TRANWO Technology VMi120 Smart iCAM User Manual

Smart iCAM
Remote HD Wi-Fi Camera
User's Manual
Pl ease read carefully before using this equipmen t.
EN
Package Contents
One Camera Two Cable Clips
One Adapter This User's Manual
One Screw and One Wall Anchor
2 Product Layout
Camera
1
2
3
4
PUSH TO EJECT PUSH TO EJECT PUSH TO EJECT PUSH TO EJECT
5
9
8 10 11
7. Micro SD Card slot
1.Light sensor
2.Microphone 8. Power adapter socket
3.Camera lens 9. Temperature sensor
4.Infrared LEDs 10. Power ON/OFF switch
5.Speaker 11.Reset button
6. Antenna 12.Power/Status LED
2
Watch the things that matter to you
anytime and anywhere
Internet
Smart iCam Wi-Fi Router
Smart iCAM is a wireless network camera. It can connect with your
smartphone or tablet via wireless technology, and monitor everything
that matters to you on your smartphone or tablet anywhere and anytime.
Before you start you need:
iPhone, iPad, Smart iCAM
Android smartphone
or Android tablet
1
3
Getting Started
3 . Download Smart iCAM app
1
To get started, key in the keyword "Smart iCAM" and
download the app from Apple App Store (iPhone/iPad) or
Google Play Store (Android).
3 .
2 Power Supply
6
1. Connect power adapter to back of the camera and plug into
power outlet.
2. Push the power button on the camera and the LED
should light up.
Note 1: When you power the camera on, the camera need to
take around 30 to 60 seconds for initial setting.
7
2: Push the power button around 10 seconds to turn off
camera.
12
3 . First-time Setup
3
3
3 .
3 Connect iPhone/iPad or Android mobile to the camera
.1
1. Turn on the Wi-Fi of your iPhone/iPad or Android mobile.
2. Tap the screen to select "Smart_iCAM_XXXXXX"
under Wi-Fi Networks. Enter the password and tap
connect button. Default password is "12345678".
Smartphone,Tablet
3. After Wi-Fi connected, open the App of "Smart iCAM" and
will see the welcome screen.
Wi-Fi router
3 .
3 View live video
.2
1. Tap the camera icon in Camera List and you can access the live video.
2. Tap and drag horizontally to pan through the video.
(Only for Pan & Tilt model )
3. Tap and drag vertically to tilt through the video.
(Only for Pan & Tilt model )
4. Tap the video and slide your fingers together or apart to
zoom in or out manually.
5. Zoom in to a video and drag your finger around the screen.
4. Select Wi-Fi SSID for camera Internet setting
After welcome page, the APP will reveal all the Wi-Fi SSID in range.
Tap the SSID used to connect Smart iCAM and enter the password
for the Wi-Fi AP/Router. Please wait for a minute while system reboot,
and the LED will be in green light. The initial setup is completed.
Note 1: SSID is a wireless network identity code that is also
4
3 . Share the camera (Multi-user)
4
3 .
4 Setup in Local Area Network (LAN)
.1
1. Download the App of Smart iCAM.
2. Open the App of Smart iCAM.
3. Tap "Add New Camera" button on Camera List page.
4. Tap the camera name you want to add from "Available Camera List",
enter the password and confirm. Default password is "admin".
6
regarded as name of wireless LAN. The major function of
SSID is to distinguish different wireless LAN. In Wi-Fi
wireless network, SSID represents Wireless Access Point's
network name during broadcast.
2: If you cannot find the Wi-Fi network you want to connect,
please check the Wi-Fi network is available and functions in
range again.
3: If you enter wrong password of SSID, the camera will beep
3 times and reset to factory default automatically. Please
close App and follow the point 3.3 instructions to setup
camera again.
4: If the camera cannot connect to the Internet, the power/status
LED will glow orange light. Please check your wireless
AP/Router and make sure Wi-Fi connection is not out of range.
5: Make sure your mobile connected to the Wi-Fi AP/Router
before.
5
7
