司 13 / 36 www.stephen-tele.com... -
Page 14: Nat
LAN device port for port mapping. Outside Port: WAN port for port mapping. Click Add to add new port mapping item and Delete to delete current port mapping item. 陈 泽 科 技 有 限 公 司 14 / 36 www.stephen-tele.com... -
Page 15: Net Service
If you need to change telnet port or HTTP port, please use the port greater than 1024, because ports under 1024 is system remain ports. HTTP service if HTTP is set to 0. 陈 泽 科 技 有 限 公 司 15 / 36 www.stephen-tele.com... -
Page 16: Qos Settings
Data/Voice DiffServ differentiated --- undifferentiated for Date and voice VLAN is not distinction VLAN tag, Tag differentiated for Date and Voice VLAN is distinction VLAN tag, Date untagged for Date VLAN is distinction VLAN tag Please refer to VLAN implement for detail 陈 泽 科 技 有 限 公 司 16 / 36 www.stephen-tele.com... -
Page 17: Advance Sip Settings
User can register two sip servers: public sip server and private sip server. these two sip servers are independent from each other and running in the same time. For how to configure private sip server. Please refer to sip configuration. 陈 泽 科 技 有 限 公 司 17 / 36 www.stephen-tele.com... -
Page 18: Digital Map
9xxxxxxx 8 digits numbers begin with 9 will be sent immediately. Number 911 will be sent will be immediately 99xT4 3 digits numbers begin with 99 with be sent after four seconds. 陈 泽 科 技 有 限 公 司 18 / 36 www.stephen-tele.com... -
Page 19: Call Service Settings
MMI filter is used to make access limit to SVG200SP+ Gateway. When MMI filter is enable. Only IP address within the start IP and end IP can access SVG200SP+ gateway. 陈 泽 科 技 有 限 公 司 19 / 36 www.stephen-tele.com... -
Page 20: Audio Settings
VPN Server Addr ： ： ： ： register to the address of VPN server 。 VPN Server Port ： ： ： ： Register to the port of VPN server 陈 泽 科 技 有 限 公 司 20 / 36 www.stephen-tele.com... -
Page 21: Dial-Peer Settings
Clear Config: restore to default settings. Notice: clear config in admin mode, all settings restores to factory default; clear config in guest modem, all settings except sip, advance sip restore to factory default. 陈 泽 科 技 有 限 公 司 21 / 36 www.stephen-tele.com... -
Page 22: Update
Config Encrypt Key: The encrypt key of confirmation file Protocol Type: The protocol type that used for upgrading Update Interval Time: The interval time that the terminals search for new configuration file. 陈 泽 科 技 有 限 公 司 22 / 36 www.stephen-tele.com... - Page 23 Gateway original version is: <<VOIP CONFIG FILE>>Version:1.0000 <GLOBLE CONFIG MODULE> ConfFile Version ： User may edit the configure file version to: <<VOIP CONFIG FILE>>Version:1.0007 <GLOBLE CONFIG MODULE> ConfFile Version ： 陈 泽 科 技 有 限 公 司 23 / 36 www.stephen-tele.com...
-
Page 24: System Manage
MGR Log Level: set the MGR log level SIP Log Level: set the SIP log level IAX2 Log Level: set the IAX2 log level Please click “apply” after setting 陈 泽 科 技 有 限 公 司 24 / 36 www.stephen-tele.com... -
Page 25: Time Set
Daylight: Daylight Saving time 2.8.4 Logout&Reboot Reboot Gateway, some setting needs to reboot to make it works. Please always save config before reboot, otherwise the setting will return to previous setting. 陈 泽 科 技 有 限 公 司 25 / 36 www.stephen-tele.com... -
Page 26: Ivr Setting
/*change to router mode*/ "#*50192.168.1.117" set WAN port IP address "#*51192.168.1.1" set default gateway IP "#*52202.112.10.37" set dns server "#*53255.255.255.0” set netmask, use 255.255.255.0 if no be set 陈 泽 科 技 有 限 公 司 26 / 36 www.stephen-tele.com... -
Page 27: Telnet Console
There are two types in command parameters: optional and required. “required” parameter use “-” as prefix and “optional” use “_” as prefix. User may type “-” or “_” then press TAB button for complementarily. 陈 泽 科 技 有 限 公 司 27 / 36 www.stephen-tele.com... -
Page 28: Global Command
Function Example exit Return to parent-node #exit logout Exit #logout ping Ping command, use to check network, #ping www.stephen-tele.com write Save setting to flash #write 4.3 Tree Structure 4.3.1 Debug (Level 0~7) path: <debug># show debug setting ---show [disable]enable debug all modules... -
Page 29: Network Diagnosis
There are some telnet commands for checking your network. Now Listing below for your information Command Function Example ping Check if the destination is accessible #ping www.stephen-tele.com tracert Show network path info #tracert www.stephen-tele.com show basic Show network settings #show basic... -
Page 30: Post Mode(Safe Mode)
Then when you want to place a PSTN calls, you can first press * to switch to the PSTN line and then place your call as you normal do. Why the settings vanish after reboot? Please go to Config Manage Save Config to save your setting always. 陈 泽 科 技 有 限 公 司 30 / 36 www.stephen-tele.com... -
Page 31: How To Use The Dial Rule
Digital Map. (Refer “How to use SVG200SP+’s Lifeline Function?”) 179 rule: when you dial 179 , the call with send to 192.168.1.179, suit for LAN application without set up a sip server. 陈 泽 科 技 有 限 公 司 31 / 36 www.stephen-tele.com... -
Page 32: How To Use Speed Dial Function
If A is the SVG200SP+ user, and B calls and talking with A through VoIP. A can press the Hook-Flash to hold the call with B, and then press * and then enter C’s number. B will be transferred to C and can talk with C. 陈 泽 科 技 有 限 公 司 32 / 36 www.stephen-tele.com... -
Page 33: Vlan Implement
“Data/Voice VLAN differentiated” is undifferentiated. Device will set the same vlan ID for voice and data. As show below if “Data/Voice VLAN differentiated” is Tag differentiated but the DiffServ is disable. Device won’t distinguish the voice, 陈 泽 科 技 有 限 公 司 33 / 36 www.stephen-tele.com... - Page 34 3. if “Data/Voice VLAN differentiated” is Tag differentiated and diffServ are both enable. Then device will distinguish the voice, signaling and data stream to VLAN ID setting. As below: 陈 泽 科 技 有 限 公 司 34 / 36 www.stephen-tele.com...
- Page 35 VLAN ID. If “VLAN ID check” is disable, SVG200SP+ will handle the packets even from different vlan ID. Please notice that VLAN ID check is enable in default. 陈 泽 科 技 有 限 公 司 35 / 36 www.stephen-tele.com...
-
Page 36: Copyright Notice
Stephen Technologies Co.,Limited. Disclaimer Notice: No license is granted, implied or otherwise, under any patent or patent rights of Stephen Technologies Co.,Limited. Stephen Technologies Co.,Limited, makes no warranties, implied or otherwise, in regard to this document and to the products described in this document.
