Page 1: Lcd Display
32 LCD DISPLAY Operating Instructions... -
Page 2: Table Of Contents
Dear customer Thank you for selecting the high-definition TFT LCD Color TV. Before operating the set, please read this Operating Instructions carefully. In order to use and maintain the set better, please follow its operating instructions. Thank you for your cooperation. Table of Contents Main features and functions ------------------------------------------------------------------------... -
Page 3: Main Features And Functions
I. Main features and functions No radiation, low flicker and low power consumption. It is an environment-protective and power-saving product. Light weight, small cubage, dual-purpose usage of wall-mounting and desk-top. Beautiful appearance, innovative type, simple operation and convenient usage. With dual-function of TV receiver and computer monitor. With multiway inputs: Video, S-Video, AV Scart,Scart RGB,DTV(YPbPr), Component(YCbCr) and analog RGB(PC) . -
Page 4: Specifications
III. Specifications Screen Size 31.51 inch (diagonal) Display Resolution 1366 768 Aspect Ratio of Screen 16:9 =88 (CR 10) Horizontal angle =88 (CR 10) Vertical angle Max. Visual Angle Power Supply 160~240V AC 50/60Hz TV Received Signal 48.25MHz-168.25MHz 175.25MHz-463.25MHz 471.25MHz-855.25MHz Broadcast Signal System PAL B/G,I,D/K, SECAM L, B/G, D/K YPbPr (480p,576p,720p,1080i)/YCbCr(480i,576i) (HDTV support... -
Page 5: Operating System Diagram
V. Operating system diagram Front view Stand-by switch Remote sensor Description of basic control button Power indicator Control button The function during watching The function when using the menu Select the screen display Enter or select menu MENU menu system Select to display the next Select the previous menu/ item stored channel... - Page 6 Rear view Power Switch SCART 2Input/Output Component Video Input/HD Video Input Antenna Input (Decoder) Pb/Cb Pr/Cr AC IN PC IN S-VIDEO SCART AIR/CABLE SCART2 PC AUDIO AUDIO AUDIO VIDEO 1 Power Input SCART Input/Output PC Input PC Input Video Input1 (Decoder) Audio Out Audio Input...
-
Page 7: Mount Up The Base
VI. Mount up the base Mount up the base (1)Put the TV on a table face down. (2)Take out the base and fasten it to the TV with 4 M5 20 screws(black). The Screw holes are as show on fig.1. The TV and the connecting face of the base can be rotated together. -
Page 8: Connection For External Video And Audio Equipment
VII. Connection for external video and audio equipment POWER AMPLIFIER DVD& SET-TOP BOX AUDIO OUT AUDIO IN AUDIO AIR/CABLE DVD&VCD AUDIO VIDEO S-VIDEO AUDIO OUT DVD& SET-TOP BOX AUDIO OUT S-VIDEO VIDEO AUDIO AUDIO OUT Use proper signal Cables to connect outputs of signal sources and inputs of the unit correspondingly. Make sure of good contact. -
Page 9: Preparation For Switch On
VIII. Preparation for switch on 1.Install the battery for the remote controller a. Press the cover of the battery compartment on the b ack of the remote controller and remove it. b. Insert 2 AAA batteries, make sure the polarity (+) or (-) of batteries conforms to the polarity marks in the battery compartment. -
Page 10: Basic Operation
IX. Basic operation 1. Power on / off operation. Insert one plug of the AC Power Cord in the jack of Power Input of the unit. Insert the other plug of AC Power Cord to the suitable AC power socket with grounding. Then switch on the Power switch of this unit. The red light of Power Indicator will be bright and the unit enter upon the stand-by status. - Page 11 press V+ or V- button to adjust program number. Press P+ or P- button to select BAND item. MANUAL SCAN Press V+ or V- button to select V/UHF or CABLE. Press P+ or P- button to select CHANNEL item. SYSTEM Press V+, V- or digital button to select channel number.
-
Page 12: How To Adjust The Image Effect
6 How to use the function of teletext Start-up Press TEXT button on the remote controller and the image (f) will appear on the screen. It means that the DATA function of teletext starts. Press TEXT button on the remote controller repeatedly and the image of teletext will change accordingly. -
Page 13: The Adjustment Of Misc
VOLUME change the sound volume EQUALIZER BALANCE change the balance of the left sound track 120Hz and right sound track ( 0 is the balance point) 500Hz 1.5KHz SOUND MODE: Normal Cinema News Flat User 5KHz 10KHz Normal SPATIAL ( Pressing the SOUND shortcut button on the remote D O W N... -
Page 14: How To Set Time, Sleep Time And Wake Up Time
XIII. How to set time, sleep time and wake up time (1) Sleep time setting TIME MENU DOWN EXIT Press MENU button. O f f S L E E P Press P+ or P- button to select TIME menu, the image P r e s s M E N U W A K E U P (p) will appear on the screen, then press... -
Page 15: Adjustment Of Image Display Under Analog Rgb(Pc)/Dtv(Ypbpr) Input Status
XV Adjustment of image display under Analog RGB(PC)/DTV(YPbPr) input status 1 The adjustment of brightness and contrast Press MENU button. PICTURE MENU DOWN EXIT Press P+ or P- button to select PICTURE menu, B R I G H T N E S S the menu (s) will appear on the screen, then press C O N T R A S T T E M P E R A T U R E... -
Page 16: The Pip Function Under Analog Rgb(Pc)/Dtv(Ypbpr) Input Status
XVI. The PIP function under Analog RGB(PC)/DTV(YPbPr) input status Press MENU button. Press P+ or P- button to select PIP menu, the image (w) will appear on the screen, then press MENU DOWN EXIT MENU button to confirm. P I P O N / O F F P I P o f f Press P+or P- button to select the item. -
Page 17: Attached Table 1
Check if the power cable is connected . Check if the signal source has normal output under the current play status. No image and sound Check the brightness and contrast of the image and check if the volume setting is correct. If it is under stand-by status. - Page 18 SPW2.025.347 SS...
