FEATURES

TRIGGER
ROTATING
REAR
HANDLE
CORD
RETAINER
KNOW YOUR STRING TIMMER (See Fig. 1)
The safe use of this product requires an understanding of the information on the tool and in this
operator's manual as well as a knowledge of the project you are attempting. Before use of this
product, familiarize yourself with all operating features and safety rules.
CORD RETAINER
A convenient cord retainer helps keep the extension cord connection secure during string
EDGER GUIDE
The easily mounted edger guide allows the string trimmer to perform as an edger.
FRONT HANDLE
The string trimmer is equipped with a front handle assembly for ease of operation and to prevent
loss of control.
GRASS DEFLECTOR
The trimmer includes a grass deflector that helps protect from flying debris.
The rotating rear handle on the string trimmer can be locked in two different positions for ease of
use when edging.
The string trimmer can be adjusted to different extension points for ease of use.
ADJUSTABLE
FRONT HANDLE
SWITCH
TELESCOPING
BOOM COUPLER
Edging COUPLER
TELESCOPING
SHAFT
GRASS
DEFLECTOR
1
EDGE GUIDE
Fig. 1
trimmer

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the String Trimmer and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Menards String Trimmer

  • Page 1 GRASS DEFLECTOR The trimmer includes a grass deflector that helps protect from flying debris. ROTATING REAR HANDLE The rotating rear handle on the string trimmer can be locked in two different positions for ease of use when edging. TELESCOPING BOOM...
  • Page 2 ASSEMBLY UNPACKING • This product requires assembly. • Carefully remove the product and any accessories from the box. Make sure that all items listed in the packing list are included. • Inspect the product carefully to make sure no breakage or damage occurred during shipping. •...
  • Page 3 STARTING/STOPPING THE TRIMMER (See Fig. 4 - 5.) • Attach the outlet end of an extension cord to the plug on the rear of the string trimmer. NOTE: Use only approved outdoor extension cords.
  • Page 4 PROPER OPERATING POSITION Fig. 6 FOLLOW THESE TIPS WHEN USING THE STRING TRIMMER: • Hold the trimmer with your right hand on the rear handle and your left hand on the front handle. • Keep a firm grip with both hands while in operation.
  • Page 5 OPERATION W A R N I N G Always hold the string trimmer away from the body keeping clearance between the body and the string trimmer. Any contact with the string trimmer cutting head while operating can result in serious personal injury.
  • Page 6 • Keep the trimmer tilted toward the area being cut; this is the best cutting area. • The string trimmer cuts when passing the unit from left to right. This will avoid throwing debris at the operator. Avoid cutting in the dangerous area shown in figure 8.
  • Page 7 OPERATION ROTATING REAR HANDLE TELESCOPING BOOM COUPLER PULL UP EDGING COUPLER TO ROTATE Fig. 8 Fig. 9 EDGING (See Fig. 9 - 11.) The rotating handle can be used in combination with the edger guide for edging sidewalks and walkways. To use the edger guide, flip down from it’s stored position. EDGER GUIDE Fig.
